Discrete Control Solution – Allen-Bradley 1794-IB10XOB6 | FLEX I/O Series
Where This Product Is Used
The Allen-Bradley 1794-IB10XOB6 is a 24VDC digital combination I/O module from the Rockwell Automation FLEX I/O platform. It delivers 10 sink/source digital inputs and 6 protected solid-state digital outputs on a single compact module, making it the preferred choice for engineers who need to consolidate discrete I/O in space-constrained panel builds.
- Automotive Assembly Lines – Monitoring conveyor position sensors and actuating pneumatic solenoids within a single FLEX I/O rack.
- Food & Beverage Packaging – Reading proximity switches and controlling filling-valve outputs under washdown-adjacent conditions.
- Material Handling & Sortation – Interfacing photo-eye sensors and divert-gate actuators in high-cycle-rate environments.
- Water/Wastewater Treatment – Monitoring float switches and controlling pump-start relays across distributed remote I/O drops.
- Machine Tool & Press Control – Capturing limit-switch feedback and issuing brake/clutch commands with deterministic scan times.
- Building Automation & HVAC – Integrating door-contact inputs and damper-actuator outputs in a ControlNet or DeviceNet node.
Technical Specifications
| Attribute | Value |
|---|---|
| Catalog Number | 1794-IB10XOB6 |
| Series / Platform | FLEX I/O (1794 Series) |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Module Type | Digital Combination (Input + Output) |
| Number of Inputs | 10 (24VDC Sink/Source) |
| Number of Outputs | 6 (24VDC Protected Solid-State) |
| Input Voltage Range | 10–30VDC |
| Output Voltage Range | 10–30VDC |
| Output Current per Point | 0.5 A max |
| Backplane Current Draw | 75 mA @ 5VDC |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Enclosure Rating | Open-style (requires enclosure) |
| Wiring Style | Removable terminal block (RTB) |
| Compatible Adapters | 1794-AENT, 1794-ACN15, 1794-ADN, 1794-APB |
| Weight | Approx. 750 g (with RTB) |
Why Engineers Specify This Model
- Combo I/O reduces rack slots – Combining 10 inputs and 6 outputs in one slot lowers hardware cost and panel footprint versus separate input and output modules.
- Protected solid-state outputs – Built-in short-circuit and overload protection eliminates the need for external fusing on each output point.
- Sink/source input flexibility – Compatible with both NPN and PNP field devices without rewiring, simplifying sensor selection.
- Hot-swap capable – FLEX I/O architecture supports module replacement under power (adapter-dependent), minimizing unplanned downtime.
- Broad network compatibility – Works across EtherNet/IP, ControlNet, DeviceNet, and PROFIBUS adapters, protecting the investment as network topology evolves.
- Proven field reliability – Part of the 1794 FLEX I/O family with decades of deployment in harsh industrial environments worldwide.
Complete System Bill of Materials
A typical FLEX I/O node using the 1794-IB10XOB6 requires the following components:
- 1794-IB10XOB6 – Digital combo I/O module (this item)
- 1794-AENT or 1794-ACN15 – EtherNet/IP or ControlNet adapter
- 1794-TB3 or 1794-TB3S – Removable terminal block (3-wire or spring-clamp)
- 1794-PS13 – FLEX I/O power supply (if local power required)
- 1794-CHS – FLEX I/O chassis/rail mount kit
- 1756-L8x ControlLogix or 1769-L3x CompactLogix – Host controller
Compliance & Industry Standards
- UL Listed (UL 508)
- CE Marked (Low Voltage Directive & EMC Directive)
- RoHS Compliant
- cUL Listed (Canadian market)
- ATEX / IECEx: Not rated for hazardous locations — use appropriate barriers if required
- Rockwell Automation Product Certification: rok.auto/certifications
Quality Assurance & Sourcing
Every 1794-IB10XOB6 unit offered through Konmask.com undergoes the following before shipment:
- Visual inspection for physical damage, label integrity, and connector condition
- Functional power-on verification where test fixtures are available
- Anti-static packaging with humidity indicator card
- Traceable lot documentation retained for 3 years
We source from authorized distributors, factory-surplus channels, and verified industrial resellers. Counterfeit-risk screening is applied to all inbound stock.
How to Source This Part
- In Stock: Add to cart and check out — ships within 1–3 business days.
- Bulk / Project Quantity: Contact us for volume pricing and lead-time commitment.
- Urgent / Emergency: Call or WhatsApp +0086 19859288691 for same-day quotation.
- Repair / Exchange: Ask about our exchange program if your existing module has failed.
Application-Specific FAQ
Q: Can the 1794-IB10XOB6 be used with a 1794-AENT EtherNet/IP adapter?
A: Yes. The module is fully compatible with the 1794-AENT adapter and is configured via RSLogix 5000 / Studio 5000 using the standard FLEX I/O EDS file.
Q: What is the maximum number of 1794-IB10XOB6 modules per adapter?
A: Up to 8 FLEX I/O modules can be mounted per adapter, subject to backplane current budget. Verify total current draw against the adapter’s 5VDC supply rating.
Q: Are the outputs relay or solid-state?
A: Solid-state (transistor) outputs with built-in protection. They are not relay outputs — do not use for AC load switching without an interposing relay.
Q: Is a removable terminal block (RTB) included?
A: RTBs are typically ordered separately (1794-TB3 or 1794-TB3S). Please confirm at time of order whether an RTB is included with your specific unit.
Q: Can this module replace a 1794-IB10 + 1794-OB6 combination?
A: Functionally yes, in most applications. Verify I/O mapping and program tag addresses in Studio 5000 before substitution in a live system.
