ABB 3HNA023200-001 – Robot Controller LCD Display Screen | IRB 8700 / IRB 6700 Platform
Engineering Background
The ABB IRB 8700 and IRB 6700 series represent ABB Robotics’ flagship heavy-payload and versatile industrial robot platforms, widely deployed in automotive body-in-white, foundry, press tending, and general material handling applications. The operator interface—specifically the teach pendant and controller HMI display—is mission-critical for programming, diagnostics, and real-time status monitoring. Part number 3HNA023200-001 is the OEM-specified LCD screen assembly for these platforms, cross-referenced under IRB87003HAC043073-003 (IRB 8700 variant) and IRB67003HAC055699-003 (IRB 6700 variant).
Product Positioning
Konmask.com supplies this display as a direct OEM-equivalent replacement for maintenance engineers and system integrators requiring a verified, traceable spare. Each unit is sourced through authorized distribution channels and undergoes incoming inspection before dispatch. This is not an aftermarket substitute—it is the same assembly specified in ABB’s spare parts catalog.
Complete Technical Specifications
- Part Number (Primary): 3HNA023200-001
- Cross-Reference 1: IRB87003HAC043073-003 (IRB 8700 series)
- Cross-Reference 2: IRB67003HAC055699-003 (IRB 6700 series)
- Manufacturer: ABB Robotics (ABB Ltd.)
- Component Type: LCD Screen / HMI Display Assembly
- Compatible Platforms: ABB IRB 8700, ABB IRB 6700
- Controller Compatibility: IRC5 / OmniCore (verify with ABB BOM revision)
- Interface: Integrated teach pendant / FlexPendant display module
- Operating Temperature: 0 °C to +50 °C (storage: −25 °C to +70 °C)
- Ingress Protection: Per ABB FlexPendant IP rating (IP54 class enclosure)
- Weight (unit): Approx. 500 g
- Country of Origin: CN
- Condition: New / OEM-equivalent
Proven Application Environments
- Automotive body-in-white welding and assembly lines
- Foundry and die-casting robot cells (high-temperature periphery)
- Press tending and stamping automation
- Heavy-payload palletizing and material handling
- General industrial robot maintenance and spare-parts inventory programs
- OEM machine builders integrating ABB IRB 8700 / IRB 6700 into turnkey systems
Engineering Advantages
- OEM Part Number Traceability: Ships with full part number documentation; no ambiguity in BOM reconciliation.
- Dual Cross-Reference Coverage: Single SKU satisfies both IRB 8700 and IRB 6700 display requirements, simplifying spare-parts inventory.
- Drop-In Replacement: No firmware modification or mechanical adaptation required; plug-and-play with existing FlexPendant harness.
- Reduced Downtime Risk: Stocking this unit eliminates lead-time exposure on a single-source OEM component.
- Verified Supply Chain: Sourced through traceable channels; each unit inspected for cosmetic and functional integrity prior to shipment.
System Architecture & Signal Flow
The 3HNA023200-001 LCD assembly integrates directly into the ABB FlexPendant teach pendant housing. The display receives video and touch-input signals via the pendant’s internal ribbon/connector interface, communicating with the IRC5 or OmniCore main computer over the pendant cable (DeviceNet / proprietary ABB protocol). The screen renders the RobotWare HMI, providing the operator with real-time axis position data, program execution status, I/O monitoring, and alarm management. Replacement of this unit restores full graphical operator interface functionality without requiring controller reconfiguration.
Sourcing & Quality Verification
- All units sourced from authorized or verified secondary-market channels with documented provenance.
- Incoming inspection covers: physical integrity, connector condition, screen surface, and part number label verification.
- Packaging: anti-static bag + foam-lined carton; suitable for international air and sea freight.
- Certificate of conformity available upon request for regulated industries.
- Batch traceability records maintained for 3 years.
Procurement Process
- Confirm compatibility: verify your robot serial number and controller revision against ABB spare parts catalog (3HNA023200-001 / IRB87003HAC043073-003 / IRB67003HAC055699-003).
- Submit inquiry or place order directly via Konmask.com product page.
- Receive order confirmation with estimated lead time (typically 3–7 business days for in-stock units).
- Unit dispatched with packing list, part number documentation, and tracking information.
- Post-delivery technical support available via support@konmask.com or +0086 19859288691.
Technical FAQ
Q: Is 3HNA023200-001 compatible with both IRB 8700 and IRB 6700?
A: Yes. This part number is cross-referenced as IRB87003HAC043073-003 for the IRB 8700 and IRB67003HAC055699-003 for the IRB 6700. Verify your specific robot BOM revision with ABB documentation before ordering.
Q: Does this display require any firmware update after installation?
A: No firmware update is required for a like-for-like replacement. The FlexPendant loads its interface from the IRC5/OmniCore controller. Consult ABB service documentation if upgrading between major RobotWare versions.
Q: What is the warranty on this unit?
A: Konmask.com provides a 90-day warranty against manufacturing defects and DOA (dead-on-arrival) units. Contact support@konmask.com within 7 days of receipt for any claims.
Q: Can you provide a datasheet or ABB spare parts catalog extract?
A: Yes. Contact support@konmask.com with your order reference and we will provide available technical documentation.
Q: What are the lead times for bulk orders?
A: Lead times for quantities >5 units are quoted individually. Contact us for volume pricing and availability.
