Industrial HMI Solution – Beckhoff CP6902-0001-0000 | CP69xx Series
Where This Product Is Used
The Beckhoff CP6902-0001-0000 Operator Panel is engineered for demanding industrial environments where reliable human-machine interaction is critical. Typical deployment scenarios include:
- Machine Tool Control – CNC machining centers, grinding machines, and multi-axis milling systems requiring real-time status visualization and parameter input.
- Packaging & Filling Lines – High-speed FMCG and pharmaceutical packaging lines where operators need instant access to line speed, batch data, and alarm management.
- Building Automation & HVAC – Central control panels for BMS systems managing HVAC, lighting, and energy metering across large facilities.
- Water & Wastewater Treatment – Pump station HMI nodes integrated with Beckhoff TwinCAT SCADA for remote monitoring and control.
- Automotive Assembly – Panel-mount operator stations on robotic welding and press lines requiring IP-rated, vibration-resistant interfaces.
- Renewable Energy – Wind turbine nacelle control panels and solar inverter monitoring stations.
Technical Specifications
| Part Number | CP6902-0001-0000 |
| Brand | Beckhoff Automation |
| Series | CP69xx Control Panel |
| Product Type | Industrial Operator Panel / HMI |
| Interface | DVI-I + USB (keyboard/mouse emulation) |
| Connection | Beckhoff DVI/USB extended display interface |
| Protection Rating | IP65 front panel |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +85 °C |
| Mounting | Panel cut-out, portrait or landscape |
| Weight | Approx. 1.0 kg |
| Compatibility | Beckhoff Industrial PCs (IPC), TwinCAT 2/3 |
Why Engineers Specify This Model
- Passive Panel Design – No active components in the panel head; all processing handled by the connected IPC, eliminating panel-side heat and fan noise.
- Extended Cable Runs – DVI/USB interface supports cable lengths up to 50 m, enabling flexible cabinet-to-panel layouts in large machinery.
- IP65 Front Sealing – Suitable for wash-down environments in food & beverage and pharmaceutical production.
- TwinCAT Native Integration – Plug-and-play with Beckhoff TwinCAT 2 and TwinCAT 3 runtime; no additional driver configuration required.
- Consistent CP69xx Ecosystem – Shares mounting dimensions and accessories with the broader CP69xx family, simplifying multi-panel machine designs.
- Long Product Lifecycle – Beckhoff’s industrial product commitment ensures spare part availability for 10+ years.
Complete System Bill of Materials
For a fully operational Beckhoff panel-based control system using the CP6902-0001-0000, engineers typically specify:
- Beckhoff Industrial PC (e.g., C6015, C6025, or C6030 series) – processing unit
- Beckhoff DVI/USB extension cable (ZK7000-xxxx) – panel connection cable
- Beckhoff TwinCAT 3 Engineering License (TC1200) – PLC runtime
- Beckhoff EtherCAT I/O Terminals (EK1100 + EL series) – field I/O
- 24 VDC DIN-rail power supply (e.g., Beckhoff PS2000) – panel power
- Panel mounting hardware and gasket kit (CP69xx accessory set)
Compliance & Industry Standards
- CE Marking – EU Machinery Directive 2006/42/EC compliant
- UL Listed – suitable for North American industrial installations
- RoHS 2 (2011/65/EU) – restricted hazardous substances compliant
- EN 61131-2 – programmable controller equipment standard
- IEC 60068 – environmental testing (temperature, vibration, humidity)
Quality Assurance & Sourcing
Konmask.com sources the Beckhoff CP6902-0001-0000 exclusively through verified industrial distribution channels. Every unit undergoes:
- Visual and dimensional inspection against Beckhoff factory specifications
- Firmware and label authenticity verification
- ESD-safe packaging and climate-controlled storage
- Full traceability documentation available on request
We maintain buffer stock of high-demand Beckhoff CP69xx panels to support urgent MRO and project procurement timelines.
How to Source This Part
- Request a Quote – Email support@konmask.com with your required quantity and delivery timeline.
- Bulk / Project Orders – Volume pricing available for OEM integrators and EPC contractors. Contact us for a project BOM review.
- Urgent MRO – Same-day quotation for emergency replacement orders. Call +0086 19859288691.
- Global Shipping – DHL Express, FedEx, and sea freight options available. Export documentation (CO, packing list, commercial invoice) provided.
Application-Specific FAQ
Q: Can the CP6902-0001-0000 be used with non-Beckhoff IPCs?
A: The panel uses a standard DVI-I video signal and USB HID interface. While optimized for Beckhoff IPCs, it can function as a display/input device with any PC supporting DVI output, though TwinCAT-specific features require a Beckhoff IPC.
Q: What is the maximum cable length between the IPC and this panel?
A: Beckhoff supports up to 50 m using their certified ZK7000 DVI/USB extension cables. Third-party active extenders may support longer runs but are not officially validated.
Q: Is this panel suitable for outdoor installations?
A: The front panel is IP65-rated (dust-tight, water jet resistant), but the rear enclosure requires additional protection for direct outdoor exposure. A NEMA 4 or IP66 enclosure is recommended for outdoor deployments.
Q: What TwinCAT version is required?
A: The CP6902-0001-0000 is compatible with both TwinCAT 2 and TwinCAT 3. No panel-specific software configuration is required beyond standard display settings in the IPC.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 12-month warranty on all Beckhoff products against manufacturing defects. Extended warranty and service contracts are available on request.
