ABB GJR2368900R234087TS01K-E – AC800M Controller Module | Freelance Automation Platform
Engineering Background
The ABB Freelance distributed control system (DCS) is a proven automation platform widely deployed in process industries including oil & gas, power generation, water treatment, and chemical manufacturing. The GJR2368900R234087TS01K-E is a core controller module within the AC800M hardware family, engineered to deliver deterministic real-time control with high availability and seamless integration into ABB’s 800xA and Freelance engineering environments.
Product Positioning
Designed for procurement engineers and system integrators who require a reliable, specification-verified replacement or expansion module for existing Freelance/AC800M installations. This module eliminates the need for full system redesign and is backward-compatible with established Freelance project configurations.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | GJR2368900R234087TS01K-E |
| Manufacturer | ABB |
| Product Family | AC800M / Freelance DCS |
| Module Type | Controller / CPU Module |
| Platform | ABB Freelance Automation Builder |
| Country of Origin | Germany |
| Weight | 400 g (approx.) |
| Communication | PROFIBUS DP / Industrial Ethernet (platform-dependent) |
| Programming Standard | IEC 61131-3 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
| Certifications | CE, UL (platform-level) |
Proven Application Environments
- Oil & Gas: Upstream/downstream process control, compressor management, SCADA integration
- Power Generation: Turbine control, boiler management, grid synchronization
- Water & Wastewater: Pump station automation, SCADA-linked remote I/O
- Chemical & Pharma: Batch process control, recipe management, FDA 21 CFR Part 11 environments
- Pulp & Paper: Continuous process lines, drive coordination
- Mining: Conveyor systems, crusher control, plant-wide DCS integration
Engineering Advantages
- Drop-in Replacement: Maintains hardware and firmware compatibility with existing Freelance/AC800M rack configurations — no re-engineering required
- Deterministic Execution: Real-time cyclic task execution ensures predictable control loop performance critical for process safety
- Redundancy Ready: Supports hot-standby controller redundancy configurations for high-availability applications
- Scalable I/O: Integrates with S800 I/O modules and third-party PROFIBUS/PROFINET devices
- Unified Engineering: Fully supported within ABB Automation Builder and 800xA engineering tools
- Long Service Life: ABB’s industrial-grade components rated for extended operational cycles in harsh environments
System Architecture & Signal Flow
The GJR2368900R234087TS01K-E mounts directly into the AC800M controller rack. It communicates with local S800 I/O modules via the internal ModuleBus backplane and connects to supervisory systems (800xA DCS, SCADA, HMI) via Industrial Ethernet or PROFIBUS DP. The module executes IEC 61131-3 control programs compiled in ABB Automation Builder, with cyclic task scheduling managed by the onboard real-time OS. Redundant power feeds and watchdog circuits ensure fail-safe operation.
Sourcing & Quality Verification
- Authentic Hardware: All units sourced from authorized distribution channels or verified industrial surplus with full traceability
- Pre-shipment Inspection: Visual inspection, label verification, and functional check performed before dispatch
- Packaging: ESD-safe anti-static packaging with moisture barrier; original ABB packaging preserved where available
- Documentation: Certificate of conformity and test report available upon request
- Warranty: 12-month operational warranty against manufacturing defects
Procurement Process
- Inquiry: Submit your RFQ with required quantity and delivery timeline via support@konmask.com or +0086 19859288691
- Quotation: Receive a formal quotation with lead time, pricing, and availability confirmation within 24 hours
- Order Confirmation: Purchase order accepted; payment terms discussed (T/T, L/C, or platform checkout)
- Quality Check: Pre-shipment inspection completed and documentation prepared
- Shipping: DHL / FedEx / UPS express or sea freight; tracking number provided within 48 hours of dispatch
- After-sales: Technical support available for installation, commissioning, and warranty claims
Technical FAQ
Q: Is this module compatible with ABB 800xA DCS?
A: Yes. The AC800M hardware family is the controller platform for both Freelance and 800xA systems. Confirm firmware version compatibility with your system integrator before installation.
Q: Can this replace an existing GJR2368900R234087TS01K-E in a live system?
A: Yes, as a direct part-number match it is a drop-in replacement. Follow ABB’s hot-swap or cold-swap procedure per your system’s redundancy configuration.
Q: What programming software is required?
A: ABB Automation Builder (for Freelance) or ABB 800xA Engineering Workplace. IEC 61131-3 function block, ladder, and structured text languages are supported.
Q: Do you provide a test report?
A: Yes. A pre-shipment functional test report is available upon request at no additional charge.
Q: What is the lead time?
A: In-stock units ship within 3–5 business days. For sourced units, typical lead time is 7–15 business days depending on origin.
