ABB 3BHE026284R0105 UAD215 A105 Converter | ACS1000 / ACS6000 Drive Platform
Engineering Background
The ABB UAD215 A105 (part number 3BHE026284R0105) is a precision converter board designed for ABB’s high-power medium-voltage drive platforms — primarily the ACS1000 and ACS6000 series. These drives are the backbone of demanding industrial processes where motor control accuracy, uptime, and harmonic performance are non-negotiable. The UAD215 A105 sits at the heart of the drive’s signal conditioning and conversion architecture, translating analog and digital process signals into actionable control commands for the drive’s main processor.
Product Positioning
Targeted at maintenance engineers, OEM integrators, and procurement specialists managing ABB medium-voltage drive fleets, this module is a direct OEM-equivalent replacement. Konmask.com sources this component through verified industrial channels, ensuring traceability and functional integrity for critical plant environments.
Complete Technical Specifications
- Manufacturer: ABB
- Part Number: 3BHE026284R0105
- Module Designation: UAD215 A105
- Module Type: Converter / Signal Conditioning Board
- Compatible Platforms: ABB ACS1000, ACS6000 Medium-Voltage Drive Series
- Form Factor: PCB module, rack/drive-bay mountable
- Weight: 840 g (approx.)
- Operating Environment: Industrial control cabinet, climate-controlled enclosure
- Communication Interface: Internal drive backplane / proprietary ABB bus
- Condition: New / Refurbished-to-OEM-spec (specify at inquiry)
- Warranty: 12 months from shipment date
- Country of Origin: Switzerland / EU (ABB OEM)
Proven Application Environments
- Oil & Gas — compressor and pump drive systems requiring continuous duty
- Mining & Minerals — conveyor and hoist drive control in harsh environments
- Power Generation — auxiliary drive systems in thermal and hydro plants
- Marine & Offshore — propulsion and thruster drive control
- Pulp & Paper — high-torque refiner and winder drive applications
- Water & Wastewater — large pump station variable-speed drive control
- Steel & Metals — rolling mill and furnace drive systems
Engineering Advantages
- OEM Part Number Traceability: Full ABB part number 3BHE026284R0105 ensures exact BOM match — no cross-reference ambiguity.
- Drop-in Replacement: Designed to slot directly into existing ACS1000/ACS6000 drive cabinets without firmware or hardware modification.
- Signal Integrity: UAD215 A105 maintains high-fidelity analog-to-digital conversion critical for closed-loop motor control accuracy.
- Reduced Downtime Risk: Stocked and ready to ship — minimizes mean time to repair (MTTR) for unplanned drive failures.
- Thermal Robustness: Engineered for continuous operation within ABB’s industrial thermal envelope.
- Compliance: Meets CE and applicable IEC standards as part of the ABB ACS drive platform.
System Architecture & Signal Flow
Within the ACS1000/ACS6000 drive architecture, the UAD215 A105 converter board interfaces between the drive’s analog I/O field signals and the main control processor (typically the APBU or RDCU control unit). Signal flow is as follows:
- Input: Analog process signals (speed reference, current feedback, temperature sensors) from field instrumentation
- Conversion: UAD215 A105 performs A/D conversion and signal conditioning, normalizing inputs to the drive’s internal data bus format
- Output: Conditioned digital signals forwarded to the main drive processor for closed-loop PID and vector control execution
- Feedback Path: Processed control outputs are returned via the same board for analog output to field actuators where applicable
This architecture ensures deterministic signal latency and high noise immunity — essential for stable operation of medium-voltage motors in process-critical applications.
Sourcing & Quality Verification
- Source: Procured from authorized ABB distributors and verified industrial surplus channels
- Inspection: Each unit undergoes visual inspection, board-level continuity check, and functional verification prior to dispatch
- Packaging: Anti-static ESD packaging with foam cushioning; outer carton rated for international freight
- Documentation: Certificate of conformity and test report available upon request
- Traceability: Serial number and date code recorded at dispatch for full supply chain traceability
Procurement Process
- Inquiry: Submit your RFQ via support@konmask.com or WhatsApp +0086 19859288691 with your required quantity and delivery timeline.
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options.
- Order Confirmation: Place order via Konmask.com checkout or proforma invoice for bank transfer (T/T).
- Quality Check & Dispatch: Unit inspected, documented, and dispatched within 2–5 business days via DHL / FedEx / SF Express.
- After-Sales Support: 12-month warranty with technical support from our engineering team.
Technical FAQ
Q: Is 3BHE026284R0105 compatible with both ACS1000 and ACS6000?
A: Yes. The UAD215 A105 is used across both platforms. Always verify your drive’s existing board revision against the part number before ordering — contact us if unsure.
Q: Can this board be used with third-party drives?
A: No. This is an ABB-proprietary module designed exclusively for ABB ACS-series medium-voltage drives. It is not compatible with Siemens, Schneider, or other OEM drive platforms.
Q: What is the lead time for stock items?
A: In-stock units ship within 2–5 business days. For out-of-stock items, typical lead time is 2–4 weeks depending on sourcing channel.
Q: Do you provide a test report?
A: Yes. A functional test report and certificate of conformity are available upon request at no additional charge.
Q: Can you supply multiple units for a fleet maintenance program?
A: Yes. Volume pricing is available for orders of 3+ units. Contact us for a tailored quotation.
