Vibration Monitoring Solution – Bently Nevada 130539-50 Interconnect Cable | 3500 Series
In rotating machinery protection, signal integrity between the proximity transducer and the monitoring rack is non-negotiable. The Bently Nevada 130539-50 Interconnect Cable is the OEM-specified 50 ft coaxial extension cable engineered for the 3500 Series Machinery Protection System, delivering low-loss signal transmission in the most demanding industrial environments. When a turbine, compressor, or pump shaft deviates by even a few microns, this cable ensures that deviation is captured — accurately, reliably, every time.
Where This Product Is Used
The 130539-50 is deployed wherever Bently Nevada 3500 Series proximity systems are installed for continuous machinery health monitoring:
- Gas & Steam Turbines — shaft radial vibration and axial position monitoring at power generation facilities
- Centrifugal Compressors — rotor dynamic monitoring in petrochemical and LNG plants
- Pumps & Fans — bearing condition monitoring in water treatment and HVAC systems
- Gearboxes — high-speed shaft monitoring in paper mills and steel rolling lines
- Marine Propulsion Systems — shaft alignment and vibration monitoring on vessels
- Nuclear & Fossil Power Plants — safety-critical turbine protection loops
Wherever API 670 compliance is mandated and signal fidelity is critical, the 130539-50 is the specified interconnect solution.
Technical Specifications
| Part Number | 130539-50 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Series | 3500 Machinery Protection System |
| Cable Type | Coaxial Interconnect / Extension Cable |
| Cable Length | 50 ft (15.24 m) |
| Connector Type | BNC / TNC (OEM-matched to 3300 XL proximity system) |
| Impedance | 50 Ω nominal |
| Operating Temperature | -40°C to +85°C |
| Jacket Material | Polyurethane / Armored sheath (environment-rated) |
| Compatible Drivers | 3300 XL 8mm, 11mm, 14mm proximity transducer systems |
| System Compatibility | Bently Nevada 3500/40M, 3500/42M, 3500/45, 3500/46M monitors |
| Weight | 620 g (approx.) |
| Country of Origin | United States |
Why Engineers Specify This Model
- OEM Signal Integrity — Matched impedance and capacitance characteristics preserve the eddy-current driver’s calibrated output, eliminating measurement drift caused by third-party cable substitutions.
- 50 ft Reach — Bridges the gap between field-mounted transducers and remote junction boxes or rack rooms without signal degradation.
- Harsh Environment Rated — Polyurethane jacket resists oil, moisture, and mechanical abrasion in turbine halls and compressor stations.
- API 670 Compliant System Component — Ensures the complete proximity system assembly meets the Machinery Protection Systems standard required by EPC contractors and plant operators.
- Drop-in Replacement — Identical form, fit, and function to original factory cable; no recalibration required upon installation.
- Reduced Downtime Risk — Stocking this cable as a critical spare eliminates multi-week OEM lead times during unplanned outages.
Complete System Bill of Materials
The 130539-50 operates as part of a complete Bently Nevada proximity measurement chain. A typical BOM includes:
- Proximity Transducer — e.g., 330780-50-00 (8mm), 330930-080-00-00 (11mm)
- Extension Cable (this item) — 130539-50 (50 ft)
- Proximitor® Driver — e.g., 3300 XL 8mm Proximitor (330180-91-00)
- Monitor Module — 3500/40M, 3500/42M, or 3500/45 Position Monitor
- Rack & Power Supply — 3500/05 Rack, 3500/15 Power Supply
- I/O Module — 3500/92 Communication Gateway (optional)
Contact Konmask for complete system sourcing and BOM verification support.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition)
- ISO 10816 / ISO 20816 — Mechanical vibration measurement and evaluation
- IEC 61511 — Functional safety for process industry sectors (SIL-rated loop compatibility)
- CE Marking — European conformity for industrial electrical equipment
- RoHS Compliant — Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask.com sources the Bently Nevada 130539-50 exclusively through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual and dimensional inspection against OEM datasheet
- Connector continuity and impedance verification
- Authenticity check — serial number and label verification against Bently Nevada / Baker Hughes records
- Anti-static packaging with humidity indicator card
- Certificate of Conformance (CoC) available upon request
We do not supply refurbished, repaired, or counterfeit components. All stock is traceable to authorized distribution.
How to Source This Part
- Submit an RFQ — Email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quote — We respond within 24 business hours with pricing, lead time, and availability confirmation.
- Place Your Order — Purchase via our secure online checkout or by proforma invoice for B2B accounts.
- Inspection & Dispatch — Parts are inspected, documented, and shipped with full traceability documentation.
- Delivery — DHL / FedEx Express worldwide; EXW, CIF, and DAP Incoterms available.
Application-Specific FAQ
Q: Can the 130539-50 be used with non-Bently Nevada monitors?
A: The cable is designed for Bently Nevada 3300 XL proximity systems. Using it with third-party monitors may affect calibration and is not recommended for API 670-compliant installations.
Q: What is the difference between 130539-50 and 330130-50-00?
A: The 130539-50 is the standard interconnect extension cable; the 330130-50-00 is a different cable assembly variant. Always verify your system drawing before ordering. Konmask’s technical team can assist with cross-referencing.
Q: Is a 50 ft cable too long for my installation? Can I get a shorter version?
A: Bently Nevada offers multiple cable lengths. Contact us with your required length and we will identify the correct part number for your application.
Q: Do you provide documentation for customs clearance?
A: Yes. We provide commercial invoice, packing list, CoC, and HS code documentation (HS: 8544.42) for all international shipments.
Q: What is the lead time for the 130539-50?
A: In-stock units ship within 3–5 business days. Out-of-stock lead time is typically 4–8 weeks from authorized distribution. Contact us for current availability.
