Engineering Background
The Allen-Bradley 80190-320-03-R is a factory-packaged Customer Interface Board (CIB) Assembly designed for integration within Rockwell Automation drive and control platforms. CIB assemblies serve as the critical communication and signal-conditioning bridge between the host controller and peripheral field devices, ensuring deterministic data exchange in demanding industrial environments.
Product Positioning
This board assembly is a genuine OEM replacement and upgrade component sourced through verified Rockwell Automation supply channels. It is positioned for procurement engineers and maintenance teams requiring a drop-in, spec-compliant replacement that eliminates re-engineering risk and minimizes system downtime. Konmask.com stocks this component with full traceability documentation available upon request.
Complete Technical Specifications
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Part Number | 80190-320-03-R |
| Description | PKGD Customer CIB Board Assembly |
| Component Type | Customer Interface Board (CIB) Assembly |
| Packaging | Factory-packaged (PKGD) — OEM original packaging |
| Revision | -R (Revision R) |
| Weight | 250 g (approx.) |
| Condition | New / Surplus New / Refurbished (specify at inquiry) |
| Compliance | RoHS-compliant; CE-marked platform |
| Country of Origin | USA |
Proven Application Environments
- Rockwell Automation PowerFlex drive systems requiring CIB interface replacement
- Industrial automation control panels with Allen-Bradley drive integration
- OEM machine builders using Rockwell Automation drive platforms
- Preventive maintenance programs for critical production lines
- Retrofit and modernization projects upgrading legacy AB drive systems
- Spare parts inventory programs for automotive, food & beverage, oil & gas, and water treatment facilities
Engineering Advantages
- OEM Genuine Component: Ensures full electrical and mechanical compatibility with the host drive platform — no derating or workaround required.
- Factory-Packaged (PKGD): Ships in original Rockwell Automation packaging with ESD protection, preserving component integrity during transit and storage.
- Revision-Controlled (-R): Revision suffix guarantees compatibility with specific firmware and hardware generations, eliminating field substitution risk.
- Drop-In Replacement: No re-parameterization or re-wiring required when replacing a like-for-like CIB board in the same drive chassis.
- Reduced MTTR: Stocking this board as a critical spare reduces Mean Time To Repair (MTTR) for unplanned drive faults.
System Architecture & Signal Flow
The CIB (Customer Interface Board) functions as the primary I/O and communication interface layer within the Allen-Bradley drive assembly. Signal flow is as follows:
- Input Side: Receives analog/digital command signals from the host PLC or DCS controller via the backplane or dedicated I/O terminals.
- Processing Layer: On-board logic conditions, isolates, and routes signals to the drive’s main control board.
- Output Side: Delivers conditioned reference signals to the drive’s power stage and feedback signals back to the controller.
- Isolation: Galvanic isolation between field-side and drive-side circuits protects both the controller and the board from transient damage.
This architecture ensures that field-level noise, ground loops, and voltage transients do not propagate into the drive’s control electronics.
Sourcing & Quality Verification
- Supply Chain: Sourced from authorized Rockwell Automation distributors and verified surplus channels with full chain-of-custody documentation.
- Inspection Protocol: Each unit undergoes visual inspection, label verification (part number, revision, date code), and packaging integrity check prior to shipment.
- Traceability: Date codes and serial numbers are recorded and available upon request for quality audit purposes.
- Anti-Counterfeit: Konmask.com does not source from unverified grey-market channels. All components are cross-referenced against Rockwell Automation’s published part number database.
- Warranty: 12-month warranty against manufacturing defects. DOA replacement within 30 days of receipt.
Procurement Process
- Submit Inquiry: Contact support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options.
- Order Confirmation: Issue a Purchase Order (PO) referencing part number 80190-320-03-R.
- Quality Check & Packaging: Unit is inspected, documented, and packed with ESD-safe materials.
- Shipment: Dispatched via DHL / FedEx / UPS with full tracking. Export documentation (commercial invoice, packing list, COO) provided for international orders.
- After-Sales Support: Technical support available post-delivery for installation verification queries.
Technical FAQ
Q: Is the 80190-320-03-R compatible with all PowerFlex drive models?
A: Compatibility is specific to the drive platform and firmware revision for which this CIB board was designed. Please provide your drive model number when inquiring so we can confirm compatibility.
Q: What does the “-R” revision suffix indicate?
A: The “-R” suffix denotes a specific hardware revision level. It is critical to match the revision of the replacement board to the revision specified in your drive’s service documentation to ensure correct operation.
Q: Can this board be repaired rather than replaced?
A: Board-level repair is possible in some cases but is not recommended for safety-critical or high-availability applications. Replacement with a new or surplus-new OEM board is the preferred approach to restore full manufacturer specifications.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. A CoC is available upon request for all orders. Please specify this requirement at the time of purchase.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. If not in stock, lead time is typically 2–4 weeks depending on sourcing. Contact us for real-time availability.
