ABB 3BHE022293R0101 PCD232 A106 Controller Module | Replacement, Equivalent & Selection Guide
The ABB 3BHE022293R0101 is a PCD232 A106 Controller Module designed for ABB’s AC800M / Symphony Plus DCS platform. This page provides full technical specifications, compatible replacement options, selection guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Part Number: 3BHE022293R0101
- Series: PCD232 A106
- Manufacturer: ABB
- Module Type: Controller Module
- Platform Compatibility: ABB AC800M / Symphony Plus DCS
- Form Factor: Rack-mount module
- Weight: 247 g
- Operating Temperature: 0°C to +55°C (typical ABB DCS range)
- Communication: Supports ABB proprietary backplane bus
- Certifications: CE, UL (verify with datasheet for exact revision)
Compatible Replacement & Equivalent Models
When the original ABB 3BHE022293R0101 is unavailable or end-of-life, the following models may serve as functional equivalents or drop-in replacements. Always verify firmware revision and hardware compatibility before substitution.
- ABB 3BHE022293R0102 – Revised hardware revision of the same PCD232 series; confirm backplane slot compatibility
- ABB 3BHE017627R0101 – Earlier PCD232 generation; may require firmware alignment
- ABB PM866K01 (3BSE050198R1) – AC800M controller; different form factor but overlapping control functions in some topologies
- ABB PM864A (3BSE018161R1) – Widely deployed AC800M controller; evaluate I/O mapping before substitution
- Third-party compatible modules – Contact Konmask.com for vetted cross-reference options with warranty
Note: All replacement decisions should be validated by a qualified automation engineer. Konmask.com provides pre-sales technical consultation at no charge.
Why Choose the Original Model
- Guaranteed compatibility with existing ABB AC800M / Symphony Plus configurations
- No firmware re-flashing required – plug-and-play replacement in same-revision systems
- ABB-certified hardware with traceable manufacturing batch records
- Longer MTBF compared to generic equivalents in continuous-process environments
- Full ABB technical support and spare-parts ecosystem availability
Typical Applications
- Power generation plant DCS control loops
- Oil & gas upstream/downstream process automation
- Chemical and petrochemical plant control systems
- Pulp & paper mill automation
- Water treatment and utility SCADA integration
- Marine and offshore platform control systems
System Compatibility
- ABB Symphony Plus (S+ Operations, S+ Engineering)
- ABB AC800M controller family (PM860, PM861, PM864, PM866 series)
- ABB Advant OCS (with appropriate gateway configuration)
- ABB 800xA System (as a field controller node)
- Backplane: Compatible with ABB TB820 / TB840 series terminal bases
Selection Guide
Use the following criteria to confirm 3BHE022293R0101 is the right module for your application:
- Step 1 – Identify your DCS platform: Confirm your system is ABB AC800M or Symphony Plus. If running Advant or older MOD 300, a gateway or different module family is required.
- Step 2 – Check hardware revision: Match the R0101 suffix to your existing installed base. Mixing R0101 and R0102 in the same rack may require firmware alignment.
- Step 3 – Verify slot count & I/O budget: Confirm available controller slots and I/O module count against your process requirements.
- Step 4 – Assess redundancy needs: For hot-standby redundancy, a paired controller module and appropriate redundancy cable are required.
- Step 5 – Contact Konmask for cross-reference: If you need a replacement and the original is unavailable, our engineers will provide a validated equivalent recommendation.
Quality Assurance & Sourcing
- All modules sourced from authorized distributors or verified surplus channels
- Each unit undergoes visual inspection, functional bench test, and ESD-safe packaging before shipment
- Batch traceability records available upon request
- Warranty: 12 months from date of shipment (DOA replacement within 30 days)
- Export compliance: ECCN classification and export license assessment available for international orders
How to Order
- Online: Add to cart directly on this page – stock status shown in real time
- Email RFQ: support@konmask.com – include quantity, required delivery date, and destination country
- Phone / WhatsApp: +0086 19859288691
- Lead time: In-stock orders ship within 1–3 business days; sourced orders 7–21 business days
- Payment: T/T wire transfer, PayPal, credit card (via Shopify Payments)
Replacement & Compatibility FAQ
Q: Can I use 3BHE022293R0102 as a direct replacement for 3BHE022293R0101?
A: In most cases yes, but verify the firmware version running on your AC800M controller. ABB recommends matching hardware revisions within the same redundant pair.
Q: Is this module compatible with ABB 800xA version 5.x and 6.x?
A: Yes, the PCD232 A106 is supported under 800xA 5.1 SP2 and later. Confirm with your 800xA system release notes for exact compatibility matrix.
Q: Do you supply tested/refurbished units?
A: Yes. All refurbished units are clearly labeled and priced separately. New surplus and factory-new options are also available. Contact us for current stock.
Q: Can Konmask.com provide a certificate of conformance (CoC)?
A: Yes, CoC and test reports are available for all units upon request at no additional charge.
Q: What is the lead time for out-of-stock units?
A: Typically 7–21 business days depending on global supply. We maintain relationships with multiple ABB-authorized channels to minimize lead time.
