Allen-Bradley 1756-PB75 ControlLogix Power Supply | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1756-PB75 is a 75 W DC-input power supply module designed for the Rockwell Automation ControlLogix 1756 chassis. It converts a 18–32 VDC source into regulated backplane power, supporting mixed I/O, controller, and communication module configurations in demanding industrial control environments.
Buyers searching for a 1756-PB75 replacement or equivalent power supply typically face one of three scenarios: an end-of-life unit requiring a drop-in substitute, a budget-driven evaluation of functional equivalents, or a cross-brand migration during system redesign. This guide addresses all three, helping you make a confident, specification-verified selection decision.
Technical Specifications
| Parameter | Value | Selection Impact |
|---|---|---|
| Catalog Number | 1756-PB75 | — |
| Input Voltage | 18–32 VDC | ⚠ Critical — must match source bus voltage |
| Output Power | 75 W (backplane) | ⚠ Critical — verify chassis load budget |
| Backplane Current (1.2 V) | 10 A | Key for module count planning |
| Backplane Current (3.3 V) | 4 A | Key for module count planning |
| Backplane Current (5 V) | 4 A | Key for module count planning |
| Backplane Current (24 V) | 2 A | Key for module count planning |
| Chassis Compatibility | 1756-Axx series (4–17 slot) | Physical fit requirement |
| Redundancy Support | Yes (with 1756-PSCA2) | Required for high-availability systems |
| Diagnostics | LED status + FAULT output | Affects monitoring integration |
| Operating Temperature | 0–60 °C | Verify against enclosure rating |
| Dimensions (H × W × D) | 147 × 45 × 144 mm | Chassis slot width: 1 slot |
| Weight | ~980 g | — |
| Certifications | UL, CE, cUL, C-Tick | Required for regulated industries |
| Firmware | No firmware required | — |
Compatible Replacement & Equivalent Models
Use the categories below to identify the most appropriate substitute based on your system constraints.
1. Direct Drop-in Replacements (Same Form, Fit & Function)
- 1756-PB75/B, /C, /D — Later firmware revisions of the same catalog number. Fully interchangeable; verify revision compatibility with your Studio 5000 project if using advanced diagnostics.
- 1756-PB75E — Enhanced revision with improved diagnostics. Drop-in replacement; no wiring changes required.
2. Functional Equivalents (Same Specs, Different Catalog)
- 1756-PA75 — AC-input (85–265 VAC) equivalent at 75 W. Functionally equivalent output; requires AC source instead of DC. Use when migrating from DC to AC power architecture.
- 1756-PB72 — 72 W DC-input predecessor. Compatible in most chassis configurations; verify total module load does not exceed 72 W before substituting.
- 1756-PB75K — Conformal-coated variant for harsh environments. Electrically identical; recommended for coastal, chemical, or high-humidity installations.
3. Cross-Brand Alternatives (Functional Substitutes — Requires Engineering Review)
- Siemens SITOP PSU100S 24 V/10 A — External DIN-rail DC supply feeding the 1756-PB75 input bus. Not a chassis-slot replacement; used as upstream source redundancy.
- Phoenix Contact QUINT-PS/1AC/24DC/10 — Similar upstream DC supply role. Suitable for redundant input power architecture.
- Note: No third-party module exists that physically replaces the 1756-PB75 in the ControlLogix backplane slot. Cross-brand alternatives apply to the upstream power source only.
Why Choose the Original Model
- Precision Power Delivery: Factory-calibrated backplane rails ensure stable 1.2 V / 3.3 V / 5 V / 24 V outputs within Rockwell’s tight tolerance specifications, preventing nuisance faults in high-density chassis.
- Full Certification Compliance: UL 508, CE, and cUL listings are pre-validated — critical for machinery directive compliance in EU and UL-listed panel builds in North America.
- Seamless ControlLogix Integration: Native backplane communication enables real-time power diagnostics visible in Studio 5000 Logix Designer, reducing MTTR during troubleshooting.
- Redundancy Architecture Support: Pairs directly with the 1756-PSCA2 chassis adapter for N+1 redundant power configurations without additional engineering.
- Rockwell Technical Support Eligibility: Genuine modules qualify for TechConnect support contracts, firmware advisories, and product lifecycle notifications.
- Warranty & Traceability: Authentic units carry Rockwell Automation’s standard warranty and full manufacturing traceability — essential for regulated industries (pharma, food & beverage, oil & gas).
Typical Applications
- Automotive Assembly: Body-in-white welding lines and paint shop conveyors requiring 24 VDC bus power with redundancy for zero-downtime production.
- Oil & Gas: Wellhead and pipeline SCADA panels where DC power from battery-backed UPS systems feeds ControlLogix chassis in remote locations.
- Water & Wastewater: Pump station and treatment plant PLCs operating on solar/battery DC microgrids with 24 VDC distribution.
- Food & Beverage: Hygienic processing lines with washdown enclosures where DC power distribution simplifies panel design and reduces AC shock risk.
- Mining & Minerals: Conveyor drive control panels powered from DC bus systems in underground or surface extraction environments.
- Semiconductor Fabrication: Cleanroom equipment controllers requiring stable, low-noise DC backplane power for precision motion and I/O modules.
System Compatibility
The 1756-PB75 is compatible with the following ControlLogix system components:
- 1756-A4, A7, A10, A13, A17 — ControlLogix chassis (4 to 17 slots); power supply occupies slot 0
- 1756-L6x / L7x / L8x — ControlLogix controllers (all current generations)
- 1756-EN2T / EN2TR / EN3TR — EtherNet/IP communication modules
- 1756-DNB — DeviceNet bridge module
- 1756-PSCA2 — Power supply chassis adapter for redundant power configuration
- 1756-IB16 / OB16E — Standard digital I/O modules
- 1756-IF8 / OF8 — Analog I/O modules
Selection Guide
Answer these three questions before ordering to confirm the 1756-PB75 is the correct fit for your system:
- Is your input power source 18–32 VDC? If your panel uses AC power (85–265 VAC), you need the 1756-PA75 instead. Contact Konmask if you are unsure of your bus voltage.
- Does your chassis load budget stay within 75 W? Sum the backplane power consumption of all installed modules (available in each module’s installation instructions). If total load exceeds 75 W, consider the 1756-PB94 (94 W) or a dual-supply configuration.
- Do you require redundant power? If your application demands N+1 power redundancy, confirm you have a 1756-PSCA2 adapter and a second 1756-PB75 unit. Konmask can supply matched pairs with verified revision alignment.
Not sure which model fits your system? Contact Konmask at support@konmask.com — our engineers respond within 24 hours with a verified recommendation.
Quality Assurance & Sourcing
Konmask sources the 1756-PB75 through authorized distribution channels and verified surplus networks. Every unit undergoes a 4-step inspection process before shipment:
- Visual Inspection: Housing, label, connector pins, and revision markings checked against Rockwell Automation’s published specifications.
- Functional Power Test: Input voltage applied; all backplane output rails measured and verified within tolerance.
- Authenticity Verification: Serial number and date code cross-referenced against known counterfeit indicators and Rockwell’s product authentication guidelines.
- Packaging & Documentation: Unit packed in anti-static ESD bag with inspection report; documentation available on request.
Available documentation upon request: Test report, certificate of conformance, country of origin declaration, photos of physical unit prior to shipment.
How to Order
- Submit Your Inquiry: Email support@konmask.com with your required quantity, target delivery date, and any revision or certification requirements.
- Receive Quotation: Konmask will respond within 24 hours with pricing, lead time, and available stock confirmation.
- Confirm & Ship: Approve the proforma invoice; units are packed, inspected, and dispatched with full tracking and documentation.
📞 +0086 19859288691 | ✉ support@konmask.com | 🌐 Konmask.com
Replacement & Compatibility FAQ
Q: Can I use the 1756-PA75 as a direct replacement for the 1756-PB75?
A: Not directly — the 1756-PA75 is the AC-input equivalent (85–265 VAC) while the 1756-PB75 requires a 18–32 VDC source. Both deliver 75 W to the backplane and are physically interchangeable in the chassis slot, but your input wiring and upstream power source must match the module’s input type. If you are migrating from DC to AC power, the 1756-PA75 is the correct functional substitute.
Q: Is the 1756-PB75 compatible with all ControlLogix chassis sizes?
A: Yes — the 1756-PB75 is compatible with all 1756-Axx chassis (4, 7, 10, 13, and 17 slot). It occupies the dedicated power supply slot and does not consume a module slot. Verify that your total chassis module load does not exceed 75 W regardless of chassis size.
Q: Are there any cross-brand equivalents or substitutes that fit directly in the 1756 backplane slot?
A: No third-party manufacturer produces a module that is electrically and mechanically equivalent to the 1756-PB75 for direct backplane installation. The ControlLogix backplane interface is proprietary to Rockwell Automation. Cross-brand alternatives (e.g., Siemens SITOP, Phoenix Contact QUINT) serve as upstream DC source supplies only and do not substitute the backplane power module itself. For genuine replacement units, Konmask supplies verified authentic 1756-PB75 modules — contact us for availability.
