Applied Materials 0040-76219 Pin Plate | Replacement, Equivalent & Selection Guide
The Applied Materials 0040-76219 Pin Plate is a precision mechanical component used in Applied Materials semiconductor processing equipment. Cross-reference part numbers: 0040-76220 | IM805-NR1 | 02-35348 | 50020R-10 | 810-002895-201. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Part Number (Primary): 0040-76219
- Cross-Reference / Alternate SKUs: 0040-76220 | IM805-NR1 | 02-35348 | 50020R-10 | 810-002895-201
- Description: Pin Plate
- OEM Brand: Applied Materials (AMAT)
- Component Category: Mechanical / Structural — Wafer Handling
- Weight: ~20 g
- Condition Available: New OEM, Refurbished, Equivalent Aftermarket
- Export Control: Please confirm ECCN classification with your compliance team prior to international shipment
Compatible Replacement & Equivalent Models
The following part numbers are confirmed cross-references or functional equivalents for the 0040-76219 Pin Plate. Always verify dimensional and material compatibility before installation:
- 0040-76220 — Direct AMAT alternate part number; same form/fit/function
- IM805-NR1 — Vendor-coded equivalent; verify pin pitch and plate thickness
- 02-35348 — Legacy reference number used in older BOM revisions
- 50020R-10 — Aftermarket equivalent; confirm material grade (typically 6061-T6 or 304 SS)
- 810-002895-201 — Assembly-level reference; may include additional sub-components
Note: Konmask.com recommends confirming compatibility with your equipment’s current BOM revision before substituting any cross-reference part.
Why Choose the Original Model
- OEM Precision: Manufactured to Applied Materials’ exact dimensional tolerances, ensuring proper wafer lift-pin alignment and repeatability
- Material Certification: OEM parts ship with full material traceability and compliance documentation
- Warranty Integrity: Using original AMAT parts preserves equipment warranty and service agreement terms
- Process Stability: Reduces risk of particle generation or pin misalignment that can cause wafer breakage or yield loss
- Long-Term Availability: Konmask.com maintains stock of both OEM and qualified equivalents to minimize downtime
Typical Applications
- Applied Materials CVD (Chemical Vapor Deposition) systems — wafer lift-pin assemblies
- Applied Materials Centura and Endura platform process chambers
- Wafer transfer and handling modules requiring precision pin plate alignment
- Preventive maintenance (PM) kits for AMAT process chambers
- Spare parts inventory for semiconductor fab equipment maintenance teams
System Compatibility
- Applied Materials Centura® Platform (various process modules)
- Applied Materials Endura® Platform
- Applied Materials Producer® CVD System
- Compatible with systems referencing BOM part 0040-76219 or any listed cross-reference SKU
Always cross-check against your equipment’s current illustrated parts catalog (IPC) or BOM before ordering.
Selection Guide
Use the decision criteria below to select the right part for your application:
- Need OEM traceability & documentation? → Order 0040-76219 (original AMAT part)
- Need a cost-effective alternative with same form/fit? → Consider 0040-76220 or 50020R-10 aftermarket equivalent
- Working from an older BOM revision? → Cross-reference 02-35348 or IM805-NR1 to confirm current active part number
- Ordering for an assembly kit? → Reference 810-002895-201 and confirm sub-component inclusion
- Unsure which variant fits your chamber revision? → Contact Konmask.com with your equipment serial number for a verified recommendation
Quality Assurance & Sourcing
- All parts sourced through authorized distributors or certified secondary-market suppliers
- Incoming inspection performed on refurbished and aftermarket equivalents
- Packaging: anti-static bag + foam-lined box; labeled with part number and lot traceability
- Certificate of Conformance (CoC) available upon request
- RoHS and REACH compliance documentation available for applicable parts
How to Order
- Online: Add to cart directly from this page — stock availability shown in real time
- RFQ / Bulk: Email support@konmask.com with quantity, required delivery date, and equipment model
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock orders ship within 1–3 business days; special orders quoted individually
- Export: International shipping available — please confirm export compliance requirements for your destination country
Replacement & Compatibility FAQ
Q: Is 0040-76220 a direct drop-in replacement for 0040-76219?
A: Yes, in most chamber configurations these are interchangeable. Verify with your equipment’s current IPC to confirm no revision-specific differences.
Q: Can I use an aftermarket pin plate (e.g., 50020R-10) without voiding my service contract?
A: This depends on your service agreement with Applied Materials. Consult your service contract terms. Konmask.com can supply OEM parts if contract compliance is required.
Q: What material is the pin plate made from?
A: Typically aluminum alloy (6061-T6) or 304 stainless steel depending on the chamber environment. Confirm with the part’s CoC or contact us for material certification.
Q: Do you offer expedited shipping for critical tool-down situations?
A: Yes. Contact us immediately at +0086 19859288691 or support@konmask.com and we will prioritize your order.
Q: How do I verify the correct part for my specific chamber revision?
A: Provide your equipment serial number and chamber module type when contacting us — our team will cross-reference against the applicable IPC revision.
