ABB PM866K01 (3BSE050198R1) – High-Performance Processor Unit | AC 800M DCS/PLC Platform
Engineering Background
The ABB PM866K01 is a central processing unit designed for ABB’s AC 800M controller platform — one of the most widely deployed distributed control system (DCS) architectures in process industries worldwide. Part number 3BSE050198R1 identifies the standard hardware revision used across power generation, oil & gas, chemical, and pulp & paper facilities.
Product Positioning
As the computational core of the AC 800M rack, the PM866K01 handles real-time process control, inter-module communication, and application program execution. It is the preferred upgrade path from PM864/PM865 series for facilities requiring expanded memory, faster scan cycles, and enhanced redundancy support. Procurement engineers specify this unit for both greenfield installations and brownfield controller upgrades.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | PM866K01 |
| ABB Order Code | 3BSE050198R1 |
| Platform | AC 800M (Advant Controller 800M) |
| Processor Type | 32-bit RISC CPU |
| Program Memory | 32 MB Flash |
| RAM | 64 MB SDRAM |
| Cycle Time | Minimum 1 ms (configurable) |
| Communication Ports | 2× Ethernet (10/100 Mbps), 1× RS-232 service port |
| Fieldbus Support | PROFIBUS DP, FOUNDATION Fieldbus H1, Modbus RTU/TCP (via CI modules) |
| Redundancy | Hot-standby CPU redundancy supported |
| Power Supply | 24 VDC (via backplane) |
| Power Consumption | ≤ 8 W typical |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Humidity | 5–95% RH, non-condensing |
| Protection Class | IP20 |
| Dimensions (H×W×D) | Approx. 233 × 40 × 230 mm (standard AC 800M module form factor) |
| Weight | ~980 g |
| Certifications | CE, UL, cUL, ATEX (Zone 2 with appropriate enclosure) |
| Firmware | Compatible with Control Builder M Professional |
| Country of Origin | Germany / Sweden (ABB manufacturing) |
Proven Application Environments
- Oil & Gas: Upstream wellhead control, midstream pipeline SCADA, downstream refinery DCS
- Power Generation: Turbine governor control, boiler management systems, substation automation
- Chemical & Petrochemical: Batch reactor sequencing, continuous process control loops
- Pulp & Paper: Digester control, recovery boiler management
- Water & Wastewater: Pump station automation, treatment plant SCADA
- Mining & Minerals: Conveyor control, crusher automation, flotation cell management
Engineering Advantages
- Hot-Standby Redundancy: Bumpless switchover in <100 ms ensures zero process interruption during CPU failover
- Dual Ethernet Ports: Supports separated plant network and engineering network connections simultaneously
- Backward Compatibility: Drop-in replacement for PM864A/PM865K01 in existing AC 800M racks without hardware modification
- Expanded Memory: 64 MB RAM supports large application programs with complex function block libraries
- IEC 61131-3 Compliant: Full support for ST, FBD, LD, SFC, and IL programming languages via Control Builder M
- Deterministic Execution: Hard real-time OS guarantees scan cycle jitter <1 ms under full load
System Architecture & Signal Flow
The PM866K01 occupies the CPU slot of the AC 800M S800 I/O rack or standalone controller housing. On power-up, it initializes the backplane bus, loads the application program from Flash, and begins cyclic execution. Process data flows from S800 I/O modules → backplane → PM866K01 CPU → control algorithm → output modules. Ethernet ports connect to the plant MMS network (IEC 61850 / OPC DA/UA) and to the ABB System 800xA operator station network. In redundant configurations, a second PM866K01 in hot-standby mode mirrors all process data via the redundancy link; switchover is automatic upon primary CPU fault detection.
Sourcing & Quality Verification
- Origin: Genuine ABB-manufactured hardware; not aftermarket or refurbished unless explicitly stated
- Inspection: Each unit undergoes visual inspection, label verification (3BSE050198R1 barcode scan), and functional power-on test before shipment
- Packaging: Ships in original ABB anti-static packaging with foam insert; includes module extraction tool where available
- Documentation: ABB product datasheet and EU Declaration of Conformity available upon request
- Warranty: 12-month Konmask warranty covering manufacturing defects; DOA replacement within 7 days
Procurement Process
- Submit RFQ via support@konmask.com with quantity, required delivery date, and destination port
- Receive formal quotation with unit price, lead time, and shipping options within 24 business hours
- Confirm order via PO or proforma invoice; payment via T/T, L/C, or PayPal
- Shipment via DHL / FedEx / UPS Express with full tracking; EXW Xiamen or CIF available
- Post-delivery technical support via email and WhatsApp (+0086 19859288691)
Technical FAQ
Q: Is PM866K01 compatible with AC 800M firmware version 6.x?
A: Yes. PM866K01 supports Control Builder M firmware from version 5.1 through the current 6.x release. Firmware upgrade via service port is supported.
Q: Can PM866K01 replace PM864A without rack modification?
A: Yes. PM866K01 is mechanically and electrically compatible with the same AC 800M rack slot. Application program re-download via Control Builder M is required after replacement.
Q: Does this unit support PROFINET?
A: Native PROFINET IO controller functionality requires the CI871 communication interface module. PM866K01 provides the Ethernet backbone; PROFINET is handled at the CI module level.
Q: What is the maximum number of I/O points supported?
A: A single PM866K01 controller can manage up to 8 S800 I/O clusters via optical ModuleBus, supporting up to ~6,400 I/O channels depending on module mix.
Q: Is hot-swap replacement possible?
A: In a redundant configuration, the standby PM866K01 can be replaced while the primary remains in control. Single-CPU configurations require a planned shutdown for module replacement.
