Vibration Monitoring Solution – Bently Nevada 31000-16-10-15-201-02-02 | 3300 XL Series
The Bently Nevada 31000-16-10-15-201-02-02 is a precision-engineered Proximity Probe Housing Assembly designed for continuous, non-contact shaft vibration and position measurement in rotating machinery. As a core component of the Bently Nevada 3300 XL Series eddy-current measurement system, this housing assembly ensures accurate, repeatable sensor positioning in demanding industrial environments.
Where This Product Is Used
This proximity probe housing assembly is specified by rotating machinery engineers across the following critical applications:
- Steam & Gas Turbines – Shaft radial vibration monitoring on high-speed turbine rotors in power generation plants
- Centrifugal Compressors – Continuous rotor displacement measurement in petrochemical and refinery compressor trains
- Pumps & Fans – Bearing journal orbit monitoring in large process pumps and induced-draft fans
- Gearboxes – Gear mesh and shaft position tracking in critical drive trains
- Marine Propulsion Systems – Shaft alignment and axial position monitoring in ship propulsion shafts
- Paper & Steel Mills – Roll and spindle vibration measurement in continuous process machinery
Technical Specifications
- Part Number: 31000-16-10-15-201-02-02
- Series: Bently Nevada 3300 XL Proximity Transducer System
- Type: Proximity Probe Housing Assembly
- Sensing Technology: Eddy-current (non-contact)
- Thread Size: 3/8-24 UNF (standard Bently Nevada probe thread)
- Housing Material: Stainless steel with corrosion-resistant finish
- Cable Length: Per configuration code (see part number suffix)
- Temperature Range: –40°C to +177°C (probe tip); electronics per driver spec
- Ingress Protection: Suitable for oil-mist and high-humidity environments
- Weight: Approx. 1,200 g (complete assembly)
- Compatibility: 3300 XL 8mm Proximity Transducer System; compatible drivers 3300 XL, 3500/42M
Why Engineers Specify This Model
- Drop-in Replacement: Exact OEM form, fit, and function – no recalibration of the monitoring system required
- API 670 Compliant: Meets the machinery protection standard mandated by most EPC contractors and plant operators
- Proven Field Reliability: Bently Nevada 3300 XL systems are installed on tens of thousands of machines worldwide
- Stainless Steel Housing: Resists corrosion in wet, oily, and chemically aggressive environments
- Precision Gap Setting: Machined housing ensures repeatable probe-to-target gap for consistent sensitivity (200 mV/mil, 7.87 V/mm)
- Long Service Life: No moving parts; solid-state eddy-current technology with MTBF exceeding 100,000 hours
Complete System Bill of Materials
For a fully operational 3300 XL proximity measurement channel, the following components are typically required:
- Proximity Probe: Bently Nevada 330103 / 330104 / 330105 series (8 mm)
- Housing Assembly: 31000-16-10-15-201-02-02 (this item)
- Extension Cable: Bently Nevada 330130 series (armored, field-selectable length)
- Proximitor® Driver/Oscillator: Bently Nevada 3300 XL 8mm Proximitor (e.g., 330180)
- Rack Monitor Module: Bently Nevada 3500/42M Proximitor/Seismic Monitor
- I/O Module: 3500/42M I/O (Keyphasor, radial, or axial per channel config)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- API 670 Annex D – Eddy-current transducer system performance verification
- IEC 61511 – Functional safety for process industry sectors (SIL-capable installations)
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation of machinery
- ATEX / IECEx – Hazardous area certification available per configuration (verify suffix codes)
Quality Assurance & Sourcing
Konmask.com sources Bently Nevada components through verified industrial automation supply channels. Every unit undergoes the following before shipment:
- Visual and dimensional inspection against OEM drawings
- Part number and label verification
- Functional continuity check (where applicable)
- Secure anti-static packaging with humidity indicator card
- Certificate of conformance available upon request
We maintain traceability records for all Bently Nevada parts and can provide documentation packages for regulated industries (oil & gas, nuclear, power generation).
How to Source This Part
- In Stock: Ready to ship within 1–3 business days from our warehouse
- Lead Time (if out of stock): Typically 2–4 weeks via our supplier network
- Minimum Order: 1 unit
- Bulk Pricing: Available for orders of 5+ units – contact us for a quote
- Export: We ship worldwide; DDP/DAP Incoterms available for most destinations
- Documentation: Commercial invoice, packing list, CoC, and HS code 9026.80 declaration included
To place an order or request a formal quotation, email [email protected] or call +0086 19859288691.
Application-Specific FAQ
Q: Is 31000-16-10-15-201-02-02 a direct replacement for older Bently Nevada probe housings?
A: Yes. This part is designed as a direct OEM-equivalent replacement within the 3300 XL system architecture. Verify your existing probe thread and cable length suffix before ordering.
Q: Can this housing be used with non-Bently Nevada probes?
A: The housing is machined to Bently Nevada 3/8-24 UNF probe thread specifications. Third-party probes with matching thread and tip diameter may physically fit, but system calibration and API 670 compliance must be re-verified.
Q: What is the correct gap voltage for this assembly?
A: The standard 3300 XL 8mm system targets a –10 VDC quiescent gap voltage at the nominal gap (typically 1.0 mm / 40 mil). Refer to Bently Nevada document 141078-01 for full gap/voltage tables.
Q: Do you supply the complete 3300 XL channel kit?
A: Yes. We can source the full BOM including probe, extension cable, Proximitor driver, and rack modules. Contact us with your channel count and configuration for a bundled quote.
Q: Is this part available with ATEX certification?
A: ATEX/IECEx variants are available depending on the part number suffix. Please confirm your hazardous area classification (Zone 1/2, gas group, temperature class) when inquiring.
