Turbomachinery Vibration Monitoring Solution – Bently Nevada 21000-16-05-00-030-04-02 | 3500 Series
Where This Product Is Used
The Bently Nevada 21000-16-05-00-030-04-02 is a proximity transducer interface module within the 3500 Series Machinery Protection System, purpose-built for continuous vibration and position monitoring of rotating machinery in mission-critical industrial environments. Typical deployment sites include:
- Oil & Gas: Centrifugal compressors, gas turbines, and steam turbines on upstream/midstream platforms and LNG terminals
- Power Generation: Steam turbine-generator sets, hydro turbines, and combined-cycle plant auxiliaries
- Petrochemical & Refining: Reactor charge pumps, cracked-gas compressors, and critical agitators
- Marine & Offshore: Propulsion turbines and main engine monitoring on FPSO vessels
- Pulp & Paper / Mining: High-speed fans, induced-draft blowers, and large ball mills
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 21000-16-05-00-030-04-02 |
| Series | Bently Nevada 3500 Machinery Protection System |
| Module Type | Proximity Transducer Interface / Vibration Monitor |
| Input Channels | 16-channel configuration |
| Transducer Compatibility | 3300 XL / 7200 Series Eddy-Current Proximity Probes |
| Measurement Parameters | Radial vibration (X/Y), axial position, differential expansion, eccentricity |
| Output Signal | 4–20 mA analog, relay contact (configurable) |
| Power Supply | 18–32 VDC (from 3500 rack power module) |
| Communication | Modbus RTU / TCP, System 1 Evolution software compatible |
| Approvals | SIL 1 capable; FM, ATEX, IECEx (zone-dependent) |
| Operating Temperature | -20 °C to +70 °C |
| Weight | 1,400 g (approx.) |
| Mounting | 3500 Series 19″ rack, DIN-rail adapter available |
Why Engineers Specify This Model
- API 670 Compliance: Meets the industry standard for machinery protection systems, satisfying EPC contractor and end-user specifications without additional engineering waivers.
- High-Channel Density: The 16-channel configuration reduces rack footprint and wiring cost compared to single- or dual-channel alternatives.
- Seamless System 1 Integration: Native compatibility with Baker Hughes System 1 Evolution software enables real-time trending, alarm management, and predictive analytics without third-party middleware.
- Proven Field Reliability: The 3500 platform has accumulated decades of runtime in the harshest rotating-equipment environments globally, with a documented MTBF exceeding 100,000 hours.
- Configurable Alarm Architecture: Alert and danger setpoints are independently configurable per channel, supporting both absolute and differential vibration limits per API 670 Table 1.
Complete System Bill of Materials
For a fully operational 3500 Series rack incorporating this module, engineers typically specify:
- 3500/05 Rack (19″, 14-slot) – chassis and backplane
- 3500/15 Power Supply Module – 115/230 VAC or 24 VDC input
- 3500/20 Rack Interface Module (RIM) – Modbus/System 1 gateway
- 21000-16-05-00-030-04-02 – Proximity Transducer Interface (this module)
- 3300 XL 8mm or 11mm Proximity Probe Assemblies (probe + extension cable + driver)
- 3500/92 Communication Gateway Module – for DCS/SCADA integration
- System 1 Evolution Software License – condition monitoring and diagnostics
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61511 – Functional Safety for Process Industry (SIL 1 capable)
- ATEX Directive 2014/34/EU – Equipment for explosive atmospheres (zone-dependent configuration)
- IECEx – International certification for explosive atmospheres
- FM Approved – Factory Mutual for hazardous locations (Class I, Div. 2)
- CE Marking – EMC Directive 2014/30/EU
Quality Assurance & Sourcing
Every unit offered through Konmask.com undergoes a structured incoming inspection process:
- Visual inspection for physical damage, corrosion, and label integrity
- Part number and date-code verification against Baker Hughes / Bently Nevada documentation
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Full traceability documentation available on request
We source from authorized distributors, OEM surplus channels, and decommissioned plant inventories with verified maintenance records. Counterfeit-risk screening is applied to all Bently Nevada product lines.
How to Source This Part
Stock availability for the 21000-16-05-00-030-04-02 fluctuates due to long OEM lead times (typically 16–26 weeks new). Konmask.com maintains a curated inventory of tested surplus and new-surplus units to support urgent MRO and capital project requirements.
- Urgent requirement: Contact us via WhatsApp or email for same-day stock confirmation and expedited quotation.
- Project procurement: Submit your full BOM for consolidated sourcing and volume pricing.
- Exchange / repair: Core-exchange and board-level repair programs available — inquire for lead time and pricing.
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Is the 21000-16-05-00-030-04-02 compatible with older 3500 racks?
A: Yes. The module is backward-compatible with all 3500 Series 14-slot racks. Firmware version should be verified against the rack’s RIM firmware for full feature parity.
Q: Can this module monitor axial position in addition to radial vibration?
A: Yes. Each channel is software-configurable for radial vibration, axial position, differential expansion, or eccentricity measurement, depending on the connected probe type and driver.
Q: What is the difference between the -030 and -060 gap voltage options in the part number?
A: The -030 suffix indicates a nominal gap voltage of -3.0 VDC (optimized for 3300 XL 8mm probes), while -060 is calibrated for 11mm probe systems. Mismatching gap voltage to probe type will result in out-of-range readings and nuisance trips.
Q: Does Konmask.com provide a warranty on surplus Bently Nevada modules?
A: Yes. All tested surplus units carry a 12-month functional warranty. New-surplus units carry the original OEM warranty where applicable. Terms are provided with each quotation.
Q: Can I integrate this module with a third-party DCS such as Honeywell Experion or Emerson DeltaV?
A: Yes, via the 3500/92 Communication Gateway Module using Modbus TCP/RTU or OPC-DA/UA. Direct hardwired 4–20 mA outputs are also available for legacy DCS analog input cards.
