Industrial HMI Solution – Allen-Bradley 2711P-T6C20D | PanelView Plus 6 Series
Where This Product Is Used
The Allen-Bradley 2711P-T6C20D PanelView Plus 6 Terminal is the operator interface of choice across demanding industrial environments. Typical deployment scenarios include:
- Discrete Manufacturing Lines – Machine-level operator panels on assembly lines, CNC workstations, and robotic cells requiring real-time status visualization and parameter entry.
- Food & Beverage Processing – Hygienic-area control panels monitoring conveyor speed, fill levels, and batch recipes, integrated with CompactLogix or ControlLogix PLCs.
- Water & Wastewater Treatment – Pump station local HMI nodes displaying flow rates, valve positions, and alarm states in remote or unmanned installations.
- HVAC & Building Automation – Chiller plant and air-handling unit control panels requiring a compact 6.5″ footprint with Ethernet connectivity to a supervisory SCADA layer.
- Oil & Gas Skid Control – Skid-mounted operator interfaces for pressure, temperature, and flow monitoring in Class I Div 2 adjacent enclosures.
- Pharmaceutical & Life Sciences – Batch process HMI stations requiring audit-trail-capable operator input and FactoryTalk View ME runtime integration.
- Material Handling & Logistics – Sortation system control points, palletizer operator stations, and AGV dispatch panels.
Technical Specifications
| Part Number | 2711P-T6C20D |
| Series | PanelView Plus 6 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Display Size | 6.5″ Color TFT LCD |
| Display Resolution | 640 × 480 (VGA) |
| Touch Screen Type | Analog Resistive Touch |
| Input Voltage | 24V DC (18–32V DC) |
| Power Consumption | ≤ 30 W |
| Communication Ports | Ethernet 10/100 Mbps (RJ-45), RS-232 (DH-485 / DF1) |
| USB Ports | 2 × USB Type-A (host) |
| Memory | 512 MB Flash, 128 MB DRAM |
| Storage | CompactFlash slot (Type II) |
| Operating System | Windows CE 6.0 |
| Runtime Software | FactoryTalk View ME |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Relative Humidity | 5–95% non-condensing |
| Enclosure Rating | NEMA 4/4X, 12, 13 (front face); IP65 |
| Weight | Approx. 0.9 kg |
| Certifications | UL, CE, cUL, RoHS |
Why Engineers Specify This Model
- Seamless Rockwell Ecosystem Integration – Native EtherNet/IP and DF1 protocol support enables direct tag-based communication with ControlLogix, CompactLogix, MicroLogix, and SLC 500 controllers without gateway hardware.
- Compact 6.5″ Footprint – Ideal for space-constrained enclosures and machine-mounted panels where larger terminals are impractical.
- FactoryTalk View ME Runtime – Supports alarm management, trending, recipe management, and multi-language displays out of the box.
- Dual USB Host Ports – Simplify application transfers, firmware updates, and peripheral connections without opening the enclosure.
- NEMA 4X / IP65 Front Face – Suitable for wash-down and dusty environments without additional protective covers.
- Long Product Lifecycle – PanelView Plus 6 is a mature, widely supported platform with readily available spare parts and Rockwell TechConnect support contracts.
- CompactFlash Expandability – Enables extended data logging, recipe storage, and application backup on removable media.
Complete System Bill of Materials
For a fully operational HMI node based on the 2711P-T6C20D, engineers typically specify the following complementary components:
- 2711P-T6C20D – PanelView Plus 6 Terminal (this unit)
- 2711P-RN15S – EtherNet/IP communication module (dual-port topology)
- 2711P-RDT6 – Replacement display / touch screen assembly
- 1606-XLP30E – 24V DC / 1.25A power supply
- CompactFlash Card (Type II, industrial grade) – Application and data storage
- 2711P-CBL-EX04 – Serial extension cable for DH-485 / DF1
- 9701-VWSS100AENE – FactoryTalk View Studio ME development license
- Ethernet patch cable (Cat5e/Cat6, industrial rated) – EtherNet/IP network connection
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment (UL Listed)
- CE Marking – EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- cUL – Canadian Standards compliance
- NEMA 4 / 4X / 12 / 13 – Enclosure type ratings (front face)
- IP65 – Ingress protection per IEC 60529 (front face)
- RoHS Compliant – Restriction of Hazardous Substances Directive
- EtherNet/IP – ODVA conformance tested
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley 2711P-T6C20D unit is subject to rigorous quality controls before dispatch:
- Visual & Physical Inspection – Enclosure integrity, connector condition, label legibility, and absence of physical damage verified before listing.
- Functional Power-On Test – Unit powered at 24V DC; boot sequence confirmed prior to shipment where applicable.
- Authentic Sourcing – Units sourced from authorized distributors, certified surplus channels, or direct OEM supply chains. Counterfeit-risk screening applied to all inbound stock.
- Traceability – Lot and date codes recorded; available upon request for compliance documentation.
- Packaging – Anti-static packaging with foam cushioning; original manufacturer packaging retained where available.
How to Source This Part
Konmask.com maintains stock of the Allen-Bradley 2711P-T6C20D for immediate dispatch. To order or request a formal quotation:
- Online Order – Add to cart and proceed to checkout. Secure payment via major credit cards, wire transfer, and PayPal accepted.
- RFQ / Bulk Inquiry – Email support@konmask.com with required quantity, delivery timeline, and destination for a competitive quote within 24 hours.
- Phone / WhatsApp – Call or message +0086 19859288691 for urgent requirements or technical pre-sales questions.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock units sourced within 5–15 business days.
- Export & Customs – Export documentation, commercial invoices, and packing lists handled for international shipments. DDP and DAP Incoterms available.
Application-Specific FAQ
Q: Is the 2711P-T6C20D compatible with CompactLogix 5370 controllers?
A: Yes. Via EtherNet/IP, the 2711P-T6C20D communicates natively with all CompactLogix 5370 (L1–L3) controllers using tag-based addressing in FactoryTalk View ME.
Q: Can this terminal run FactoryTalk View ME version 10 or later?
A: The 2711P-T6C20D supports FactoryTalk View ME up to version 10.x. Verify firmware revision compatibility in Rockwell publication 2711P-TD001 for the latest supported runtime version.
Q: What is the difference between 2711P-T6C20D and 2711P-T6C20D8?
A: The suffix “8” denotes a unit pre-loaded with additional application memory or a specific firmware bundle. Both share the same hardware platform. Confirm application memory requirements before ordering.
Q: Is this unit suitable for Class I Division 2 hazardous locations?
A: The standard 2711P-T6C20D is not rated for Class I Div 2 out of the box. For hazardous location installations, consult Rockwell Automation for an appropriate purge-and-pressurization enclosure solution or specify a Div 2 rated variant.
Q: Can I replace the touch screen assembly in the field?
A: Yes. The replacement display/touch assembly (catalog number 2711P-RDT6) is a field-replaceable unit. Refer to Rockwell Automation installation instructions publication 2711P-IN006 for the procedure.
Q: What communication protocols does the 2711P-T6C20D support?
A: EtherNet/IP (primary), DF1 Full-Duplex, DF1 Half-Duplex Master/Slave, DH-485, and DH+ (via 2711P-RN6 module). Compatible with legacy SLC 500 and PLC-5 systems as well as modern Logix platforms.
