Industrial Automation & Defense-Grade Solution — Adlink CPCI-6920/S408/M4G(G)-1270 | CPCI-6920 Series
Where This Product Is Used
The Adlink CPCI-6920/S408/M4G(G)-1270 is a high-performance CompactPCI single-board computer engineered for mission-critical embedded applications. Engineers and system integrators deploy this module across the following verticals:
- Defense & Military Systems — Radar signal processing, electronic warfare platforms, and ruggedized command-and-control units requiring long-lifecycle CPU availability.
- Telecommunications Infrastructure — ATCA/CompactPCI chassis-based carrier-grade platforms for base station controllers and network edge computing.
- Industrial Automation — Real-time machine vision, motion control supervisors, and SCADA host controllers in factory automation lines.
- Transportation & Railway — EN 50155-compatible rolling stock computing, wayside control units, and passenger information systems.
- Medical Imaging — High-throughput data acquisition and image reconstruction in CT/MRI ancillary processing nodes.
- Test & Measurement — Automated test equipment (ATE) requiring deterministic I/O and high-bandwidth PCIe expansion.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | CPCI-6920/S408/M4G(G)-1270 |
| Form Factor | CompactPCI (PICMG 2.0 R3.0), 6U |
| Processor | Intel® Core™ i7-1270 (12-core, up to 4.8 GHz Turbo, 28W TDP) |
| Memory | 4 GB DDR4 ECC SO-DIMM (expandable) |
| Storage | 8 GB onboard SSD (M.2 NVMe slot available) |
| Slot Width | 4-slot (4HP) |
| Bus Interface | CompactPCI 32/64-bit, 33/66 MHz; PCIe x4 rear I/O |
| Display | Dual independent display via DisplayPort + HDMI |
| Ethernet | 2× GbE (Intel i210); optional 10GbE rear transition module |
| USB | 4× USB 3.2 Gen 1, 2× USB 2.0 |
| Serial I/O | 2× RS-232/422/485 (software selectable) |
| Operating Temperature | 0°C to +60°C (standard); -40°C to +85°C (extended, on request) |
| Operating System | Windows 10/11 IoT, Linux (kernel 5.x+), VxWorks, QNX |
| Weight | 2,500 g (module only) |
| MTBF | >100,000 hours @ 25°C (Telcordia SR-332) |
Why Engineers Specify This Model
- 12th-Gen Intel Core i7-1270 Performance — Hybrid architecture (P-cores + E-cores) delivers up to 40% more throughput than previous-gen i7-8700 CompactPCI boards, enabling real-time AI inference at the edge.
- ECC Memory Protection — Hardware error-correcting memory prevents silent data corruption in 24/7 industrial and defense deployments.
- Long-Term Availability (LTA) — Adlink guarantees 7+ year product lifecycle, critical for defense and rail programs with decade-long support contracts.
- Rear I/O Transition Module (RTM) Ecosystem — Modular rear I/O expansion avoids front-panel cabling clutter in high-density chassis.
- Conduction-Cooling Option — Available in conduction-cooled variant for sealed enclosures with no active airflow.
- BIOS Customization — Adlink SEMA (Smart Embedded Management Agent) provides remote board management, watchdog, and health monitoring via API.
Complete System Bill of Materials
For a fully operational CompactPCI system based on the CPCI-6920/S408/M4G(G)-1270, engineers typically specify:
- CPCI-6920/S408/M4G(G)-1270 — System Host Board (this unit)
- Adlink cPCI-6U chassis (8-slot or 14-slot, with 300W+ PSU)
- Rear Transition Module (RTM) for GbE/serial breakout
- Adlink CPCI-3510 or compatible I/O peripheral boards
- M.2 NVMe SSD (256 GB–1 TB) for OS and data logging
- CompactPCI backplane (passive, 8-slot, 64-bit)
- DIN-rail or rack-mount chassis adapter kit
Compliance & Industry Standards
- PICMG 2.0 R3.0 — CompactPCI specification compliance
- CE / FCC Class A — EMC emissions and immunity
- RoHS 2 (2011/65/EU) — Hazardous substance restriction
- IEC 60068-2 — Vibration and shock testing
- MIL-STD-810H — Environmental engineering (ruggedized variants)
- EN 50155 — Railway rolling stock electronics (applicable variants)
- ISO 9001:2015 — Adlink manufacturing quality management
Quality Assurance & Sourcing
Konmask.com sources the CPCI-6920/S408/M4G(G)-1270 exclusively through verified Adlink authorized distribution channels and certified secondary-market partners. Every unit undergoes:
- Visual inspection and cosmetic grading
- Power-on self-test (POST) verification
- BIOS version and firmware integrity check
- Functional I/O port validation (Ethernet, USB, serial)
- Anti-static packaging with humidity indicator card
- Serialized traceability record retained for 5 years
How to Source This Part
Ready to procure the Adlink CPCI-6920/S408/M4G(G)-1270? Konmask.com offers:
- In-Stock Units — Ships within 1–3 business days from Hong Kong warehouse.
- Volume Pricing — Request a formal quotation for orders of 3+ units.
- Consignment & Exchange — Trade-in your legacy CompactPCI boards for credit.
- Export Documentation — Full commercial invoice, packing list, and COO certificate provided for customs clearance.
Contact our technical sales team: support@konmask.com | +0086 19859288691
Application-Specific FAQ
Q: Can the CPCI-6920/S408/M4G(G)-1270 operate as a system host controller in a mixed-vendor CompactPCI chassis?
A: Yes. It is fully PICMG 2.0 R3.0 compliant and functions as a system slot controller in any standards-compliant 6U CompactPCI chassis, including third-party chassis from Elma, Schroff, and Pixus.
Q: Is this board compatible with VxWorks real-time operating systems?
A: Adlink provides BSP (Board Support Package) for VxWorks 7 and Wind River Linux. Contact Konmask for BSP availability and licensing details.
Q: What is the maximum RAM configuration?
A: The /M4G variant ships with 4 GB DDR4 ECC. The board supports up to 32 GB via SO-DIMM slot upgrade — confirm with Konmask for compatible DIMM part numbers.
Q: Does Konmask offer warranty on this unit?
A: All units sold by Konmask.com carry a 90-day functional warranty. Extended 1-year warranty available upon request.
Q: Can I get a datasheet or test report before purchasing?
A: Yes. Email support@konmask.com with your inquiry and we will provide the official Adlink datasheet and our internal test report.
