Profibus DP Communication Solution – ABB CI810V1 3BSE008584R1 | AC800M Series
Where This Product Is Used
The ABB CI810V1 (catalog no. 3BSE008584R1) is a Profibus DP master/slave communication interface module designed for integration within ABB’s AC800M Distributed Control System (DCS) platform. It is deployed across a wide range of demanding industrial environments:
- Oil & Gas Processing Plants – Connects field instruments, valve positioners, and remote I/O over Profibus DP segments in upstream/downstream facilities.
- Chemical & Petrochemical Plants – Enables deterministic, high-speed communication between the AC800M controller and Profibus-enabled field devices in hazardous areas.
- Pulp & Paper Mills – Integrates drives, actuators, and sensors on a single Profibus network, reducing wiring complexity and improving diagnostics.
- Power Generation & Utilities – Used in turbine control, boiler management, and substation automation where reliable fieldbus communication is critical.
- Water & Wastewater Treatment – Connects distributed pump stations and instrumentation to a central AC800M controller via Profibus DP.
- Mining & Minerals Processing – Supports robust communication in high-vibration, electrically noisy environments typical of mineral processing facilities.
Technical Specifications
- Part Number: CI810V1
- Catalog / Order Number: 3BSE008584R1
- Manufacturer: ABB
- Series: AC800M / Freelance DCS
- Module Type: Profibus DP Communication Interface
- Fieldbus Protocol: Profibus DP (EN 50170 / IEC 61158)
- Profibus Role: DP Master (Class 1 & Class 2)
- Max. Profibus Slaves: Up to 125 slave devices per segment
- Baud Rate: 9.6 kbps – 12 Mbps (auto-negotiated)
- Backplane Interface: AC800M CPU module backplane bus
- Connector: 9-pin D-Sub (DB9) female, RS-485
- Power Supply: Supplied via AC800M backplane (no external power required)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: –40 °C to +70 °C
- Humidity: 5% – 95% RH, non-condensing
- Weight: Approx. 480 g
- Dimensions: Standard AC800M module form factor
- Certifications: CE, UL, cUL, ATEX (zone 2 when installed in approved enclosure)
Why Engineers Specify This Model
- Native AC800M Integration: Plugs directly into the AC800M backplane — no external gateway or converter required, minimizing latency and single points of failure.
- Proven Fieldbus Reliability: Profibus DP is a battle-tested protocol with decades of deployment in process industries; CI810V1 inherits this reliability.
- High Device Density: Supports up to 125 slave devices per segment, enabling large-scale I/O architectures without additional hardware.
- Diagnostic Transparency: Provides live slave diagnostics accessible through ABB’s Control Builder engineering tool, reducing MTTR during fault conditions.
- Backward Compatibility: Compatible with existing Profibus DP field device installations, protecting prior capital investment when upgrading controllers.
- Redundancy Support: Can be configured in redundant pairs with appropriate AC800M CPU configurations for high-availability applications.
Complete System Bill of Materials
For a complete AC800M Profibus DP control node, engineers typically specify the following alongside the CI810V1:
- ABB PM861A / PM864A / PM866A – AC800M CPU Module
- ABB TB807 / TB811 – Termination Board for I/O modules
- ABB SD821 / SD822 – 24 VDC Power Supply Module
- ABB TP830 – Profibus DP Termination Plug (bus terminator)
- Profibus DP cable (shielded, twisted pair, Type A per EN 50170)
- ABB Control Builder M – Engineering & Configuration Software
- Profibus DP field devices (drives, valve positioners, remote I/O, transmitters)
Compliance & Industry Standards
- Profibus DP: EN 50170 / IEC 61158 / IEC 61784
- EMC Directive: 2014/30/EU (CE marked)
- Low Voltage Directive: 2014/35/EU
- UL 508 / cUL – Industrial Control Equipment
- ATEX Directive 2014/34/EU – Zone 2 (with approved enclosure)
- RoHS Compliant: 2011/65/EU
- IEC 61131-2: Programmable Controllers – Equipment Requirements
Quality Assurance & Sourcing
Konmask.com sources ABB CI810V1 3BSE008584R1 modules through verified industrial automation supply channels. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, corrosion, and connector integrity
- Label and serial number verification against ABB factory records where applicable
- Functional power-on check
- Anti-static packaging with humidity indicator card
- Traceable documentation provided upon request (test reports, CoC)
We stock both new-in-box (NIB) and refurbished/tested units. Condition is clearly stated at time of quotation.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity and delivery timeline.
- Phone / WhatsApp: +0086 19859288691 — available for urgent inquiries and technical pre-sales support.
- Lead Time: In-stock units ship within 1–3 business days. Ex-stock availability confirmed at time of order.
- Global Shipping: DHL Express, FedEx International Priority, and sea freight options available. Export documentation (commercial invoice, packing list, CO) provided.
- Payment: T/T (bank transfer), PayPal, and trade credit terms available for qualified accounts.
Application-Specific FAQ
Q: Is the CI810V1 compatible with AC800M PM851 CPU modules?
A: Yes. The CI810V1 is compatible with all AC800M CPU variants including PM851, PM856, PM860, PM861, PM864, and PM866 series, subject to firmware version requirements. Consult ABB’s compatibility matrix or contact us for confirmation.
Q: Can CI810V1 operate as a Profibus DP slave?
A: The CI810V1 is primarily configured as a DP Master (Class 1). Slave functionality depends on the firmware version and Control Builder M configuration. Contact ABB or our technical team for your specific use case.
Q: What is the maximum cable length for Profibus DP at 12 Mbps?
A: At 12 Mbps, the maximum segment length is 100 m (Type A cable). At lower baud rates (e.g., 93.75 kbps), segments can extend up to 1,200 m. Repeaters can extend total network reach.
Q: Do you provide a warranty on CI810V1 modules?
A: Yes. New-in-box units carry the original ABB warranty. Refurbished/tested units are covered by Konmask’s 90-day functional warranty. Extended warranty options are available upon request.
Q: Can this module be used in a SIL-rated safety application?
A: The CI810V1 is not a SIL-certified safety module. For safety-instrumented systems, ABB’s S800 I/O with dedicated safety CPUs (e.g., PM865A) should be specified. Contact us for SIL-compliant alternatives.
