PROFIBUS DP Fieldbus Solution – ABB FI830F 3BDH000032R1 | AC800M Series
Where This Product Is Used
The ABB FI830F (Part No. 3BDH000032R1) is a PROFIBUS DP fieldbus interface module engineered for the ABB AC800M Distributed Control System (DCS) platform. It is deployed across a wide range of industrial environments where deterministic, high-speed field device communication is critical:
- Oil & Gas Processing Plants – Integrates PROFIBUS DP field instruments (transmitters, valve positioners, motor starters) into the AC800M controller backbone for real-time process control.
- Chemical & Petrochemical Facilities – Enables safe, reliable communication between the DCS and hazardous-area field devices in compliance with IEC 61158.
- Power Generation & Utilities – Connects distributed I/O stations, drives, and protection relays to the AC800M in turbine control and boiler management systems.
- Pulp & Paper Mills – Supports high-node-count PROFIBUS segments for coordinating drives, actuators, and sensors across large production lines.
- Water & Wastewater Treatment – Provides robust fieldbus connectivity for pump stations, flow meters, and analyzers in demanding outdoor environments.
- Pharmaceutical & Food Manufacturing – Facilitates GMP-compliant process automation with deterministic scan cycles required for batch control.
Technical Specifications
| Part Number | FI830F / 3BDH000032R1 |
| Manufacturer | ABB |
| Product Series | AC800M / Freelance DCS |
| Module Type | PROFIBUS DP Fieldbus Interface Module |
| Fieldbus Protocol | PROFIBUS DP (IEC 61158 / EN 50170) |
| Communication Speed | Up to 12 Mbit/s |
| Max. DP Slaves per Segment | Up to 125 slave devices |
| Redundancy Support | Yes (with redundant fieldbus configuration) |
| Power Supply | Supplied via AC800M controller backplane |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Weight | Approx. 1,000 g (module + housing) |
| Mounting | AC800M controller rack / S800 I/O station |
| Certifications | CE, UL, cUL, ATEX (zone 2 when installed per ABB guidelines) |
Why Engineers Specify This Model
- Native AC800M Integration – The FI830F plugs directly into the AC800M controller rack, eliminating external gateways and reducing latency to sub-millisecond cycle times.
- High Node Density – Supports up to 125 PROFIBUS DP slaves per segment, making it ideal for large-scale process plants with hundreds of field devices.
- Redundant Architecture Ready – Supports dual-redundant fieldbus ring topologies, ensuring zero-downtime operation in safety-critical processes.
- Proven Reliability – ABB’s AC800M platform has an installed base of over 10,000 systems globally; the FI830F is a field-proven component with a long service life.
- Simplified Engineering – Fully configurable via ABB Control Builder M, with automatic GSD file import for rapid slave commissioning.
- Wide Environmental Tolerance – Rated for continuous operation in harsh industrial environments including high humidity, vibration, and EMI-rich settings.
Complete System Bill of Materials
For a complete AC800M PROFIBUS DP fieldbus segment, engineers typically specify the following alongside the FI830F:
- ABB PM866 / PM891 – AC800M Process Controller CPU
- ABB TB820V2 – PROFIBUS DP Termination Board
- ABB S800 I/O Modules (AI810, AO810, DI810, DO810) – Distributed I/O
- ABB CI854 – PROFIBUS DP Communication Interface (for S800 I/O stations)
- PROFIBUS DP Cable (Type A, shielded, 150 Ω) – Segment wiring
- PROFIBUS Bus Terminator Plugs – Segment end termination
- ABB Control Builder M – Engineering & configuration software
Compliance & Industry Standards
- IEC 61158 – Fieldbus standard for industrial communication networks
- EN 50170 – PROFIBUS general purpose field communication system
- IEC 61131-3 – Programmable controllers: programming languages
- IEC 61511 – Functional safety for the process industry (SIL-capable system)
- CE Marking – European conformity for EMC and Low Voltage Directive
- UL / cUL Listed – North American safety certification
- RoHS Compliant – Restriction of hazardous substances
Quality Assurance & Sourcing
At Konmask.com, every ABB FI830F 3BDH000032R1 unit is subject to our multi-point verification process:
- Authenticity Verification – Each module is inspected against ABB’s original part markings, firmware labels, and serial number traceability.
- Functional Pre-Shipment Test – Modules are bench-tested for power-up integrity and communication port functionality before dispatch.
- Anti-Static Packaging – Shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceable Documentation – Certificate of conformity and test report available upon request.
- Warranty – 12-month warranty against manufacturing defects; replacement or full refund guaranteed.
How to Source This Part
The ABB FI830F (3BDH000032R1) is available for immediate inquiry. To place an order or request a quotation:
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Online: https://konmask.com
Lead time: In-stock units ship within 1–3 business days. Out-of-stock units sourced within 7–14 business days. DHL / FedEx / UPS express available worldwide.
Application-Specific FAQ
Q: Is the FI830F compatible with both AC800M and AC800F controllers?
A: The FI830F is primarily designed for the AC800M platform. For AC800F (Freelance), please verify the specific controller variant and firmware version with ABB documentation before ordering.
Q: Can the FI830F support PROFIBUS PA devices?
A: The FI830F is a PROFIBUS DP interface. To connect PROFIBUS PA field devices, a DP/PA coupler or link (e.g., ABB DP/PA Link) must be added to the segment.
Q: What is the maximum cable length per PROFIBUS DP segment?
A: At 1.5 Mbit/s, maximum segment length is 200 m; at 93.75 kbit/s, up to 1,200 m. Repeaters can extend total network reach.
Q: Does this module support hot-swap / online replacement?
A: Hot-swap capability depends on the AC800M controller configuration and redundancy mode. Consult ABB’s AC800M Hardware Manual (3BSE036351) for detailed procedures.
Q: Can Konmask.com provide the original ABB datasheet and GSD file?
A: Yes. Contact us at support@konmask.com and we will provide the official ABB datasheet, GSD file, and wiring diagrams at no charge.
