Machine Operator Interface Solution – Allen-Bradley 2711-B6C10 | PanelView 600 Series
The Allen-Bradley 2711-B6C10 is a 6-inch color touchscreen and keypad HMI terminal from the PanelView 600 series, engineered for demanding industrial operator interface applications. Designed to integrate seamlessly with Rockwell Automation control platforms, this unit delivers reliable real-time visualization and operator control in environments where uptime is non-negotiable.
Where This Product Is Used
The 2711-B6C10 is deployed across a wide range of industrial sectors where operators require a robust, intuitive interface to monitor and control automated processes:
- Automotive Assembly Lines — Operator stations for robotic welding cells, conveyor control, and end-of-line test stations.
- Food & Beverage Processing — Batch control panels for mixers, fillers, and pasteurizers requiring washdown-adjacent HMI placement.
- Water & Wastewater Treatment — Pump station control, valve sequencing, and alarm annunciation at remote lift stations.
- Oil & Gas Upstream/Midstream — Wellhead control panels and compressor station operator interfaces.
- Pharmaceutical Manufacturing — GMP-compliant process visualization for reactors, CIP systems, and packaging lines.
- Material Handling & Warehousing — Sortation system control, conveyor speed adjustment, and fault acknowledgment stations.
- HVAC & Building Automation — Chiller plant operator panels and air handling unit control interfaces.
- Machine Tool & OEM Equipment — Embedded operator panels for injection molding machines, presses, and CNC ancillary systems.
Technical Specifications
- Part Number: 2711-B6C10
- Series: PanelView 600
- Manufacturer: Allen-Bradley / Rockwell Automation
- Display Type: 6-inch Color STN LCD
- Input Method: Touchscreen + Keypad (Combination)
- Display Resolution: 320 × 240 pixels (QVGA)
- Communication Port: DH-485 / RS-232 (DF1)
- Power Supply: 24 VDC
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Storage Temperature: −40°C to 85°C
- Enclosure Rating: NEMA 4/4X, 12, 13 (front panel)
- Memory: 512 KB application memory
- Programming Software: PanelBuilder 1400e / RSView ME (legacy)
- Weight: 2,300 g (approx.)
- Certifications: UL, CE, CSA
Why Engineers Specify This Model
- Dual Input Flexibility: The combination of touchscreen and physical keypad allows operation with gloved hands or in high-vibration environments where touch-only panels are unreliable.
- Proven Rockwell Ecosystem Integration: Native DH-485 communication ensures plug-and-play compatibility with SLC 500 and MicroLogix PLC families without additional gateways.
- NEMA 4/4X Front Panel Rating: Suitable for washdown and dust-laden environments without additional enclosure engineering.
- Long Field Service History: Extensive installed base means readily available replacement units, spare parts, and experienced integrators globally.
- Color Display Advantage: Color-coded alarm states and process graphics reduce operator response time versus monochrome alternatives.
- Compact 6-Inch Form Factor: Fits standard panel cutouts, minimizing retrofit engineering costs when replacing legacy terminals.
Complete System Bill of Materials
For a complete PanelView 600 operator station, engineers typically specify the following complementary components:
- 2711-B6C10 — PanelView 600 Color/Touch/Keypad Terminal (this unit)
- 2711-NC13 — DH-485 Communication Cable (PanelView to SLC/MicroLogix)
- 2711-NM14 — RS-232 DF1 Cable
- 1747-UIC — USB-to-DH-485 Interface Converter (for programming)
- 1606-XLP30E — 24 VDC Power Supply (30W, panel mount)
- 2711-ND1 — Memory Module (for application backup/transfer)
- SLC 5/03 or MicroLogix 1100 — Compatible host PLC controller
Contact Konmask.com to source complete BOM packages with verified compatibility.
Compliance & Industry Standards
- UL 508A — Industrial Control Panels
- CE Marking — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- CSA C22.2 — Canadian Standards Association certification
- NEMA 250 — Enclosure Type 4, 4X, 12, 13 front panel compliance
- RoHS — Restriction of Hazardous Substances (verify lot date code)
- IEC 61131-2 — Programmable Controllers: Equipment Requirements and Tests
Quality Assurance & Sourcing
Konmask.com sources the 2711-B6C10 exclusively through verified surplus and authorized distribution channels. Every unit offered is subject to the following quality process:
- Visual Inspection: Housing integrity, display condition, keypad actuation, and connector pin inspection.
- Functional Power-On Test: Unit is powered at 24 VDC and display/keypad response is verified prior to shipment.
- Date Code & Firmware Logging: Series letter, firmware revision, and manufacture date code are recorded and available on request.
- Anti-Static Packaging: Shipped in ESD-safe bags with foam cushioning and double-wall carton.
- Traceability: Each unit is assigned an internal lot reference for post-sale traceability.
How to Source This Part
- In-Stock Orders: Add to cart and complete checkout. Orders confirmed before 18:00 CST ship same business day.
- Bulk / Project Quantities: Contact support@konmask.com for volume pricing and lead time on quantities of 3 or more units.
- Urgent / Emergency Replacement: Call or WhatsApp +0086 19859288691 for expedited sourcing and same-day quotation.
- International Shipping: DDP (Delivered Duty Paid) options available for EU, Southeast Asia, and Middle East destinations. Contact us for customs documentation support.
- Exchange / Core Return Program: Have a faulty 2711-B6C10? Ask about our exchange program to reduce net replacement cost.
Application-Specific FAQ
Q: Is the 2711-B6C10 compatible with ControlLogix or CompactLogix PLCs?
A: Not natively. The PanelView 600 series communicates via DH-485 or RS-232 DF1, which are native to SLC 500 and MicroLogix families. For ControlLogix/CompactLogix integration, consider upgrading to the PanelView Plus 600 (2711P series) with EtherNet/IP support.
Q: Can I reuse my existing PanelBuilder application files?
A: Yes. Applications created in PanelBuilder 1400e (.PBA files) are directly transferable to the 2711-B6C10 via the 2711-ND1 memory module or serial download cable.
Q: What is the panel cutout dimension for the 2711-B6C10?
A: The standard panel cutout is 192 mm × 141 mm (7.56″ × 5.55″). Refer to Allen-Bradley installation document 2711-IN009 for full mounting specifications.
Q: Is this unit suitable for Class I Division 2 hazardous locations?
A: The standard 2711-B6C10 is not rated for Class I Div 2. For hazardous location applications, consult Rockwell Automation for purged/pressurized enclosure solutions or alternative certified HMI products.
Q: What warranty does Konmask.com provide?
A: All units carry a 90-day functional warranty covering defects in operation under normal use conditions. Extended warranty options are available — contact us for details.
Q: Can Konmask.com assist with PanelView 600 to PanelView Plus migration projects?
A: Yes. Our technical team can advise on migration paths, compatible replacement models, and application conversion considerations. Contact support@konmask.com with your project details.
