Servo Motion Control Solution — Allen-Bradley 2094-BMP5-S | Kinetix 6000 Series
The Allen-Bradley 2094-BMP5-S is a bypass/brake power module within the Kinetix 6000 multi-axis servo drive system. Designed for high-performance coordinated motion applications, this axis module integrates seamlessly into Rockwell Automation’s Integrated Architecture, enabling precise torque, velocity, and position control across demanding industrial environments.
Where This Product Is Used
The 2094-BMP5-S is specified by motion control engineers across a broad range of industrial sectors:
- Automotive Assembly Lines — Coordinated multi-axis positioning for robotic welding, body-in-white assembly, and transfer systems requiring synchronized servo motion.
- Packaging Machinery — High-speed pick-and-place, form-fill-seal, and cartoning machines where precise axis timing is critical to throughput and product integrity.
- CNC & Machine Tool Applications — Spindle and feed-axis control in milling, turning, and grinding centers demanding sub-millisecond loop closure.
- Material Handling & Conveyance — Servo-driven indexing tables, gantry systems, and overhead transfer units in distribution and logistics facilities.
- Printing & Converting — Web tension control and register correction in flexographic, gravure, and digital printing lines.
- Semiconductor & Electronics Manufacturing — Ultra-precise wafer handling, PCB drilling, and SMT placement requiring micron-level repeatability.
- Food & Beverage Processing — Hygienic servo motion for slicing, portioning, filling, and labeling in regulated production environments.
Technical Specifications
- Part Number: 2094-BMP5-S
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: Kinetix 6000 Multi-Axis Servo Drive
- Module Type: Bypass / Brake Power Module
- Continuous Output Current: 5 A RMS
- Bus Voltage: Compatible with Kinetix 6000 shared DC bus architecture
- Communication: Integrated Motion on EtherNet/IP (via IAM/AM pairing)
- Control Interface: Logix-based motion control via Studio 5000 / RSLogix 5000
- Feedback Support: Hiperface, EnDat, incremental encoder (motor-dependent)
- Mounting: Kinetix 6000 power rail (2094-PRSx series)
- Protection Class: IP20 (panel-mount, enclosure required)
- Weight: 500 g (approx.)
- Certifications: UL, CE, cUL
Why Engineers Specify This Model
- Shared DC Bus Efficiency — The Kinetix 6000 architecture allows regenerative energy from decelerating axes to be reused by accelerating axes, reducing overall energy consumption by up to 30% versus standalone drives.
- Integrated Motion on EtherNet/IP — Eliminates dedicated motion networks; a single EtherNet/IP cable carries both I/O and motion data, simplifying cabinet wiring and reducing commissioning time.
- Logix-Native Programming — Motion instructions (MAM, MAS, MAJ, MAPC) are programmed directly in Studio 5000, eliminating the need for a separate motion controller or proprietary language.
- Scalable Multi-Axis Architecture — Add axes to an existing Kinetix 6000 power rail without redesigning the power supply or bus infrastructure.
- Safe Torque Off (STO) — The -S suffix denotes integrated STO (Safe Stop) functionality, meeting SIL 2 / PLd safety requirements without external safety relays on the drive output.
- Proven Field Reliability — Kinetix 6000 has been deployed in tens of thousands of machines globally since its introduction, with a well-established spare-parts ecosystem.
Complete System Bill of Materials
A functional Kinetix 6000 servo axis using the 2094-BMP5-S typically requires the following components:
- Integrated Axis Module (IAM): 2094-BC01-MP5-S or equivalent (provides AC input, converter, and first axis)
- Power Rail: 2094-PRS2 / 2094-PRS4 / 2094-PRS6 (2, 4, or 6 slot)
- Servo Motor: MPL, MPM, or VPL series (matched to 2094-BMP5-S current rating)
- Motor Power Cable: 2090-CPWM7DF-16AAxx (length-specific)
- Feedback Cable: 2090-CFBM7DF-CEAAxx (motor-specific)
- ControlLogix / CompactLogix Controller: 1756-L7x / 1769-L3x series with EtherNet/IP motion support
- EtherNet/IP Switch: Stratix 5700 or equivalent managed switch
- 24 VDC Control Power Supply: 1606-XLP series or equivalent
- Circuit Breaker / Fusing: Per NEC/IEC sizing for 2094-BMP5-S input current
Contact Konmask for bundle pricing on complete Kinetix 6000 axis kits.
Compliance & Industry Standards
- Safety: IEC 62061 SIL 2, ISO 13849-1 PLd (Safe Torque Off function)
- EMC: EN 61800-3 Category C2 (with recommended line filter)
- Electrical Safety: UL 508C, cUL, CE (Low Voltage Directive 2014/35/EU)
- RoHS: Compliant (Directive 2011/65/EU)
- Industry Protocols: EtherNet/IP (ODVA conformance tested)
- Functional Safety: TÜV-assessed Safe Torque Off per IEC 61800-5-2
Quality Assurance & Sourcing
Konmask.com sources industrial automation components through verified supply channels with full traceability:
- Authenticity Verification — Every unit undergoes visual inspection, label authentication, and where applicable, functional power-on testing before dispatch.
- Traceable Supply Chain — We maintain documentation of origin for all stocked parts, enabling audit-ready procurement for regulated industries.
- Condition Grading — Parts are clearly graded: New (factory-sealed), New Surplus (unused, original packaging), or Refurbished (tested, warranted). Contact us to confirm current stock condition for this SKU.
- Warranty — All units carry a minimum 90-day Konmask operational warranty. Extended warranty options available on request.
- Counterfeit Prevention — We do not source from unverified grey-market channels. Suspicious units are quarantined and not listed for sale.
How to Source This Part
- Confirm your requirement — Verify the part number (2094-BMP5-S) against your existing power rail slot count and IAM model to ensure bus compatibility.
- Check stock & lead time — Contact Konmask via email or phone for real-time availability, condition grade, and lead time. We maintain safety stock on high-velocity Kinetix 6000 modules.
- Request a quote — Provide your required quantity and delivery location. Volume pricing is available for OEM and MRO customers.
- Place your order — Orders can be placed directly on Konmask.com or via purchase order (PO) for approved accounts.
- Receive & verify — Each shipment includes a packing list with part number, serial number (if applicable), and condition grade for your incoming inspection records.
Expedited shipping available. For emergency plant-down situations, contact us directly at +0086 19859288691 for priority handling.
Application-Specific FAQ
Q: Can the 2094-BMP5-S be used as a standalone drive without an IAM?
A: No. The BMP5-S is an Axis Module (AM) that requires an Integrated Axis Module (IAM) on the same power rail to provide AC-to-DC conversion and bus power. It cannot operate independently.
Q: What is the difference between 2094-BMP5 and 2094-BMP5-S?
A: The “-S” suffix indicates the inclusion of the Safe Torque Off (STO) safety function, which allows the drive to be de-energized in a safe state without removing main power. This is required for machinery meeting ISO 13849 PLd or SIL 2 safety ratings.
Q: Which servo motors are compatible with this module?
A: The 2094-BMP5-S is rated for 5 A continuous output. Compatible motors include Allen-Bradley MPL-A/B series and MPM series in the appropriate frame size. Always verify the motor’s continuous stall current does not exceed the drive’s continuous rating.
Q: Can this module be used with a CompactLogix controller?
A: Yes. The Kinetix 6000 system supports Integrated Motion on EtherNet/IP with both ControlLogix (1756) and CompactLogix (1769) platforms running Studio 5000 v20 or later.
Q: Is firmware upgrade required after installation?
A: Firmware is managed through the Logix controller and MotionView Online. Konmask recommends verifying firmware compatibility with your controller revision before commissioning. Contact us if you need assistance with firmware version matching.
Q: Do you offer technical support for integration?
A: Konmask provides pre-sales technical consultation to help confirm compatibility and system BOM. For full commissioning support, we recommend engaging a certified Rockwell Automation system integrator.
