DCS Field Wiring Solution – ABB NFTP01 | AC800M Series
Where This Product Is Used
The ABB NFTP01 Field Termination Panel is engineered for industrial process control environments where reliable, organized I/O signal termination is critical. It is widely deployed in:
- Oil & Gas Plants – Connecting field instruments (transmitters, valves, RTDs) to ABB AC800M DCS controllers in upstream/downstream processing units.
- Chemical & Petrochemical Facilities – Providing a structured wiring interface for hazardous-area field devices routed through marshalling cabinets.
- Power Generation – Terminating analog and digital I/O signals from turbine control loops and boiler management systems.
- Pulp & Paper Mills – Organizing multi-loop process signals in high-density I/O marshalling panels.
- Water & Wastewater Treatment – Interfacing field sensors and actuators with centralized DCS control rooms.
- Pharmaceutical Manufacturing – Supporting GMP-compliant control architectures with clean, labeled signal termination points.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | NFTP01 |
| Manufacturer | ABB |
| Series | AC800M / Freelance DCS |
| Product Type | Field Termination Panel (FTP) |
| Function | I/O Signal Field Wiring Termination |
| Compatible Controllers | ABB AC800M, S800 I/O Modules |
| Weight | 860 g |
| Mounting | DIN Rail / Panel Mount |
| Application | Process Automation, DCS Marshalling |
| Condition | New / Surplus / Refurbished (specify on inquiry) |
Why Engineers Specify This Model
- Native ABB Compatibility – Designed specifically for the AC800M ecosystem, ensuring plug-and-play integration with S800 I/O modules without custom wiring adapters.
- Reduced Wiring Errors – Pre-labeled, structured terminal layout minimizes field wiring mistakes during commissioning and maintenance.
- High-Density Signal Management – Accommodates multiple I/O channels in a compact footprint, optimizing cabinet space in marshalling enclosures.
- Simplified Maintenance – Modular design allows individual channel isolation and replacement without disrupting adjacent loops.
- Long Service Life – Built to ABB’s industrial-grade standards for continuous operation in demanding process environments.
- Proven in Critical Infrastructure – Trusted by process engineers across energy, chemical, and utilities sectors globally.
Complete System Bill of Materials
For a complete AC800M DCS I/O termination system, engineers typically specify the following alongside the NFTP01:
- ABB AC800M Controller (PM860, PM861, PM864, PM866 series)
- ABB S800 I/O Modules (AI810, AO810, DI810, DO810, etc.)
- ABB TB820 / TB840 ModuleBus Modem
- ABB CI854 / CI858 PROFIBUS / FOUNDATION Fieldbus Interface
- Marshalling Cabinet with DIN Rail
- Shielded Instrumentation Cable (twisted pair, 0.5–1.5 mm²)
- Cable Glands and Ferules
Contact support@konmask.com for complete BOM assistance and compatible part sourcing.
Compliance & Industry Standards
- Designed and manufactured under ABB’s ISO 9001 certified quality management system.
- Compatible with IEC 61131-3 compliant control architectures.
- Suitable for integration in systems meeting IEC 61511 (Functional Safety / SIL) requirements when used within validated ABB AC800M configurations.
- CE Marked for European market compliance.
- RoHS compliant materials.
Quality Assurance & Sourcing
At Konmask.com, every ABB NFTP01 unit is:
- Authenticity Verified – Sourced from authorized ABB distributors or directly from ABB-certified supply chains.
- Inspection Tested – Visually inspected and functionally verified prior to shipment.
- Properly Packaged – Anti-static packaging with original or equivalent protective materials to prevent transit damage.
- Traceable – Batch and serial documentation available upon request for regulated industries.
How to Source This Part
- Add to Cart – Click “Add to Cart” for standard stock orders.
- Request a Quote – For bulk orders (>5 units), OEM pricing, or project-based procurement, email support@konmask.com.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock or special-order units: 5–15 business days depending on origin.
- Global Shipping – We ship worldwide via DHL, FedEx, and UPS with full export documentation.
- Payment – T/T Bank Transfer, PayPal, and major credit cards accepted.
Application-Specific FAQ
Q: Is the NFTP01 compatible with ABB Freelance DCS as well as AC800M?
A: The NFTP01 is primarily designed for the AC800M / S800 I/O platform. For Freelance DCS compatibility, please confirm your specific I/O module model with our technical team before ordering.
Q: Can the NFTP01 be used in SIL 2 safety loops?
A: The NFTP01 can be part of a SIL-rated system when used within a fully validated ABB AC800M Safety configuration. Consult your functional safety engineer and ABB documentation for SIL loop validation requirements.
Q: Do you supply the NFTP01 with a warranty?
A: Yes. All units sold through Konmask.com carry a minimum 90-day warranty against manufacturing defects. Extended warranty options are available — contact us for details.
Q: What is the difference between NFTP01 and other ABB FTP variants?
A: Different NFTP variants correspond to different I/O channel counts and module compatibility. The NFTP01 is the base configuration. Contact our team to confirm the correct variant for your specific S800 I/O module type.
Q: Can you provide the ABB datasheet or wiring diagram?
A: Yes. Technical documentation including datasheets and installation manuals is available upon request. Email support@konmask.com with your inquiry.
