ABB PM564-TP-ETH (1SAP121100R0071) CPU Module | Replacement, Equivalent & Selection Guide
The ABB PM564-TP-ETH (Order No. 1SAP121100R0071) is a high-performance CPU module from the AC500 programmable logic controller (PLC) series. Featuring an integrated touchscreen panel (TP) and onboard Ethernet (ETH) interface, it is engineered for demanding industrial automation applications requiring real-time control, HMI visualization, and seamless network connectivity — all in a single compact unit.
At Konmask.com, we specialize in sourcing, cross-referencing, and supplying ABB AC500 modules for OEM replacements, system upgrades, and new installations worldwide.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model / SKU | PM564-TP-ETH |
| Order Number | 1SAP121100R0071 |
| Series | ABB AC500 |
| Type | CPU Module with Touchscreen & Ethernet |
| Display | Integrated touchscreen panel (TP) |
| Communication | Onboard Ethernet (ETH), PROFIBUS, serial |
| Memory | Program memory expandable via SD card |
| I/O Expansion | Supports AC500 I/O expansion modules |
| Programming | IEC 61131-3 (Automation Builder / CoDeSys) |
| Power Supply | 24 V DC |
| Operating Temp. | 0 °C to +60 °C |
| Protection Rating | IP20 |
| Country of Origin | Germany |
| Weight | Approx. 4,460 g (with packaging) |
Compatible Replacement & Equivalent Models
If the PM564-TP-ETH is unavailable or you are evaluating alternatives, the following models offer compatible or equivalent functionality within the ABB AC500 family and from third-party manufacturers:
| Model | Brand | Key Difference | Compatibility |
|---|---|---|---|
| PM564-ETH (1SAP121000R0071) | ABB | No touchscreen panel | Direct AC500 replacement (no TP) |
| PM564-TP (1SAP121200R0071) | ABB | Touchscreen, no Ethernet | AC500 — add external ETH module |
| PM583-ETH (1SAP130300R0271) | ABB | Higher memory, more I/O | Upward-compatible AC500 upgrade |
| PM591-ETH (1SAP140100R0271) | ABB | Mid-range AC500-eCo | Cost-optimized alternative |
| CPU 1214C DC/DC/DC | Siemens S7-1200 | Different platform | Functional equivalent — requires reprogramming |
| CompactLogix 5370 L1 | Allen-Bradley | Different platform | Functional equivalent — requires reprogramming |
Note: Cross-platform replacements require engineering evaluation. Contact our team for migration support.
Why Choose the Original PM564-TP-ETH
- Integrated HMI + PLC: Eliminates the need for a separate operator panel, reducing panel space and wiring cost.
- Native Ethernet: Supports MODBUS TCP, EtherNet/IP, and ABB proprietary protocols out of the box.
- Proven AC500 Ecosystem: Seamlessly pairs with all AC500 I/O modules, communication modules, and power supplies.
- IEC 61131-3 Compliance: Programmed via ABB Automation Builder — compatible with existing AC500 project files.
- Industrial Robustness: Designed for 24/7 operation in harsh industrial environments.
Typical Applications
- Water & wastewater treatment plant automation
- Building management systems (BMS / HVAC control)
- Machine tool and packaging line control
- Energy management and power distribution monitoring
- Oil & gas process control panels
- Conveyor and material handling systems
- Renewable energy (wind / solar inverter control)
System Compatibility
The PM564-TP-ETH is designed to operate within the ABB AC500 PLC platform and is compatible with:
- AC500 I/O modules: DI, DO, AI, AO, mixed I/O (e.g., DC532, DA501, AI531)
- AC500 communication modules: CM572-DP (PROFIBUS), CM577-ETH (Ethernet)
- AC500 power supply modules: PS501-PROG, PS502
- ABB Automation Builder 2.x programming environment
- SD memory cards for program backup and data logging
Selection Guide
Use the table below to select the right AC500 CPU for your project requirements:
| Requirement | Recommended Model |
|---|---|
| Need integrated touchscreen + Ethernet | PM564-TP-ETH (this model) |
| Need Ethernet only, no HMI | PM564-ETH (1SAP121000R0071) |
| Need HMI only, no Ethernet | PM564-TP (1SAP121200R0071) |
| Need higher processing power | PM583-ETH or PM592-ETH |
| Cost-sensitive small application | PM591-ETH (AC500-eCo) |
| Safety application (SIL 2/3) | AC500-S Safety CPU (PM5xx-S) |
Not sure which model fits your system? Send us your existing PLC model number or project requirements — our engineers will recommend the best match.
Quality Assurance & Sourcing
- ✅ Genuine ABB product — sourced from authorized distributors and verified supply chains
- ✅ Inspection & testing — each unit undergoes functional verification before shipment
- ✅ Traceability — full documentation including order number, serial number, and country of origin
- ✅ Warranty — 12-month warranty against manufacturing defects
- ✅ Export compliance — proper customs documentation and HS code classification provided
How to Order
- Click Add to Cart or Contact Us for bulk / project pricing.
- Provide your delivery country for accurate shipping and duty estimation.
- For urgent requirements, email support@konmask.com with your PO or RFQ.
- Lead time: In-stock items ship within 1–3 business days; special orders within 7–14 days.
Replacement & Compatibility FAQ
Q: Can PM564-TP-ETH replace PM564-ETH directly?
A: Yes, the PM564-TP-ETH is a superset of PM564-ETH — it adds the touchscreen panel. No firmware changes are required; existing programs are fully compatible.
Q: Is PM564-TP-ETH compatible with older AC500 V2 I/O modules?
A: Yes, it supports both AC500 V2 and V3 I/O modules. Verify firmware version compatibility in ABB Automation Builder before deployment.
Q: Can I use a Siemens S7-1200 as a drop-in replacement?
A: No. While functionally equivalent in capability, the S7-1200 uses a different hardware platform and programming environment. Full reprogramming and I/O rewiring are required.
Q: What is the difference between PM564-TP-ETH and PM564-TP?
A: The PM564-TP-ETH includes an onboard Ethernet port; the PM564-TP does not. If Ethernet connectivity is required, the PM564-TP-ETH is the correct choice.
Q: Do you supply the SD memory card separately?
A: Yes. Compatible SD cards for AC500 program storage are available — contact us for part numbers and pricing.
