Analog Signal Conditioning Solution — Allen-Bradley 1492-AIFM16-F-3 | IFM Series
Where This Product Is Used
The Allen-Bradley 1492-AIFM16-F-3 is a 16-channel analog input interface module (IFM) designed to terminate and condition field-side analog signals before they reach the PLC I/O rack. It is widely deployed in:
- Process manufacturing — oil & gas, chemical, and water treatment plants requiring dense 4–20 mA loop termination
- Automotive assembly lines — torque, pressure, and position sensor signal aggregation for ControlLogix systems
- Food & beverage facilities — hygienic-area transmitter wiring with clean panel-side termination
- HVAC and building automation — multi-zone temperature and humidity sensor inputs via standard analog signals
- Pharmaceutical manufacturing — validated analog loops requiring traceable, documented wiring infrastructure
- Power generation and utilities — high-density analog termination in MCC and control room panels
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 1492-AIFM16-F-3 |
| Series | IFM (Interface Module) |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Number of Channels | 16 Analog Inputs |
| Signal Type | Current / Voltage (field-configurable) |
| Termination Style | Screw terminal, DIN rail mount |
| Compatible I/O Modules | 1746, 1756, 1769 Analog I/O series |
| Compatible Controllers | ControlLogix, CompactLogix, SLC 500 |
| Mounting | 35 mm DIN rail |
| Weight | Approx. 80 g |
| Country of Origin | USA |
Why Engineers Specify This Model
- High-density termination — 16 channels in a compact DIN-rail footprint reduces panel space vs. discrete terminal blocks
- Pre-wired system integration — mates directly with Rockwell 1492 pre-wired cables, eliminating field-side wiring errors
- Signal integrity — integrated fusing and filtering on each channel protects downstream I/O cards from transients
- Reduced commissioning time — plug-and-play cable connection to analog I/O modules cuts loop-check time significantly
- Rockwell ecosystem compatibility — fully validated within Studio 5000 / RSLogix 5000 project architectures
- Long product lifecycle — part of the established 1492 IFM family with broad spare-parts availability
Complete System Bill of Materials
For a complete analog termination assembly using the 1492-AIFM16-F-3, engineers typically specify:
- 1492-AIFM16-F-3 — This interface module (field-side termination)
- 1756-IF16 / 1769-IF16C — ControlLogix or CompactLogix 16-ch analog input card (rack-side)
- 1492-ACABLE016XX — Pre-wired analog cable (length per project, XX = meters)
- 1492-DN3TW — DIN rail end anchor for IFM module
- 1756-A7 / 1756-A13 — ControlLogix chassis (if applicable)
- 1756-PA72 — ControlLogix power supply
Compliance & Industry Standards
- CE Marked — compliant with EU Low Voltage and EMC Directives
- UL Listed — UL 508 Industrial Control Equipment
- RoHS Compliant
- Designed to IEC 61131-2 PLC interface standards
- Suitable for use in ATEX Zone 2 / Class I Div 2 installations when used with appropriate barriers
Quality Assurance & Sourcing
All Allen-Bradley components sold through Konmask.com are sourced from verified industrial distributors and authorized supply chains. Each unit undergoes:
- Visual and label authenticity inspection
- Functional continuity verification prior to dispatch
- Secure anti-static packaging with tamper-evident sealing
- Full traceability documentation available on request
We serve OEMs, system integrators, MRO procurement teams, and plant engineers globally.
How to Source This Part
- In Stock: Add to cart and proceed to checkout — most orders ship within 1–3 business days
- Bulk / Project Quantity: Contact us for volume pricing and lead-time commitment
- Urgent Requirement: Email support@konmask.com or call +0086 19859288691 for expedited sourcing
- Cross-reference / Substitution: Our engineers can advise on compatible alternatives if this exact part is unavailable
Application-Specific FAQ
Q: Is the 1492-AIFM16-F-3 compatible with the 1756-IF16 ControlLogix analog input module?
A: Yes. The 1492-AIFM16-F-3 is designed to interface directly with the 1756-IF16 via the 1492-ACABLE016XX pre-wired cable assembly.
Q: Can this module handle both 4–20 mA and 0–10 V signals simultaneously?
A: Signal type is determined by the connected I/O card configuration and field wiring. Consult the 1492-AIFM16-F-3 installation instructions for per-channel wiring diagrams.
Q: What is the difference between the -F-3 and other 1492-AIFM16 variants?
A: The “-F-3” suffix denotes the fusing and filtering configuration. Other variants differ in fuse rating, filtering level, or termination style. Contact us if you need help selecting the correct variant.
Q: Does Konmask.com provide a warranty on this part?
A: Yes. We offer a standard 12-month warranty against manufacturing defects. Extended warranty and service contracts are available on request.
Q: Can I get a datasheet or wiring diagram?
A: Yes — email support@konmask.com with your part number and we will provide the official Rockwell Automation documentation.
