ABB CMA135 (3DDE300415) – Diesel Engine Start/Stop Automatic Control Module | UNITROL Series
Engineering Background
The ABB CMA135, part number 3DDE300415, is a dedicated automatic control module engineered for diesel engine start/stop sequencing within ABB’s UNITROL excitation and generator control platform. Designed to meet the rigorous demands of power generation, marine propulsion, and industrial standby systems, this module provides deterministic control logic for engine cranking, run confirmation, and safe shutdown sequences — eliminating manual intervention and reducing operator error in critical power infrastructure.
Product Positioning
The CMA135 3DDE300415 is the OEM-specified solution for integrating diesel prime movers into ABB UNITROL-based automatic voltage regulator (AVR) and generator management systems. It is the preferred choice for procurement engineers specifying replacement or expansion modules in existing ABB installations, where form-fit-function compatibility is non-negotiable.
Complete Technical Specifications
| Manufacturer | ABB (ASEA Brown Boveri) |
| Part Number / SKU | CMA135 / 3DDE300415 |
| Module Type | Diesel Start/Stop Automatic Control Module |
| Platform / Series | UNITROL Excitation & Generator Control System |
| Function | Automatic engine start/stop sequencing, crank control, run confirmation, shutdown logic |
| Form Factor | Plug-in PCB module (DIN rail / rack mount compatible) |
| Operating Voltage | 24 VDC (nominal, system bus powered) |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Weight | 1,260 g (approx.) |
| Country of Origin | Sweden |
| Compliance | CE, IEC 60068, IEC 61131 |
| Warranty | 12 months (Konmask verified) |
Proven Application Environments
- Power Generation: Diesel genset automatic start/stop in standby and peak-shaving applications
- Marine & Offshore: Engine management integration in vessel power management systems (PMS)
- Oil & Gas: Emergency diesel generator (EDG) control in upstream and downstream facilities
- Data Centers & Critical Infrastructure: UPS bypass and generator auto-transfer sequencing
- Industrial Plants: Compressor and pump drive diesel engine automation
- Utilities & Substations: Backup power system integration with SCADA/DCS
Engineering Advantages
- OEM Form-Fit-Function: Direct plug-in replacement for existing ABB UNITROL installations — no rewiring or reconfiguration required
- Deterministic Sequencing Logic: Hardened start/stop timing eliminates race conditions and false starts in multi-engine configurations
- Fail-Safe Architecture: Integrated watchdog and self-diagnostic routines ensure safe shutdown on fault detection
- Low Integration Risk: Factory-calibrated and tested; compatible with ABB UNITROL 1000, 5000, and 6000 series AVR platforms
- Long Service Life: Industrial-grade components rated for continuous duty in harsh electrical environments
System Architecture & Signal Flow
The CMA135 module interfaces directly with the UNITROL system backplane, receiving start/stop commands from the AVR supervisory controller. Upon a valid start command, the module executes a configurable pre-lube delay, initiates the crank output, monitors the engine speed feedback signal for run confirmation, and releases the crank circuit upon successful start. On shutdown, the module manages cooldown timers and actuates the fuel solenoid stop output in the correct sequence. All I/O signals are optically isolated to protect the control system from diesel engine electrical noise.
