Industrial Drive Power Rectification Solution — Allen-Bradley 80190-380-01-R | SCB Series
Where This Product Is Used
The Allen-Bradley 80190-380-01-R Rectifier Board is a packaged custom SCB (Servo Control Board) rectifier assembly deployed in high-demand industrial power conversion environments. Typical installation sites include:
- CNC Machining Centers — Provides stable DC bus voltage for spindle and axis servo drives in multi-axis milling and turning centers.
- Automated Assembly Lines — Supports AC-to-DC conversion in Allen-Bradley drive systems powering conveyor, pick-and-place, and robotic actuators.
- Injection Molding Machines — Rectifies three-phase AC input to supply consistent DC power to hydraulic servo pump drives.
- Metal Forming & Press Equipment — Handles high-cycle rectification demands in servo-driven press and stamping applications.
- Packaging & Material Handling — Integrated into Allen-Bradley drive cabinets for continuous-duty packaging line servo systems.
- Oil & Gas Field Equipment — Used in drive panels requiring robust rectification under harsh environmental conditions.
Technical Specifications
| Attribute | Value |
|---|---|
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Part Number | 80190-380-01-R |
| Series | SCB (Servo Control Board) — Custom Packaged |
| Component Type | Rectifier Board Assembly |
| Package Type | PKGD CUSTR (Packaged Custom) |
| Weight | 320 g |
| Condition | New / Refurbished (specify at inquiry) |
| Compatibility | Allen-Bradley SCB-series servo drive platforms |
| Country of Origin | USA (Original Manufacture) |
For full electrical ratings (input voltage, current capacity, switching frequency), please contact our technical team with your drive model number for cross-reference confirmation.
Why Engineers Specify This Model
- OEM-Matched Design — The 80190-380-01-R is a factory-packaged custom board, ensuring dimensional and electrical compatibility with Allen-Bradley SCB drive enclosures without field modification.
- Reduced Downtime Risk — Stocking this board as a critical spare eliminates multi-week lead times during unplanned drive failures on production lines.
- Proven Reliability in High-Cycle Applications — Designed for continuous industrial duty cycles typical of servo and spindle drive systems.
- Drop-In Replacement — Maintains original connector pinout and mounting footprint, enabling rapid board swap without rewiring.
- Traceability — Sourced with full part number traceability to Allen-Bradley / Rockwell Automation manufacturing records.
Complete System Bill of Materials
When replacing or upgrading the rectifier board in an Allen-Bradley SCB drive system, engineers typically source the following complementary components:
- SCB Servo Control Board (main logic board)
- Gate Driver / IGBT Module (power stage)
- DC Bus Capacitor Bank
- Current Feedback Module / Hall-Effect Sensor
- Encoder Interface Board
- Power Supply Board (auxiliary 24 VDC)
- Fuse & Fuse Holder Assembly (input protection)
- Thermal Interface Pad / Heatsink Assembly
Contact support@konmask.com for a complete BOM quote for your drive model.
Compliance & Industry Standards
- CE Marking — Original Allen-Bradley components comply with EU Low Voltage Directive and EMC Directive requirements.
- UL Listed — Manufactured under Rockwell Automation’s UL-recognized quality program.
- RoHS Compliance — Confirm revision suffix (-R) for RoHS-compliant variant applicability.
- ISO 9001 — Sourced through suppliers operating under ISO 9001-certified quality management systems.
- IEC 61800 Series — Compatible with adjustable-speed electrical power drive systems per IEC 61800 standards.
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley component undergoes a structured verification process before dispatch:
- Visual Inspection — Board surface, solder joints, connector integrity, and component seating checked against OEM reference.
- Part Number Verification — Label, silkscreen, and packaging cross-referenced to confirm exact 80190-380-01-R identity.
- Functional Test (where applicable) — Boards sourced as refurbished are bench-tested prior to listing.
- Anti-Static Packaging — Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceability Documentation — Certificate of conformance and sourcing records available upon request for MRO and OEM procurement teams.
How to Source This Part
To place an order or request a formal quotation for the AB 80190-380-01-R Rectifier Board:
- Online: Add to cart directly on this page and complete checkout. We accept T/T bank transfer, PayPal, and major credit cards.
- Email RFQ: Send your part number, required quantity, and delivery timeline to support@konmask.com.
- Phone / WhatsApp: Call or message +0086 19859288691 for urgent sourcing inquiries.
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock items: contact us for sourcing ETA.
- Export: We ship globally. DDP, DAP, and EXW Incoterms available. Export documentation provided for customs clearance.
Application-Specific FAQ
Q: Is the 80190-380-01-R compatible with all Allen-Bradley SCB drive variants?
A: This board is designed for specific SCB-series configurations. Please provide your full drive model number so our engineers can confirm compatibility before purchase.
Q: What does the “-R” suffix indicate?
A: The “-R” suffix typically denotes a revised or RoHS-compliant variant of the base part. Confirm with your drive documentation or contact us for clarification.
Q: Can this board be repaired instead of replaced?
A: Board-level repair is possible for some failure modes (blown fuses, failed diodes). Contact us to discuss repair vs. replacement economics for your application.
Q: Do you offer a warranty on this part?
A: Yes. New units carry a 12-month warranty. Refurbished units carry a 6-month warranty. Terms available on request.
Q: Can I return the part if it does not fit my drive?
A: We recommend confirming compatibility before purchase. Returns are accepted within 30 days for uninstalled parts in original packaging. See our Returns Policy for details.
