Bently Nevada 21000-16-10-00-297-03-02 – Proximity Probe Housing Assembly | 3300 XL Series Platform
Engineering Background
The Bently Nevada 3300 XL Series represents the industry benchmark for continuous machinery protection in rotating equipment applications. Developed by Baker Hughes (Bently Nevada), this platform has been deployed globally across power generation, oil & gas, petrochemical, and heavy industrial facilities where unplanned downtime carries catastrophic operational and financial consequences.
Product Positioning
The 21000-16-10-00-297-03-02 is a precision-engineered proximity probe housing assembly designed to mechanically protect and accurately position eddy-current proximity probes in high-vibration, high-temperature machinery environments. It provides the structural interface between the probe tip and the monitored shaft, ensuring consistent gap distance, signal integrity, and long-term measurement reliability. This component is a direct OEM-equivalent replacement for installed 3300 XL system infrastructure.
Complete Technical Specifications
| Part Number | 21000-16-10-00-297-03-02 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Series / Platform | 3300 XL Proximity Transducer System |
| Component Type | Proximity Probe Housing Assembly |
| Sensing Technology | Eddy-Current (Non-contact) |
| Compatible Probe Series | 3300 XL 8mm / 11mm Proximity Probes |
| Thread Specification | Per OEM drawing (M10 / 3/8-24 UNF typical) |
| Housing Material | 316 Stainless Steel (corrosion-resistant) |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
| Ingress Protection | IP67 (sealed assembly) |
| Mounting Configuration | Threaded boss / bracket mount |
| Cable Exit | Integral armored extension cable compatible |
| Weight | Approx. 1,080 g (assembly) |
| Country of Origin | United States |
| HS Code | 9031.80.9090 |
| Compliance | API 670, CE, RoHS |
Proven Application Environments
- Power Generation: Steam turbines, gas turbines, hydro generators — radial and axial vibration monitoring
- Oil & Gas: Compressor trains, centrifugal pumps, expanders — continuous shaft displacement measurement
- Petrochemical / Refining: Critical rotating machinery per API 670 machinery protection requirements
- Marine & Offshore: Propulsion shafting and auxiliary machinery in harsh salt-air environments
- Pulp & Paper / Steel: High-speed rolls, fans, and blowers requiring non-contact vibration sensing
- Nuclear / Utility: Safety-critical turbine-generator sets with continuous online monitoring
Engineering Advantages
- OEM-Equivalent Fit: Direct mechanical replacement for existing 3300 XL installations — no re-engineering or adapter required
- Signal Integrity Preservation: Precision-machined bore maintains probe-to-shaft gap tolerance within ±0.025 mm
- Corrosion Resistance: 316 SS construction withstands process fluids, steam, and aggressive atmospheres
- Vibration Immunity: Rigid housing design eliminates probe resonance artifacts in high-frequency measurement environments
- Sealed Construction: IP67 rating prevents moisture ingress that would degrade eddy-current field linearity
- Long Service Life: Designed for continuous 24/7 operation in API 670-compliant machinery protection systems
System Architecture & Signal Flow
The 21000-16-10-00-297-03-02 housing assembly integrates into the complete Bently Nevada 3300 XL transducer chain as follows:
- Probe Tip (housed within this assembly) → generates eddy-current field directed at rotating shaft target
- Extension Cable → transmits raw oscillator signal from probe to proximitor
- Proximitor / Oscillator-Demodulator (3300 XL) → converts gap distance to DC voltage output (typically −18 VDC nominal)
- 3500 / 3300 Monitor Rack → processes voltage signal for alarm, trip, and trending functions
- DCS / SCADA Integration → 4–20 mA or digital output to plant control system
Correct housing installation is critical: probe gap must be set to OEM-specified linear range (typically 1.0–2.0 mm) using a calibrated gap tool before commissioning.
Sourcing & Quality Verification
- Source: Authorized surplus and OEM-traceable supply channels; no counterfeit or grey-market stock
- Inspection: Each unit undergoes visual inspection, dimensional verification, and functional continuity check prior to shipment
- Documentation: Certificate of conformance (CoC) and original packaging available upon request
- Traceability: Lot and date codes recorded; full chain-of-custody documentation available for regulated industries
- Warranty: 12-month operational warranty against manufacturing defects
Procurement Process
- Confirm Part Number: Verify 21000-16-10-00-297-03-02 against your BOM or existing installation tag
- Request Quote: Contact support@konmask.com or call +0086 19859288691 for volume pricing and lead time
- Submit PO: Standard NET 30 terms available for qualified industrial accounts; T/T, L/C accepted
- Expedited Shipping: DHL / FedEx express available for AOG (Aircraft/Asset on Ground) critical situations
- Technical Support: Pre-sale and post-sale engineering support included at no charge
Technical FAQ
Q: Is this a genuine Bently Nevada OEM part?
A: Yes. All units are sourced from OEM-traceable supply chains. CoC documentation is available upon request.
Q: What probe models are compatible with this housing?
A: This housing is designed for the Bently Nevada 3300 XL 8mm and 11mm proximity probe series. Verify thread and cable exit compatibility with your installation drawing before ordering.
Q: Can this housing be used in hazardous (Ex) classified areas?
A: Consult the OEM ATEX/IECEx certification documentation for your specific installation zone. Contact us for certified variants if required.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. Contact us for current inventory status.
Q: Do you provide installation and commissioning support?
A: Yes. Our engineering team provides remote technical guidance for gap setting, cable routing, and system integration at no additional cost.
