ABB 235820-00171490 – Rectangular Ring Terminal | Industrial Crimp Lug Connector | ABB Wiring Accessories Series
Engineering Background
ABB’s wiring accessories portfolio is engineered to meet the rigorous demands of industrial panel building, machine wiring, and process automation. The 235820-00171490 Rectangular Ring Terminal is part of ABB’s comprehensive terminal and connector range, designed to deliver consistent, vibration-resistant electrical connections in demanding environments.
Product Positioning
This rectangular ring terminal is the preferred choice for procurement engineers specifying reliable crimp-type lugs for switchgear panels, motor control centers (MCCs), and industrial control cabinets. It provides a secure, low-resistance connection point that withstands mechanical stress and thermal cycling.
Complete Technical Specifications
- Part Number / SKU: 235820-00171490
- Manufacturer: ABB
- Product Type: Rectangular Ring Terminal (Crimp Lug)
- Series / Platform: ABB Wiring Accessories – Terminal & Connector Series
- Connection Method: Crimp
- Terminal Shape: Rectangular Ring
- Material: Electrolytic copper with tin plating (typical ABB standard)
- Insulation: Non-insulated / bare metal (verify with datasheet)
- Weight: 500 g (packaged)
- Country of Origin: CN
- Compliance: RoHS compliant; CE marked (verify with official ABB datasheet)
Proven Application Environments
- Industrial switchgear and control panel wiring
- Motor Control Centers (MCC) and Variable Frequency Drive (VFD) installations
- Process automation and DCS/PLC cabinet terminations
- Power distribution boards and bus bar connections
- Railway, marine, and heavy-duty machinery wiring
- Building automation and HVAC control systems
Engineering Advantages
- Secure Mechanical Bond: Rectangular ring geometry prevents rotation and ensures consistent torque retention on bolt terminals
- Low Contact Resistance: Tin-plated copper construction minimizes resistive losses and prevents oxidation
- Vibration Resistance: Crimp connection eliminates solder joint fatigue in high-vibration environments
- ABB Ecosystem Compatibility: Designed to integrate seamlessly with ABB terminal blocks, busbars, and panel components
- Consistent Quality: Manufactured under ABB’s ISO-certified production processes
System Architecture & Signal Flow
The 235820-00171490 functions as the termination point between stranded or solid copper conductors and bolted connection points (studs, busbars, or terminal blocks). The crimp barrel accepts the stripped conductor end; the rectangular ring eye is then secured under a bolt or screw, completing a gas-tight, low-impedance electrical path. This architecture is standard in IEC 60947-compliant panel assemblies.
Sourcing & Quality Verification
- Authorized Distribution: Konmask.com sources ABB components through verified supply channels to ensure authenticity
- Traceability: Each shipment is accompanied by documentation supporting part number and batch traceability
- Inspection: Products undergo incoming quality inspection before dispatch
- Datasheet Verification: Buyers are encouraged to cross-reference the ABB official part number 235820-00171490 against the ABB product catalog prior to ordering
Procurement Process
- Confirm part number 235820-00171490 against your BOM or panel schedule
- Select required quantity and add to cart
- Submit purchase order or proceed to checkout (B2B invoicing available on request)
- Receive order confirmation with estimated lead time
- Shipment dispatched with tracking; DDP/DAP terms available for international orders
- Contact support@konmask.com for bulk pricing, technical queries, or expedited sourcing
Technical FAQ
Q: Is this an OEM ABB part or a compatible replacement?
A: Konmask.com supplies genuine ABB parts. The 235820-00171490 is an authentic ABB product sourced through verified channels.
Q: What conductor cross-section does this terminal accept?
A: Please refer to the official ABB datasheet for 235820-00171490 for exact wire gauge and cross-section specifications. Contact us if you need assistance identifying the correct variant.
Q: Can I order in bulk quantities?
A: Yes. Bulk and project-quantity orders are welcome. Contact us at support@konmask.com or call +0086 19859288691 for volume pricing.
Q: What is the lead time?
A: Standard in-stock items ship within 1–3 business days. Lead times for larger quantities or special configurations will be confirmed at order.
Q: Do you provide a certificate of conformance?
A: Yes, documentation including CoC and packing lists can be provided upon request.
