Machine Safety Solution – Allen-Bradley 1791DS-IB8XOB8 | 1791DS Series
The Allen-Bradley 1791DS-IB8XOB8 is a compact Safety Digital I/O module designed for DeviceNet Safety networks. With 8 safety-rated digital inputs and 8 digital outputs in a single housing, it delivers SIL 2 / PLd-rated safety I/O for machine guarding, emergency stop, and light curtain integration — without the bulk of a traditional safety relay panel.
Where This Product Is Used
- Machine Guarding & Light Curtain Integration — Connects OSSD-output safety light curtains directly to the DeviceNet Safety network, enabling zone-based access control on stamping presses, robotic cells, and packaging lines.
- Emergency Stop (E-Stop) Circuits — Monitors dual-channel E-stop buttons and safety rope pulls across conveyor systems and automated assembly stations, with on-board cross-fault detection.
- Safety Gate & Interlock Monitoring — Reads safety door switches and interlocks on CNC machining centers and injection molding machines, triggering controlled stops via the output channels.
- Two-Hand Control Stations — Validates simultaneous actuation timing for press brake and hydraulic press applications, meeting EN 574 Type IIIC requirements.
- Palletizer & Material Handling Safety Zones — Manages multiple safety zones on high-speed palletizers, stretch wrappers, and AGV crossing points within a single compact module.
- Automotive Body-in-White Welding Lines — Integrates with safety PLCs (GuardLogix) to enforce safe-state conditions during fixture loading and robot teach modes.
Technical Specifications
- Part Number / SKU: 1791DS-IB8XOB8
- Series: 1791DS (ArmorBlock Guard I/O)
- Manufacturer: Allen-Bradley / Rockwell Automation
- Network Protocol: DeviceNet Safety (CIP Safety)
- Safety Inputs: 8 × dual-channel safety digital inputs (24 V DC)
- Safety Outputs: 8 × solid-state safety digital outputs (24 V DC, 0.5 A per output)
- Safety Integrity Level: SIL 2 (IEC 62061), PLd Cat. 3 (ISO 13849-1)
- Housing: IP67-rated ArmorBlock (sealed, no enclosure required)
- Supply Voltage: 24 V DC (±10%)
- Operating Temperature: 0 °C to +55 °C
- Certifications: UL, CE, TÜV, cUL
- Mounting: DIN rail or panel mount via M12 connectors
- Weight: ~500 g
- Catalog Number: 1791DS-IB8XOB8
Why Engineers Specify This Model
- Distributed Safety I/O at the Machine — IP67 ArmorBlock housing eliminates the need for a control cabinet at each safety zone, reducing wiring costs by up to 60% versus traditional hardwired safety relays.
- Single Module, Dual Function — Combining 8 inputs and 8 outputs in one unit simplifies BOM and reduces panel footprint compared to separate input/output modules.
- Native CIP Safety Integration — Plug-and-play with GuardLogix and Compact GuardLogix safety PLCs; safety data is transported over the same DeviceNet cable as standard I/O, no separate safety bus required.
- On-Board Diagnostics — Per-channel fault detection and status LEDs accelerate troubleshooting and minimize unplanned downtime.
- Proven Rockwell Ecosystem — Fully supported in Studio 5000 Logix Designer with pre-built Add-On Instructions (AOIs) for rapid safety program development.
Complete System Bill of Materials
- 1791DS-IB8XOB8 — Safety Digital I/O Module (this item)
- 1756-L73S / 1756-L72S — GuardLogix Safety Controller (ControlLogix platform)
- 1788-DN2DN — DeviceNet Scanner Module
- 1485C-P1A50 — DeviceNet Thick Cable (per meter)
- 1485T-P2T5-T5 — DeviceNet T-Port Tap
- 440G-MT47280 — TLS-GD2 Safety Gate Switch (compatible input device)
- 800FM-MT44 — Mushroom-Head E-Stop Push Button (compatible input device)
- 1606-XLP72E — 24 V DC Power Supply, 3 A
Compliance & Industry Standards
- IEC 62061 — Safety Integrity Level SIL 2
- ISO 13849-1 — Performance Level PLd, Category 3
- IEC 61508 — Functional Safety of E/E/PE Safety-Related Systems
- EN ISO 13849-1:2015 — Machine Safety
- UL 508 — Industrial Control Equipment
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- TÜV Rheinland Certified
- RoHS Compliant
