Factory Automation HMI Solution – Allen-Bradley 6176M-19PT | 6176M Series Industrial Monitor
The Allen-Bradley 6176M-19PT is a 19-inch industrial-grade flat panel monitor engineered for demanding manufacturing and process control environments. Designed as a dedicated display solution for Rockwell Automation PanelView and FactoryTalk systems, this monitor delivers reliable, high-visibility operator interface performance across continuous-duty industrial applications.
Where This Product Is Used
The 6176M-19PT is specified across a broad range of industrial sectors where operators require a large-format, rugged display integrated into control panels or operator workstations:
- Automotive Manufacturing: Assembly line HMI stations, robotic cell operator panels, and paint shop control rooms requiring continuous 24/7 display operation.
- Food & Beverage Processing: Washdown-adjacent control panels in packaging lines, filling stations, and conveyor management systems.
- Oil & Gas / Petrochemical: Control room SCADA workstations, pipeline monitoring panels, and compressor station operator interfaces.
- Pharmaceutical Manufacturing: GMP-compliant production line HMI displays, batch control stations, and cleanroom-adjacent operator panels.
- Water & Wastewater Treatment: SCADA visualization terminals, pump station control panels, and remote monitoring workstations.
- Power Generation & Utilities: Substation control rooms, turbine monitoring panels, and distributed control system (DCS) operator stations.
- Material Handling & Logistics: Warehouse automation control desks, sortation system HMI stations, and conveyor control panels.
- Discrete Manufacturing: CNC machine operator interfaces, press control panels, and production line supervision stations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 6176M-19PT |
| Brand / Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | 6176M Industrial Monitor Series |
| Display Size | 19 inches (diagonal) |
| Display Type | TFT LCD Flat Panel |
| Touch Technology | Resistive Touchscreen (PT = Touch) |
| Resolution | 1280 × 1024 (SXGA) |
| Brightness | Approx. 250–300 cd/m² |
| Contrast Ratio | 700:1 (typical) |
| Video Input | VGA (DB-15), DVI (model dependent) |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature | -20°C to +60°C |
| Humidity | 10–90% RH, non-condensing |
| Enclosure Rating | NEMA 4 / IP65 (front panel) |
| Mounting | Panel mount (cutout required) |
| Weight | Approx. 200 g (shipping weight; unit weight varies) |
| Certifications | UL, CE, cUL |
Why Engineers Specify This Model
- Seamless Rockwell Ecosystem Integration: Natively compatible with FactoryTalk View SE/ME, PanelView Plus, and RSView32 — no driver conflicts or display calibration issues common with third-party monitors.
- NEMA 4 / IP65 Front Panel Sealing: Protects against dust ingress, water jets, and coolant splatter — essential for machine-side installations in metalworking and food processing.
- 19″ SXGA Resolution: Provides ample screen real estate for complex HMI faceplates, trend displays, and alarm management screens without operator eye strain.
- Resistive Touch Interface: Operable with gloved hands — critical for operators in automotive, chemical, and heavy manufacturing environments.
- Wide Input Voltage Range: 100–240 VAC universal input eliminates the need for step-down transformers in international installations.
- Long Product Lifecycle: Rockwell Automation’s extended lifecycle support policy ensures spare parts and firmware availability for 7+ years post-purchase.
- Panel-Mount Form Factor: Designed for flush integration into NEMA enclosures and operator consoles — maintains enclosure integrity without additional sealing hardware.
Complete System Bill of Materials
For a complete Allen-Bradley HMI workstation or operator panel build, the following complementary components are typically specified alongside the 6176M-19PT:
- Controller: Allen-Bradley ControlLogix (1756 series) or CompactLogix (1769 series) PLC
- HMI Software: FactoryTalk View Site Edition (SE) or Machine Edition (ME)
- Communication Module: 1756-ENBT or 1756-EN2T EtherNet/IP bridge module
- Power Supply: Allen-Bradley 1606-XLP or 1606-XLS series 24VDC panel power supply
- I/O Modules: 1756-IB16 (digital input) / 1756-OB16E (digital output) for field device integration
- Networking: Stratix 5700 managed Ethernet switch for EtherNet/IP topology
- Enclosure: Hoffman A-series or Rittal TS8 NEMA 4 steel enclosure
- Cables: VGA or DVI video cable (shielded, industrial grade), USB touch interface cable
Compliance & Industry Standards
- UL 508A — Industrial Control Panels (panel-mount installation compliance)
- CE Marking — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- cUL — Canadian Standards compliance (CSA equivalent)
- NEMA 4 / IEC IP65 — Front panel ingress protection rating
- RoHS Compliant — Restriction of Hazardous Substances Directive
- FCC Part 15 Class A — Electromagnetic emissions for industrial environments
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley 6176M-19PT unit is subject to a rigorous pre-shipment verification process:
- ✅ Authenticity Verification: Units are cross-referenced against Rockwell Automation authorized distributor records and date codes.
- ✅ Functional Power-On Test: Display backlight, touch calibration, and video signal acceptance verified before dispatch.
- ✅ Physical Inspection: Front panel seal integrity, connector condition, and bezel completeness checked against OEM specifications.
- ✅ Traceability Documentation: Each unit ships with inspection records, sourcing documentation, and a Konmask quality certificate.
- ✅ Secure Packaging: Anti-static foam packaging with humidity indicator cards for safe international transit.
How to Source This Part
- Confirm Your Requirements: Verify the part number (6176M-19PT), required quantity, and any firmware or accessory needs (mounting brackets, cables).
- Request a Quote: Contact our team via email at support@konmask.com or WhatsApp/phone at +0086 19859288691 for volume pricing and lead time confirmation.
- Submit Your Purchase Order: PO accepted via email. We support T/T wire transfer, PayPal, and major credit cards.
- Receive Shipping Confirmation: Units ship within 1–3 business days from verified stock. DHL, FedEx, and UPS express options available.
- Post-Delivery Support: Our technical team provides installation guidance and compatibility verification at no additional charge.
Application-Specific FAQ
Q: Is the 6176M-19PT compatible with FactoryTalk View ME running on a PanelView Plus 7?
A: The 6176M-19PT is a standalone monitor — it requires a separate PC or thin client running FactoryTalk View SE, or can be used as an extended display. It is not a PanelView Plus replacement but complements PanelView-based systems as a secondary operator display.
Q: Can this monitor be used in a NEMA 12 enclosure environment?
A: The front panel is rated NEMA 4 / IP65, making it suitable for NEMA 12 (dust and drip-tight) environments. The rear of the unit requires a clean, dry enclosure interior.
Q: What video signal does the 6176M-19PT accept?
A: The standard 6176M-19PT accepts VGA (analog RGB) input via a DB-15 connector. Confirm your source device output compatibility before ordering.
Q: Is the touchscreen operable with chemical-resistant gloves?
A: Yes. The resistive touch technology responds to pressure rather than capacitance, making it fully operable with standard industrial gloves including nitrile, latex, and leather variants.
Q: What is the typical lead time for the 6176M-19PT?
A: In-stock units ship within 1–3 business days. For large quantity orders or units requiring specific firmware, lead time is 5–10 business days. Contact us for real-time stock confirmation.
Q: Do you provide a warranty on this unit?
A: Yes. Konmask provides a 90-day functional warranty on all industrial monitors. Extended warranty options are available upon request.
