Allen-Bradley 1440-TPR06-00RE – XM-360 Absolute Position Transducer | Rockwell Automation XM Series
Engineering Background: The XM Series condition monitoring platform from Rockwell Automation (Allen-Bradley) is the industry benchmark for machine protection and predictive maintenance in rotating machinery. Designed for continuous, real-time measurement of shaft position and speed, the XM-360 module integrates directly into the Logix control architecture, enabling seamless data acquisition without additional gateways.
Product Positioning: The 1440-TPR06-00RE is a passive rotary position transducer engineered for high-resolution absolute angular measurement. It is the preferred sensor for turbomachinery, compressors, pumps, and motor-driven systems where precise shaft position feedback is critical for protection relay logic and condition-based maintenance programs.
Complete Technical Specifications
- Manufacturer: Allen-Bradley / Rockwell Automation
- Part Number: 1440-TPR06-00RE
- Series / Platform: XM-360 Absolute Position Transducer
- Sensor Type: Rotary Position Transducer (Passive)
- Measurement: Absolute angular shaft position & rotational speed
- Output Signal: Compatible with XM-360 Dynamic Measurement Module input
- Connector: RE-type (rear-exit cable configuration)
- Cable Length: 6 m (standard)
- Housing Material: Stainless steel / industrial-grade enclosure
- Operating Temperature: -40 °C to +121 °C
- IP Rating: IP67 (dust-tight, water-resistant)
- Weight: Approx. 1,200 g (including cable)
- Compliance: CE, UL, RoHS
- Country of Origin: USA
Proven Application Environments
- Turbomachinery protection systems (steam turbines, gas turbines, expanders)
- Centrifugal & reciprocating compressors
- Large motor-driven pump trains
- Gearbox and drivetrain condition monitoring
- Power generation and petrochemical plant machinery
- Continuous process industries requiring API 670-compliant monitoring
Engineering Advantages
- High-Resolution Absolute Position: Eliminates homing routines; position is known immediately on power-up.
- Native XM Platform Integration: Plug-and-play with the XM-360 module — no signal conditioning required.
- Logix Ecosystem Compatibility: Data surfaces directly in Studio 5000 / FactoryTalk for unified dashboards.
- Robust RE-Exit Cable Design: Rear-exit connector minimizes mechanical stress in confined machine housings.
- Wide Temperature Range: Qualified for both arctic cold-start and high-ambient process environments.
- Passive Transducer Architecture: No internal electronics — inherently immune to EMI/RFI common in drive-heavy plants.
System Architecture & Signal Flow
The 1440-TPR06-00RE transducer mounts to the machine shaft or coupling and feeds a continuous angular position signal to the Allen-Bradley XM-360 Dynamic Measurement Module. The XM-360 processes raw transducer data, applies configurable alarm/trip thresholds, and publishes structured data over the EtherNet/IP backplane to the ControlLogix or CompactLogix controller. Operators monitor live position, speed, and derived vibration vectors in FactoryTalk View or any OPC-UA compatible SCADA platform.
Sourcing & Quality Verification
- Source: Authorized distribution channel & verified surplus with full traceability
- Inspection: Each unit inspected for physical integrity, label authenticity, and connector condition prior to shipment
- Packaging: Original OEM packaging retained where available; anti-static protective packaging applied for all units
- Warranty: 12-month operational warranty against manufacturing defects
- Documentation: Certificate of conformance available upon request
Procurement Process
- Submit your RFQ via Konmask.com or email support@konmask.com
- Receive stock confirmation and lead-time within 24 business hours
- Review proforma invoice — payment via T/T, PayPal, or trade terms for qualified accounts
- Shipment via DHL / FedEx / UPS with full tracking; export documentation (CO, packing list, commercial invoice) included
- Post-delivery technical support available from our automation engineering team
Technical FAQ
Q: Is the 1440-TPR06-00RE compatible with the XM-360 module only?
A: Yes. This transducer is specifically designed for the Allen-Bradley XM-360 Absolute Position Transducer input channel. It is not interchangeable with standard proximity probes or encoders without signal conditioning.
Q: What is the difference between -00RE and other suffix variants?
A: The suffix denotes cable exit direction and length. -00RE = 6 m rear-exit cable. Other variants include different cable lengths or connector orientations. Confirm your machine housing geometry before ordering.
Q: Can this sensor be used for API 670 compliance?
A: The XM-360 platform is designed to meet API 670 machinery protection standards when properly configured. Consult your system integrator for site-specific compliance validation.
Q: Do you provide installation support?
A: Yes. Our engineering team can provide mounting guidelines, wiring diagrams, and XM-360 configuration parameters. Contact us at support@konmask.com.
