Allen-Bradley 80190-300-01-R – Packaged Customer XIO Board Assembly | Rockwell Automation Control Platform
Engineering Background: The Allen-Bradley 80190-300-01-R is a factory-packaged customer XIO (eXtended I/O) board assembly designed for integration within Rockwell Automation’s industrial control architectures. XIO board assemblies serve as the physical interface layer between the control backplane and field-level I/O signals, enabling deterministic data exchange in demanding process and discrete manufacturing environments.
Product Positioning: This assembly is engineered for OEM integrators, system builders, and MRO procurement teams requiring a pre-packaged, quality-verified XIO board replacement or expansion component. The “-R” revision designation indicates a controlled engineering revision, ensuring backward compatibility within qualified system configurations. Sourced through Konmask’s verified industrial supply chain, this unit is suitable for both new installations and legacy system maintenance.
Complete Technical Specifications
- Part Number: 80190-300-01-R
- Manufacturer: Allen-Bradley / Rockwell Automation
- Description: Packaged Customer XIO Board Assembly
- Revision: -R (controlled engineering revision)
- Assembly Type: XIO (eXtended I/O) Board, customer-packaged configuration
- Form Factor: PCB board assembly, packaged for field installation
- Weight: Approx. 400 g (packaged)
- Compatibility: Rockwell Automation industrial control platforms utilizing XIO backplane architecture
- Condition: New / Surplus New (specify at time of order)
- Country of Origin: USA (Rockwell Automation manufacturing)
- RoHS Compliance: Per Rockwell Automation product documentation
- Warranty: 12-month Konmask quality warranty
Proven Application Environments
- Discrete manufacturing automation lines requiring XIO backplane expansion
- Process control systems with distributed I/O architectures
- OEM machine builder platforms integrating Allen-Bradley control hardware
- MRO (Maintenance, Repair & Operations) replacement for existing XIO board failures
- System upgrades and capacity expansions within qualified Rockwell Automation installations
- Automotive, food & beverage, oil & gas, and general industrial sectors
Engineering Advantages
- Factory-Packaged Integrity: Delivered in OEM packaging, preserving ESD protection and mechanical integrity during transit and storage
- Revision-Controlled Design: The “-R” suffix ensures traceability and compatibility within documented system revisions
- Plug-and-Play Replacement: Designed for direct substitution within compatible XIO backplane slots — minimizes downtime during MRO events
- Rockwell Ecosystem Compatibility: Engineered to operate within Allen-Bradley’s deterministic I/O communication protocols
- Quality-Verified Supply: Each unit sourced and inspected through Konmask’s industrial component verification process
System Architecture & Signal Flow
The 80190-300-01-R XIO board assembly interfaces with the system backplane to extend I/O capacity beyond the local chassis. In a typical Rockwell Automation architecture, the XIO board acts as a bridge between the main controller backplane and remote or extended I/O racks. Signal flow proceeds from field devices → terminal blocks → XIO board I/O circuitry → backplane communication bus → controller CPU. The packaged assembly includes the board, mounting hardware, and protective packaging as shipped from the factory, ready for installation by qualified automation engineers.
Sourcing & Quality Verification
- Source Traceability: Units are sourced from authorized distributors, OEM surplus, or factory-new stock with documented chain of custody
- Incoming Inspection: Visual inspection for physical damage, label verification (part number, revision, date code), and packaging integrity check
- Counterfeit Mitigation: All Allen-Bradley components verified against Rockwell Automation part marking standards prior to listing
- Storage Conditions: Stored in ESD-safe, climate-controlled warehouse environment
- Documentation: Certificate of conformance and packing list provided upon request
Procurement Process
- Step 1 — Inquiry: Submit your BOM or part number requirement via email or the product page inquiry form
- Step 2 — Quote: Konmask provides a formal quotation within 1 business day, including lead time and availability confirmation
- Step 3 — Order Confirmation: Purchase order accepted via email; proforma invoice issued for payment processing
- Step 4 — Quality Check & Dispatch: Unit undergoes final inspection before secure packaging and shipment
- Step 5 — Delivery & Support: Tracking provided upon dispatch; Konmask technical support available post-delivery
Lead Time: Typically 3–7 business days for in-stock units; extended lead times communicated at quotation stage.
Minimum Order Quantity: 1 unit.
Payment Terms: T/T, PayPal, or as agreed.
Technical FAQ
Q: Is the 80190-300-01-R compatible with all Allen-Bradley XIO backplane systems?
A: Compatibility depends on the specific system revision and backplane configuration. Please provide your system model and firmware version when inquiring to confirm compatibility.
Q: What does the “-R” revision suffix indicate?
A: The “-R” suffix denotes a specific engineering revision of the board assembly. It is important to match the revision to your system’s qualified component list (QCL) or consult Rockwell Automation documentation.
Q: Can Konmask provide a certificate of conformance?
A: Yes. A certificate of conformance and inspection record are available upon request for all orders.
Q: What is the warranty coverage?
A: Konmask provides a 12-month warranty against defects in materials and workmanship from the date of shipment. Warranty claims are processed via our support team.
Q: Do you offer volume pricing for multiple units?
A: Yes. Volume discounts are available for orders of 3+ units. Contact our sales team for a tailored quotation.
