Industrial HMI Solution – Allen-Bradley 2711P-T12C4A8 | PanelView Plus 6
The Allen-Bradley 2711P-T12C4A8 is a 12.1-inch color touch-screen HMI terminal from Rockwell Automation’s PanelView Plus 6 1250 series. Engineered for demanding industrial environments, it delivers real-time process visualization, operator control, and seamless integration with Allen-Bradley PLCs and ControlLogix/CompactLogix systems. Whether you are upgrading a legacy panel or commissioning a new production line, this terminal is the benchmark choice for plant-floor HMI applications worldwide.
Where This Product Is Used
- Automotive Manufacturing: Body-in-white welding lines, paint-shop conveyors, and final assembly stations rely on the 2711P-T12C4A8 for real-time torque monitoring and fault visualization.
- Food & Beverage Processing: Filling, capping, and pasteurization lines use this terminal to display batch recipes, CIP cycle status, and HACCP-critical temperature trends.
- Water & Wastewater Treatment: Pump stations, filtration skids, and SCADA-connected lift stations deploy it for remote operator interaction and alarm management.
- Oil & Gas Upstream/Midstream: Wellhead control panels and pipeline compressor stations use the terminal for pressure/flow visualization in Class I Div 2 enclosures.
- Pharmaceutical & Life Sciences: Validated batch manufacturing lines (21 CFR Part 11 environments) use it for electronic batch records and operator e-signatures.
- Material Handling & Logistics: Sortation systems, palletizers, and AS/RS warehouses use it as the primary operator interface for conveyor speed and zone control.
- Power Generation & Utilities: Substation control rooms and generator skids use it for real-time energy metering and protection relay status display.
Technical Specifications
| Part Number | 2711P-T12C4A8 |
| Series | PanelView Plus 6 1250 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Display Size | 12.1 in (307 mm) diagonal |
| Display Type | Color TFT LCD, Touch Screen |
| Resolution | 800 × 600 (SVGA) |
| Input Type | Analog Resistive Touch |
| Processor | Intel Celeron M 1.0 GHz |
| RAM | 512 MB DDR2 |
| Storage | 512 MB CompactFlash |
| Operating System | Windows CE 6.0 |
| Communication Ports | 2× USB 2.0, 1× RS-232, 1× Ethernet 10/100 Mbps |
| Supply Voltage | 24V DC (18–32V DC) |
| Power Consumption | ≤ 40 W |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Humidity | 5–95% RH (non-condensing) |
| Protection Rating | NEMA 4/4X, IP65 (front bezel) |
| Certifications | UL, CE, cUL |
| Weight | Approx. 3.2 kg |
| Panel Cutout | Refer to Rockwell publication 2711P-IN006 |
Why Engineers Specify This Model
- Native FactoryTalk View ME Integration: Runs FactoryTalk View Machine Edition natively — no gateway or protocol converter required for Allen-Bradley PLC networks.
- Proven NEMA 4/4X Sealing: Front-panel IP65 rating withstands washdowns, dust ingress, and high-pressure cleaning in food and pharma environments.
- 12.1-Inch Optimal Viewing Area: Large enough for multi-trend displays and alarm banners without requiring a full PC-based panel, reducing BOM cost.
- Dual USB for Peripheral Flexibility: Supports barcode scanners, USB drives for recipe/log transfer, and USB-to-serial adapters without additional hardware.
- Long Product Lifecycle: PanelView Plus 6 series has an extended support lifecycle from Rockwell, protecting capital investment in panel designs.
- Compact Flash Expandability: Field-replaceable CF card allows fast application restore and firmware updates without PC access.
Complete System Bill of Materials
- 2711P-T12C4A8 — PanelView Plus 6 1250 Touch Terminal (this unit)
- 2711P-RN15S — EtherNet/IP communication module (if required)
- 2711P-RN6 — DH-485 / RS-232 communication module
- 1756-L75 — ControlLogix L75 PLC (typical host controller)
- 1756-EN2T — EtherNet/IP bridge module for ControlLogix backplane
- 2711P-RSACDIN — DIN rail mounting adapter kit
- 2711P-B12C4A8 — Equivalent keypad-only variant (no touch)
- 1492-CABLE010X — Pre-wired I/O cable for panel integration
- 2711P-T12C4D8 — DC-powered variant with same display spec
Compliance & Industry Standards
- UL 508 — Industrial Control Equipment
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- NEMA 4 / NEMA 4X — Enclosure protection for indoor/outdoor use
- IEC 61131-2 — Programmable controllers: equipment requirements
- RoHS Compliant — Restriction of Hazardous Substances
- cUL Listed — Canadian safety certification
Quality Assurance & Sourcing
Every 2711P-T12C4A8 unit sourced through Konmask.com undergoes a documented inspection process:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware version verification against Rockwell Automation release notes
- Power-on functional test with display and touch calibration check
- Anti-static packaging with humidity indicator card
- Certificate of conformance available on request
We source from authorized distributors, OEM decommissions, and verified surplus channels. All units are traceable to original manufacturer documentation.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity and delivery timeline.
- Phone / WhatsApp: +0086 19859288691 — available for urgent sourcing inquiries.
- Lead Time: In-stock units ship within 3–5 business days; sourced units typically 7–15 business days.
- Export & Customs: We handle export documentation, HS code classification, and commercial invoices for international shipments.
- Payment: T/T bank transfer, PayPal, and trade assurance accepted.
Application-Specific FAQ
Q: Can the 2711P-T12C4A8 communicate directly with a CompactLogix PLC over EtherNet/IP?
A: Yes. With the built-in Ethernet port and FactoryTalk View ME, it communicates natively with CompactLogix (1769-L) and ControlLogix (1756-L) processors over EtherNet/IP without any additional modules.
Q: Is this terminal suitable for outdoor installations?
A: The front bezel is rated NEMA 4/4X (IP65), making it suitable for outdoor enclosures when the rear of the unit is protected from direct weather exposure. A NEMA 4X stainless enclosure is recommended for coastal or washdown environments.
Q: What FactoryTalk View ME version does this terminal support?
A: It supports FactoryTalk View ME v5.0 through v10.0. Always verify compatibility with your specific application version before deployment.
Q: Can I replace the CompactFlash card in the field?
A: Yes. The CF card is field-replaceable. Rockwell recommends using only approved CF cards listed in publication 2711P-IN006 to ensure reliable operation.
Q: Is the 2711P-T12C4A8 still in production?
A: Rockwell Automation has transitioned the PanelView Plus 6 series to end-of-life/limited availability status. Konmask.com maintains surplus stock to support ongoing maintenance and replacement needs.
Q: What is the difference between 2711P-T12C4A8 and 2711P-T12C4D8?
A: The suffix A8 denotes AC power input; D8 denotes DC power input (24V DC). All other specifications are identical.
