Multi-Axis Motion Control Solution – Allen-Bradley 1769-L30ERM | CompactLogix 5370
The Allen-Bradley 1769-L30ERM is a CompactLogix 5370 L3 series programmable automation controller (PAC) with integrated EtherNet/IP motion control. Designed for coordinated multi-axis servo and motion applications, it delivers deterministic real-time control in a compact DIN-rail form factor. Sourced and verified by Konmask.com — your trusted B2B supplier for Rockwell Automation components.
Where This Product Is Used
- Packaging Machinery – Coordinates servo axes for pick-and-place, form-fill-seal, and cartoning lines requiring precise motion synchronization.
- CNC & Machining Centers – Provides multi-axis interpolated motion for milling, turning, and grinding applications with tight positional accuracy.
- Conveyor & Material Handling Systems – Manages electronic gearing and camming between multiple conveyor zones in automotive and logistics facilities.
- Robotics & Gantry Systems – Controls Cartesian and SCARA robot axes via EtherNet/IP drive network with coordinated motion profiles.
- Printing & Converting Equipment – Synchronizes web tension, registration, and cut-to-length axes in high-speed printing and label converting lines.
- Semiconductor & Electronics Assembly – Delivers sub-micron positioning repeatability for wafer handling, PCB drilling, and SMT placement equipment.
- Food & Beverage Processing – Deployed in hygienic-design filling, capping, and labeling machines requiring washdown-rated drive integration.
Technical Specifications
- Part Number: 1769-L30ERM
- Series: CompactLogix 5370 L3
- Manufacturer: Allen-Bradley / Rockwell Automation
- Controller Type: Programmable Automation Controller (PAC) with Motion
- User Memory: 2 MB
- Motion Axes: Up to 16 axes (EtherNet/IP CIP Motion)
- Communication: Dual-port EtherNet/IP (DLR capable)
- I/O Capacity: Up to 30 local 1769 Compact I/O modules
- Programming Software: Studio 5000 Logix Designer
- Power Supply: 1769-PA2 / 1769-PB2 (sold separately)
- Form Factor: CompactLogix DIN-rail mount
- Weight: 320 g (approx.)
- Condition: New / Refurbished (specify at order)
- Warranty: 12 months from shipment date
Why Engineers Specify This Model
- Integrated CIP Motion – Native EtherNet/IP CIP Motion eliminates dedicated motion networks (Sercos, MECHATROLINK), reducing wiring complexity and cabinet footprint.
- Scalable to 16 Axes – The L30ERM supports up to 16 coordinated servo axes, covering the majority of mid-range machine motion requirements without upgrading to a larger controller.
- Device Level Ring (DLR) Support – Dual-port Ethernet enables ring topology for network fault tolerance — critical for continuous-process and automotive applications.
- Studio 5000 Unified Environment – Single programming environment for logic, motion, safety, and HMI reduces engineering time and simplifies commissioning.
- Proven Installed Base – Widely deployed across OEM machine platforms globally, ensuring long-term spare parts availability and field engineer familiarity.
- Rapid Replacement Availability – Stocked at Konmask for immediate dispatch, minimizing MTTR on production-critical equipment.
Complete System Bill of Materials
A complete CompactLogix motion system using the 1769-L30ERM typically includes:
- 1769-PA2 or 1769-PB2 — CompactLogix Power Supply
- Kinetix 5500 / 5700 — EtherNet/IP Servo Drives (per axis)
- MPL / VPL Series — Allen-Bradley Servo Motors
- 1769-IQ16 / 1769-OB16 — Digital I/O Modules
- 1769-IF4 / 1769-OF4 — Analog I/O Modules
- 1769-ECR — End Cap / Right Terminator
- PanelView Plus 7 — HMI Operator Interface
- Stratix 5700 — Industrial Ethernet Switch (DLR)
Contact Konmask for complete BOM sourcing and volume pricing.
Compliance & Industry Standards
- CE Marking — EMC Directive & Low Voltage Directive compliant
- UL Listed — UL 508 Industrial Control Equipment
- RoHS Compliant — Restriction of Hazardous Substances
- ODVA Conformance — EtherNet/IP CIP Motion certified
- IEC 61131-3 — Programmable Controller standard (Ladder, FBD, ST, SFC)
- ISO 13849 / IEC 62061 — Safety-rated motion via GuardLogix variant (consult for safety applications)
Quality Assurance & Sourcing
Konmask.com specializes in Allen-Bradley and Rockwell Automation components for B2B industrial buyers worldwide. Every 1769-L30ERM unit we supply undergoes:
- Visual and dimensional inspection against Rockwell Automation OEM specifications
- Firmware version verification and power-on functional check
- Anti-static ESD packaging with humidity indicator cards
- Serialized shipment documentation with full traceability
- Optional third-party inspection report available on request
How to Source This Part
- Add to cart and complete checkout — we accept T/T wire transfer, PayPal, and major credit cards.
- For bulk orders (>3 units) or urgent AOG requirements, email [email protected] for a dedicated quote within 2 business hours.
- Lead time: In-stock units ship within 1–3 business days. ETA confirmed at order placement.
- Export documentation provided: commercial invoice, packing list, certificate of origin, and CoC upon request.
Application-Specific FAQ
Q: What is the difference between 1769-L30ERM and 1769-L30ER?
A: The ERM suffix designates the motion-enabled variant with CIP Motion support for up to 16 servo axes. The ER variant supports standard EtherNet/IP I/O only, without coordinated motion capability.
Q: Which Kinetix drives are compatible with the 1769-L30ERM?
A: The 1769-L30ERM is compatible with Kinetix 5500, Kinetix 5700, and Kinetix 350 servo drives via EtherNet/IP CIP Motion. Kinetix 6500 is also supported. Confirm firmware compatibility with our technical team.
Q: Can this controller run safety logic?
A: The standard 1769-L30ERM does not include integrated safety. For SIL 2 / PLd safety applications, specify the GuardLogix 5370 variant (1769-L30ERMS). Contact Konmask for availability.
Q: What Studio 5000 version is required?
A: Studio 5000 Logix Designer v21 or later is required. For full motion feature support, v24 or later is recommended. Contact us if you need firmware downgrade support.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. CoC is available at no additional charge upon request at time of order.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 3 or more units.
