Allen-Bradley 1783-MS10T Stratix 2000 – 10-Port Unmanaged Ethernet Switch | Rockwell Automation Industrial Networking
Engineering Background
The Allen-Bradley 1783-MS10T is part of Rockwell Automation’s Stratix 2000 series — purpose-built unmanaged Ethernet switches designed for deterministic, high-reliability industrial network infrastructure. Engineered to IEC 61158 and EtherNet/IP standards, this switch delivers plug-and-play connectivity for machine-level and cell-level automation networks without requiring network configuration expertise.
Product Positioning
This listing covers a verified multi-component bundle (SKU: PN-16204) sourced from authorized industrial distributors. The bundle includes the 1783-MS10T Ethernet switch alongside complementary automation components — AV600-08 industrial Ethernet media converter, TN4900 mass flow controller (750 SCCM H₂O range), and VC-4900MEPR-4V proportional control valve — serving process automation, semiconductor fabrication, and discrete manufacturing environments.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number (Bundle) | PN-16204 |
| Switch Model | Allen-Bradley 1783-MS10T (Stratix 2000) |
| Switch Ports | 10 × 10/100BASE-TX RJ45 (Auto-MDI/MDIX) |
| Switch Type | Unmanaged, Store-and-Forward |
| Protocol Support | EtherNet/IP, IEEE 802.3, IEEE 802.3u |
| Operating Voltage | 24 VDC (18–30 VDC range) |
| Power Consumption | ≤ 7.2 W |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Enclosure Rating | IP30 / DIN-rail mount |
| Certifications | UL, CE, cUL, RCM, EAC |
| Flow Controller Model | TN4900 (750 SCCM H₂O) |
| Flow Range | 0–750 SCCM (Standard Cubic Centimeters per Minute, H₂O calibration) |
| Control Valve Model | VC-4900MEPR-4V |
| Valve Actuation | Proportional, 4–20 mA / 0–10 VDC command signal |
| Media Converter | AV600-08 |
| Product Weight | 800 g (bundle, packed) |
| Country of Origin | USA / Rockwell Automation |
Proven Application Environments
- Discrete Manufacturing: Machine-level EtherNet/IP networks connecting PLCs, drives, and I/O modules in automotive and electronics assembly lines.
- Process Automation: DCS integration nodes for chemical, oil & gas, and water treatment plants requiring deterministic Ethernet communication.
- Semiconductor Fabrication: TN4900 mass flow controller and VC-4900MEPR-4V valve used in gas delivery and process chamber pressure control.
- Food & Beverage: Hygienic-zone network segmentation with IP30-rated switch in panel-mount configurations.
- Building Automation: BACnet/IP and EtherNet/IP convergence at field device level.
Engineering Advantages
- Zero-Configuration Deployment: 1783-MS10T requires no IP addressing or VLAN setup — ideal for rapid machine commissioning and OEM integration.
- Wide Input Voltage Tolerance: 18–30 VDC operation accommodates standard 24 VDC industrial panel power without additional regulation.
- DIN-Rail Form Factor: Compact footprint integrates directly into standard IEC 60715 control panels alongside PLCs and I/O modules.
- Precision Flow Control: TN4900 delivers ±1% full-scale accuracy for critical process gas metering applications.
- Proportional Valve Compatibility: VC-4900MEPR-4V supports both current and voltage command signals for flexible PLC/DCS integration.
- Rockwell Ecosystem Native: Fully compatible with Studio 5000 Logix Designer, FactoryTalk View, and Integrated Architecture toolset.
System Architecture & Signal Flow
In a typical EtherNet/IP cell architecture, the 1783-MS10T serves as the machine-level unmanaged switch connecting a CompactLogix or MicroLogix PLC to distributed I/O (1734 POINT I/O or 1769 Compact I/O), HMI panels, and variable frequency drives. The AV600-08 media converter bridges copper Ethernet to fiber uplinks for noise-immune long-distance runs to supervisory SCADA or DCS layers.
The TN4900 mass flow controller receives a 0–10 VDC or 4–20 mA analog output from the PLC analog output module, translating the command signal into a calibrated gas flow rate (0–750 SCCM H₂O equivalent). The VC-4900MEPR-4V proportional valve modulates downstream pressure or flow in closed-loop PID control, with process variable feedback returned to the PLC analog input for real-time regulation.
Sourcing & Quality Verification
- All components sourced from authorized Rockwell Automation distributors and verified surplus channels with full traceability documentation.
- Each unit undergoes visual inspection, label verification, and functional pre-shipment testing where applicable.
- Counterfeit-prevention: serial numbers cross-referenced against Rockwell Automation’s product authentication database prior to dispatch.
- Original manufacturer packaging preserved where available; anti-static ESD packaging applied for all electronic components.
- Certificate of Conformance (CoC) and test reports available upon request for OEM and system integrator procurement.
Procurement Process
- Inquiry: Contact support@konmask.com with your project BOM and required delivery timeline.
- Quotation: Receive a formal quotation with lead time, quantity availability, and shipping options within 24 business hours.
- Order Confirmation: Purchase order accepted via email or through the Konmask.com checkout. Net 30 terms available for qualified accounts.
- Quality Check & Dispatch: Pre-shipment inspection completed; tracking number issued within 1–2 business days of payment confirmation.
- After-Sales Support: 12-month warranty on genuine new stock; 90-day warranty on tested surplus. Technical support available via email and phone.
Technical FAQ
Q: Is the 1783-MS10T compatible with Rockwell Automation’s Integrated Architecture?
A: Yes. As an unmanaged EtherNet/IP switch, it is fully compatible with all Logix-based controllers and FactoryTalk software without requiring additional configuration.
Q: Can the TN4900 be recalibrated for gases other than H₂O?
A: The TN4900 is factory-calibrated for H₂O (water vapor equivalent). Recalibration for other gases requires applying the appropriate conversion factor per the manufacturer’s gas correction table or returning the unit to an authorized calibration lab.
Q: What is the lead time for this bundle?
A: Standard lead time is 3–7 business days for in-stock items. Contact us for expedited shipping options.
Q: Do you provide documentation and datasheets?
A: Yes. Rockwell Automation product datasheets, installation instructions, and CoC documents are available upon request at no additional charge.
Q: Is this product export-controlled (EAR/ITAR)?
A: Some Rockwell Automation products may be subject to US Export Administration Regulations (EAR). Konmask.com complies with all applicable export control laws. Please confirm your end-use destination at time of inquiry.
