ABB AI845-EA 3BSE023675R2 Analog Input Module – S800 I/O Series
When an analog input module fails mid-process in a refinery, a power plant, or a chemical reactor, the consequences are immediate and severe: operators lose real-time visibility into critical process variables — temperature, pressure, flow, and level — forcing an unplanned shutdown that can cost tens of thousands of dollars per hour. The ABB AI845-EA is the precision interface that stands between your process and that scenario, converting field-level analog signals into reliable digital data that your AC 800M controller can act on with confidence.
Within ABB’s S800 I/O ecosystem, the AI845-EA occupies a high-value position as an extended-accuracy, HART-capable analog input module. Designed to integrate seamlessly with the AC 800M Distributed Control System — one of the most widely deployed DCS platforms in global process industries — this module is trusted by automation engineers across oil & gas, pulp & paper, power generation, and specialty chemicals. Its combination of channel density, signal fidelity, and HART pass-through capability makes it a benchmark component in modern process automation architectures.
Technical Specifications
- Part Number: AI845-EA
- Catalog Number: 3BSE023675R2
- Brand: ABB
- Series: S800 I/O
- Compatible Controller: AC 800M DCS
- Module Type: Analog Input
- Signal Type: 4–20 mA with HART communication
- Number of Channels: 8 (single-ended)
- Accuracy Class: Extended accuracy (EA)
- Isolation: Channel-to-bus isolation
- Weight: 340 g
- Mounting: S800 I/O ModuleBus carrier
Note: All specifications are sourced from ABB official documentation. Konmask.com does not fabricate or alter manufacturer data.
Key Features & Benefits
- Extended Accuracy (EA): Higher measurement precision compared to standard AI845, critical for tight process control loops where signal drift causes product quality deviations.
- HART Pass-Through: Enables simultaneous 4–20 mA process data and HART digital communication, allowing remote device diagnostics and configuration without interrupting the process.
- 8-Channel Density: Maximizes cabinet space efficiency — fewer modules, fewer carriers, lower wiring cost per I/O point.
- Hot-Swap Capable: Modules can be replaced under power on the S800 carrier, minimizing maintenance downtime in live production environments.
- Integrated Diagnostics: Self-monitoring with fault reporting to the AC 800M controller, enabling predictive maintenance strategies.
- Galvanic Isolation: Protects the controller backplane from field-side ground loops and transient surges common in industrial environments.
Industry & Equipment Applications
- Oil & Gas: Pipeline pressure monitoring, separator level control, wellhead instrumentation loops
- Power Generation: Boiler drum level, turbine inlet temperature, feedwater flow measurement
- Chemical & Petrochemical: Reactor temperature profiling, distillation column pressure, feed rate control
- Pulp & Paper: Digester pressure, bleach plant flow, recovery boiler instrumentation
- Water & Wastewater: Pump station flow metering, tank level monitoring, dosing control
- Pharmaceuticals: Clean-room environmental monitoring, bioreactor parameter acquisition
System Integration & Compatible Parts
The AI845-EA is designed for plug-and-play integration within the ABB AC 800M / S800 I/O architecture. Commonly paired components include:
- ModuleBus Carriers: TB820V2, TB840A — provide the physical mounting and communication bus for S800 modules
- AC 800M Controllers: PM861, PM864, PM866 — the host controllers that process AI845-EA data
- Power Supply Units: SD821, SD822 — dedicated S800 I/O power supplies
- Redundancy Modules: For high-availability configurations in SIL-rated applications
- HART Multiplexers: Compatible with third-party HART infrastructure for asset management integration
Contact our technical team to verify compatibility with your specific AC 800M firmware version and system configuration.
