Allen-Bradley 2097-V34PR6-LM Kinetix 300 Servo Drive | Replacement, Equivalent & Selection Guide
The Allen-Bradley 2097-V34PR6-LM is a single-axis EtherNet/IP servo drive from the Kinetix 300 series, designed for precise motion control in industrial automation systems. This drive delivers reliable performance for OEM machine builders and system integrators requiring compact, high-performance servo solutions compatible with Rockwell Automation control architectures.
Technical Specifications
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Part Number / SKU: 2097-V34PR6-LM
- Series: Kinetix 300
- Drive Type: Single-Axis EtherNet/IP Servo Drive
- Input Voltage: 240V AC, Three-Phase
- Output Current (Continuous): 6A RMS
- Output Current (Peak): 18A RMS
- Communication Interface: EtherNet/IP
- Feedback Support: Incremental Encoder, Absolute Encoder (multi-turn)
- Safe Torque Off (STO): Integrated, SIL 2 / PLd
- Mounting: Panel Mount
- Enclosure Rating: IP20
- Operating Temperature: 0–50°C
- Weight: Approx. 1.8 kg
- Certifications: CE, UL, cUL
Compatible Replacement & Equivalent Models
When the 2097-V34PR6-LM is unavailable or requires a cost-effective alternative, the following models are commonly evaluated as replacements or equivalents. Always verify electrical and mechanical compatibility before substitution.
- 2097-V34PR6-LM (OEM Original) — Exact match; recommended for warranty-critical or safety-certified installations.
- 2097-V34PR3-LM — Same Kinetix 300 platform, lower continuous output (3A); suitable for lighter-load axes.
- 2097-V34PR12-LM — Higher current rating (12A continuous); drop-in upgrade for higher-torque applications.
- 2097-V31PR2-LM — Single-phase 120V input variant; use only when three-phase supply is unavailable.
- Kinetix 350 (2097-Vxxx series) — Next-generation platform with enhanced diagnostics; requires firmware and wiring review.
- Third-party equivalents (Yaskawa, Mitsubishi, Siemens) — Functional replacements possible with EtherNet/IP gateway adapters; engineering assessment required.
Why Choose the Original 2097-V34PR6-LM
- Native integration with Studio 5000 / RSLogix 5000 programming environment — zero additional configuration overhead.
- Plug-and-play compatibility with Allen-Bradley Kinetix servo motors (MPL, MPM, VPL series).
- Integrated STO (Safe Torque Off) eliminates external safety relay in most SIL 2 / PLd applications.
- Compact footprint reduces panel space by up to 30% vs. previous-generation drives.
- Rockwell Automation global support network and long-term spare parts availability.
Typical Applications
- Packaging machinery (form-fill-seal, cartoning, labeling)
- Conveyor and material handling systems
- CNC and multi-axis coordinated motion
- Printing and converting equipment
- Semiconductor and electronics assembly
- Food & beverage processing lines
System Compatibility
- Controllers: CompactLogix (1769-Lxx), ControlLogix (1756-Lxx), Micro820/Micro850 (via EtherNet/IP)
- Software: Studio 5000 Logix Designer v21+, Motion Analyzer, DriveExecutive
- Motors: Allen-Bradley MPL-Bxxxx, MPM-Bxxxx, VPL-Bxxxx servo motor families
- Network: EtherNet/IP (CIP Motion); supports linear and ring topologies
- Safety: Compatible with GuardLogix and SmartGuard safety controllers via hardwired STO
Selection Guide
Use the following criteria to confirm the 2097-V34PR6-LM is the correct drive for your application, or to identify the appropriate alternative:
- Step 1 — Supply Voltage: Confirm 240V AC three-phase availability. For 120V single-phase, select 2097-V31PR2-LM.
- Step 2 — Motor Current: Verify motor continuous and peak current ratings. The -PR6 suffix indicates 6A continuous / 18A peak. Upsize to -PR12 if motor peak exceeds 18A.
- Step 3 — Feedback Type: The -LM suffix denotes low-profile multi-turn absolute encoder support. Confirm motor feedback connector compatibility.
- Step 4 — Communication: EtherNet/IP is standard. If SERCOS or analog interface is required, evaluate Kinetix 6000/6200 series instead.
- Step 5 — Safety Level: STO (SIL 2 / PLd) is built-in. For SIL 3 / PLe requirements, consult Rockwell Automation safety engineering.
- Step 6 — Environment: IP20 rating requires clean, enclosed panel. For harsh environments, add appropriate enclosure (NEMA 12 or IP54 cabinet).
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Pre-shipment inspection: visual, label verification, and functional power-on test where applicable.
- Anti-counterfeit measures: holographic labels, serial number cross-check with manufacturer records.
- Packaging: original or equivalent ESD-safe packaging with moisture barrier and shock protection.
- Warranty: 12-month replacement warranty against manufacturing defects.
How to Order
- Online: Add to cart directly on this page and complete checkout.
- Quote Request: Email [email protected] with quantity, delivery timeline, and project details.
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 9:00–18:00 CST)
- Lead Time: In-stock items ship within 1–3 business days; sourced items 5–15 business days.
- Payment: T/T (Wire Transfer), PayPal, credit card via Shopify Payments.
- Export: Worldwide shipping available; DDP/DAP Incoterms supported.
Replacement & Compatibility FAQ
Q: Can I replace a 2097-V34PR6-LM with a 2097-V34PR12-LM without changing the motor?
A: Yes, provided the motor’s continuous current does not exceed 12A and peak does not exceed 36A. No firmware changes are required; re-tune the axis after replacement.
Q: Is the 2097-V34PR6-LM compatible with Kinetix 6000 motors?
A: Kinetix 6000 motors use a different feedback connector (Hiperface vs. low-profile). A feedback adapter cable (2090-XXNFMF-Sxx) may be required. Verify motor catalog number before ordering.
Q: What is the difference between 2097-V34PR6-LM and 2097-V34PR6?
A: The “-LM” suffix indicates the low-profile multi-turn absolute encoder interface. The non-LM variant supports incremental encoder only. Confirm your motor’s feedback type before substituting.
Q: Can this drive be used with a non-Rockwell PLC?
A: The drive communicates via standard EtherNet/IP (CIP Motion). Third-party PLCs with CIP Motion support (e.g., Omron NJ/NX series) may be compatible, but full functionality and safety integration require engineering validation.
Q: Do you provide a certificate of conformance (CoC)?
A: Yes. CoC and inspection reports are available upon request for all orders.
