Allen-Bradley 2711P-B6C20D PanelView Plus 600 Color Keypad/Touch Screen | Replacement, Equivalent & Selection Guide
The Allen-Bradley 2711P-B6C20D is a 6-inch color HMI terminal from Rockwell Automation’s PanelView Plus 600 series, combining a keypad and touch screen interface for flexible operator control in industrial automation environments. This page provides full technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
- Part Number: 2711P-B6C20D
- Brand / Manufacturer: Allen-Bradley (Rockwell Automation)
- Series: PanelView Plus 600
- Display Size: 6.5-inch color TFT LCD
- Resolution: 320 × 240 (QVGA)
- Interface Type: Keypad + Touch Screen (dual-mode)
- Communication Ports: RS-232, DH-485, DF1, DeviceNet (via adapter)
- Ethernet: 10/100 Mbps (RJ-45)
- Memory: 512 MB Flash / 128 MB RAM
- Operating System: Windows CE 6.0
- Power Supply: 24 VDC (18–32 VDC range)
- Power Consumption: Approx. 25 W
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: −40 °C to 70 °C
- Humidity: 5–95% RH (non-condensing)
- Protection Rating: NEMA 4/4X, 12, 13; IP65 (front panel)
- Certifications: UL, CE, cUL
- Weight: Approx. 2.3 kg
- Dimensions (H × W × D): 200 × 260 × 75 mm (approx.)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as direct or functional replacements for the 2711P-B6C20D. Always verify communication protocol, mounting cutout, and software compatibility before substitution.
- 2711P-B6C5A8 — PanelView Plus 6 600, same form factor, updated firmware platform
- 2711P-T6C20D — Touch-only variant of the same 600 series (no keypad)
- 2711P-B6C5D — Compact 600 series with CE 6.0, direct functional equivalent
- 2711P-B7C4D8 — 7-inch upgrade option when larger display is acceptable
- 2711R-T7T — PanelView 800 series, suitable for simpler applications with reduced feature set
- Weintek MT8071iE — Third-party equivalent; supports AB EtherNet/IP and DF1 protocols
- Siemens KTP600 Basic PN — Cross-brand alternative for EtherNet/IP-compatible systems
Note: Third-party replacements require application re-engineering. Contact Konmask for compatibility assessment.
Why Choose the Original Model
- Native FactoryTalk View ME integration — zero re-programming required for existing AB systems
- Dual-input flexibility — keypad + touch screen suits both gloved-hand and precision touch environments
- Proven field reliability — widely deployed in automotive, food & beverage, and discrete manufacturing
- Rockwell ecosystem compatibility — seamless integration with ControlLogix, CompactLogix, MicroLogix, and SLC 500 PLCs
- Long-term parts availability — Konmask maintains stock of new, refurbished, and tested units
Typical Applications
- Machine operator panels on assembly lines
- Process monitoring stations in food & beverage plants
- HVAC and building automation control interfaces
- Packaging machinery HMI replacement projects
- Water treatment and utilities SCADA front-ends
- OEM equipment upgrades requiring drop-in HMI replacement
System Compatibility
- Software: FactoryTalk View Studio ME (v5.0 and above recommended)
- PLC Families: ControlLogix (1756), CompactLogix (1769), MicroLogix (1100/1400), SLC 500, PLC-5
- Networks: EtherNet/IP, DH-485, DF1 (RS-232), DeviceNet (with adapter)
- Mounting: Panel cutout 192 × 138 mm (standard PanelView Plus 600 cutout)
- Firmware: Compatible with FactoryTalk View ME runtime v5.x–v9.x
Selection Guide
Use the criteria below to confirm the 2711P-B6C20D is the right choice, or to identify the best alternative:
- Display size needed: 6-inch → 2711P-B6C20D ✓ | 7-inch → consider 2711P-B7C4D8 | 10-inch → consider 2711P-B10C4D8
- Input method: Keypad + Touch → 2711P-B6C20D ✓ | Touch only → 2711P-T6C20D
- Communication protocol: EtherNet/IP + serial → 2711P-B6C20D ✓ | EtherNet/IP only → 2711P-B6C5A8
- Environment: IP65 / NEMA 4 required → 2711P-B6C20D ✓
- Budget / availability: Refurbished units available — contact Konmask for pricing
- Software platform: Existing FactoryTalk ME project → original model preferred to avoid migration effort
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels
- New-in-box (NIB), factory-refurbished, and tested-used grades available
- Each unit undergoes power-on functional verification before shipment
- Traceable documentation provided upon request (test reports, CoC)
- Warranty: 12 months on new units; 6 months on refurbished units
- Export compliance: EAR99 classification; no license required for most destinations
How to Order
- Step 1: Confirm part number — 2711P-B6C20D
- Step 2: Specify required condition: New / Refurbished / Tested-Used
- Step 3: Indicate quantity and required delivery timeline
- Step 4: Submit inquiry via support@konmask.com or add to cart and checkout
- Step 5: Receive quotation within 1 business day; lead time confirmed at order
For urgent requirements or bulk orders (>5 units), contact us directly at +0086 19859288691 for priority handling.
Replacement & Compatibility FAQ
Q: Can I replace a 2711P-B6C20D with a 2711P-B6C5A8 without reprogramming?
A: In most cases yes — both run FactoryTalk View ME and share the same form factor. However, firmware version differences may require a project conversion in FactoryTalk View Studio. Always test on a backup before live deployment.
Q: Is the 2711P-B6C20D compatible with ControlLogix 5580 (v32+)?
A: The hardware is compatible via EtherNet/IP, but FactoryTalk View ME runtime v9.0+ is recommended for full feature support with newer Logix firmware. Verify runtime version on the unit before connecting.
Q: Can a third-party HMI (e.g., Weintek) replace this unit?
A: Yes, with re-engineering. The Weintek MT8071iE supports AB EtherNet/IP and DF1 drivers, but the FactoryTalk ME project must be rebuilt in EasyBuilder Pro. Konmask can advise on migration scope.
Q: What is the panel cutout size for the 2711P-B6C20D?
A: Standard cutout is approximately 192 mm × 138 mm. Refer to Rockwell publication 2711P-IN006 for exact dimensional drawings.
Q: Do you supply refurbished units with warranty?
A: Yes. Refurbished units carry a 6-month warranty covering manufacturing defects. All units are functionally tested prior to dispatch.
