ABB 3BHB006309R0001 – UNS0882A-PV1 Control Board | AC800M DCS Platform
Engineering Background: The ABB AC800M is ABB’s flagship Distributed Control System (DCS) controller platform, widely deployed in power generation, oil & gas, pulp & paper, and chemical process industries. The 3BHB006309R0001 (UNS0882A-PV1) is a dedicated control board within the AC800M architecture, responsible for core process logic execution, I/O coordination, and real-time communication across the control network.
Product Positioning: Designed for procurement engineers and MRO specialists sourcing certified replacement or expansion boards for existing AC800M DCS installations. Konmask.com supplies this module with full traceability documentation, enabling rapid integration without system reconfiguration.
Complete Technical Specifications
- Part Number: 3BHB006309R0001
- Module Designation: UNS0882A-PV1
- Manufacturer: ABB Ltd. (Switzerland)
- Platform: AC800M Distributed Control System (DCS)
- Module Type: Control Board / Processor Card
- Form Factor: Rack-mount, DIN-rail compatible within AC800M chassis
- Operating Voltage: 24 VDC (supplied via backplane)
- Operating Temperature: 0°C to +55°C
- Storage Temperature: -25°C to +70°C
- Humidity: 5–95% RH, non-condensing
- Communication Interface: Profibus DP / Ethernet (platform-dependent)
- Certifications: CE, UL (per ABB AC800M series standards)
- Weight: Approx. 260 g
- Country of Origin: Germany / Sweden (ABB manufacturing)
Proven Application Environments
- Power plant DCS control loops (boiler, turbine, BOP systems)
- Oil & gas upstream/downstream process control
- Pulp & paper mill automation (digester, recovery boiler)
- Chemical and petrochemical batch/continuous process control
- Water treatment and municipal utility SCADA integration
- Marine and offshore platform control systems
Engineering Advantages
- Drop-in Replacement: Direct hardware compatibility with existing AC800M racks — no firmware re-flashing required in most configurations
- High MTBF: ABB industrial-grade components rated for continuous 24/7 operation in harsh environments
- Redundancy Support: Compatible with AC800M hot-standby redundancy configurations
- Deterministic Execution: Real-time OS ensures cycle-accurate process control with sub-millisecond response
- Scalable I/O: Supports expansion via S800 I/O modules and CI840/CI854 communication interfaces
System Architecture & Signal Flow
Within the AC800M architecture, the UNS0882A-PV1 control board sits at the controller layer, interfacing upward to the operator station (OPC/OPC-UA) and downward to field I/O via the S800 I/O bus or Profibus DP fieldbus. The board executes IEC 61131-3 compliant control programs compiled in ABB’s Control Builder M engineering tool. Signal flow: Field sensors → S800 I/O → Backplane bus → UNS0882A-PV1 processor → Control output → Actuators/drives.
Sourcing & Quality Verification
- Source: Authorized surplus, OEM-decommissioned, and certified refurbished channels
- Inspection: Each unit undergoes visual inspection, board-level continuity check, and functional power-on test prior to shipment
- Packaging: ESD-safe anti-static bag + foam-lined carton with desiccant
- Documentation: Certificate of conformity, test report, and traceability record available on request
- Warranty: 12-month replacement warranty against manufacturing defects
Procurement Process
- Submit RFQ via support@konmask.com or add to cart directly
- Receive proforma invoice with lead time confirmation (typically 1–3 business days)
- Payment via T/T, PayPal, or trade assurance
- Shipment via DHL / FedEx / UPS with full tracking; export documentation (commercial invoice, packing list, COO) included
- Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: Is the 3BHB006309R0001 compatible with AC800M PM865 controllers?
A: Compatibility depends on the specific AC800M chassis generation. Please provide your existing controller part number for cross-reference confirmation.
Q: Can this board be used in a redundant controller pair?
A: Yes, the UNS0882A-PV1 supports AC800M redundancy configurations when paired with the appropriate redundancy module and cabling.
Q: What firmware version is pre-loaded?
A: Firmware version varies by unit. We recommend using ABB Control Builder M to verify and update firmware to match your system baseline after installation.
Q: Do you provide an exchange/core return program?
A: Yes. Contact us for exchange pricing if you have a faulty unit to return as core credit.
