Allen-Bradley 1771-P7 Power Supply | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1771-P7 is a high-reliability power supply module designed for the PLC-5 / 1771 I/O chassis platform. This page provides complete technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Part Number | 1771-P7 |
| Series | 1771 (PLC-5 I/O Chassis) |
| Input Voltage | 85–264 VAC, 47–63 Hz (universal input) |
| Output Voltage | +5 VDC, ±12 VDC, +24 VDC (chassis backplane) |
| Output Current (5V) | Typically 16 A (chassis dependent) |
| Form Factor | Single-slot, left-end mount |
| Chassis Compatibility | 1771-A1B, A2B, A3B, A4B series |
| Operating Temperature | 0 °C to 60 °C |
| Weight | 1.6 kg (approx.) |
| Certifications | UL, CE, CSA |
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or functional replacements for the 1771-P7. Always verify chassis slot count, output current rating, and firmware compatibility before substitution.
| Model | Manufacturer | Compatibility Notes |
|---|---|---|
| 1771-P4S | Allen-Bradley | Same chassis family; lower output current — verify load requirements |
| 1771-P6S | Allen-Bradley | Higher-capacity variant; drop-in for most 1771-P7 applications |
| 1771-P7E | Allen-Bradley | Enhanced version with improved diagnostics; direct functional equivalent |
| 1771-P7 (Refurbished) | Various OEM | Tested & recertified units; suitable for non-critical or backup systems |
| Third-party equivalents | Spectrum Controls / Wago | Verify pinout and output spec before installation; consult datasheet |
⚠ Note: Always cross-reference the chassis catalog number and I/O module count before ordering a replacement power supply.
Why Choose the Original Model
- Guaranteed compatibility — factory-tested against all 1771-series chassis variants
- Rockwell Automation firmware alignment — no risk of backplane communication errors
- Full warranty & traceability — original part numbers ensure audit-ready documentation
- Long service life — designed for 24/7 industrial duty cycles in harsh environments
- Proven field reliability — widely deployed in automotive, oil & gas, and utilities sectors
Typical Applications
- Automotive assembly line control systems
- Oil & gas pipeline monitoring and SCADA integration
- Water treatment and utilities automation
- Food & beverage processing lines
- Legacy PLC-5 system maintenance and life extension projects
- Discrete manufacturing and machine tool control
System Compatibility
The 1771-P7 is designed exclusively for the Allen-Bradley 1771 I/O chassis platform (PLC-5 family). It is not compatible with ControlLogix (1756), CompactLogix (1769), or SLC 500 (1746) chassis without a full system redesign. For migration projects, consult Rockwell’s PLC-5 to ControlLogix Migration Guide or contact Konmask for engineering support.
| Platform | Compatible? | Notes |
|---|---|---|
| 1771 (PLC-5) | ✅ Yes | Native platform — all chassis variants |
| 1756 (ControlLogix) | ❌ No | Different backplane architecture |
| 1769 (CompactLogix) | ❌ No | Compact form factor; incompatible |
| 1746 (SLC 500) | ❌ No | Different power supply standard |
Selection Guide
Use the following decision criteria to confirm the 1771-P7 is the right choice — or to identify the best alternative:
- Step 1 — Identify your chassis: Confirm the 1771-Axx chassis catalog number from the nameplate.
- Step 2 — Count I/O slots: Higher slot counts require higher output current; verify the 1771-P7 rating meets your load.
- Step 3 — Check input voltage: Confirm site supply voltage (120 VAC / 240 VAC) matches the module’s universal input range.
- Step 4 — Evaluate redundancy needs: For critical systems, consider a redundant power supply configuration with a 1771-P7E.
- Step 5 — Assess lifecycle: If migrating away from PLC-5, evaluate ControlLogix migration kits before purchasing additional 1771-series hardware.
Quality Assurance & Sourcing
All units sourced through Konmask.com undergo the following verification process:
- ✅ Visual inspection and label authenticity check
- ✅ Functional power-on test at rated load
- ✅ Output voltage and ripple measurement
- ✅ Traceability documentation (batch/lot records available on request)
- ✅ Anti-static packaging and secure international shipping
We source from authorized distributors, OEM surplus channels, and certified refurbishers. Counterfeit-risk screening is applied to all inbound stock.
How to Order
- Online: Add to cart directly from this page — stock availability shown in real time.
- Email RFQ: support@konmask.com — include part number, quantity, and required delivery date.
- Phone / WhatsApp: +0086 19859288691
- Bulk / Project orders: Request a formal quotation with lead time and warranty terms.
- Export orders: We ship internationally with full commercial invoice and packing list documentation.
Replacement & Compatibility FAQ
Q: Can I use a 1771-P6S instead of a 1771-P7?
A: Yes, in most cases. The 1771-P6S offers higher output current and is a functional upgrade. Verify chassis slot count and total I/O load before substitution.
Q: Is the 1771-P7 still in production?
A: The 1771 series has reached end-of-life (EOL) status with Rockwell Automation. New units are available through authorized surplus channels; refurbished units are a cost-effective alternative.
Q: What is the warranty on units from Konmask?
A: New/surplus units carry a 12-month warranty. Refurbished units carry a 6-month warranty. Extended warranty available on request.
Q: Can I migrate my 1771 system to ControlLogix?
A: Yes. Rockwell offers migration kits and engineering services. Contact us for migration planning support and compatible ControlLogix alternatives.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes, CoC and test reports are available for all units upon request.
