Turbine & Compressor Vibration Monitoring Solution — Bently Nevada 31000-28-05-15-030-00-02 | 3300 Series
The Bently Nevada 31000-28-05-15-030-00-02 is a precision-engineered Proximity Probe Housing Assembly from the industry-standard 3300 Series eddy current system. Designed for continuous, non-contact shaft vibration and position measurement, this assembly is the preferred choice of rotating machinery engineers worldwide for critical turbomachinery protection and condition monitoring.
Where This Product Is Used
This proximity probe housing assembly is deployed across the most demanding rotating machinery environments in heavy industry:
- Steam & Gas Turbines — Radial vibration and axial position monitoring on HP/LP turbine shafts in power generation plants
- Centrifugal Compressors — Shaft orbit and differential expansion measurement in petrochemical and LNG facilities
- Pumps & Fans — Continuous bearing health monitoring in water treatment and HVAC critical systems
- Gearboxes — Eccentricity and runout detection in high-speed industrial gearboxes
- Marine Propulsion Systems — Shaft vibration surveillance on vessel main engines and auxiliary drives
- Paper & Steel Mills — Roll and drive shaft monitoring in continuous process lines
Technical Specifications
- Part Number: 31000-28-05-15-030-00-02
- Series: Bently Nevada 3300 XL / 3300 Series
- Type: Proximity Probe Housing Assembly (Eddy Current)
- Probe Diameter: 8 mm (standard)
- Cable Length: 5 m (extension cable included per configuration)
- Measurement Range: 0–2 mm linear gap (typical)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Operating Temperature: −40°C to +177°C
- Frequency Response: DC to 10,000 Hz
- Housing Material: Stainless steel, corrosion-resistant
- Connector: Integral coaxial, compatible with 3300 Series drivers
- Weight: Approx. 1,500 g (assembly)
- Country of Origin: USA
Why Engineers Specify This Model
- API 670 Compliant — Meets the mandatory machinery protection standard for critical rotating equipment in oil & gas
- Proven 3300 Series Ecosystem — Direct drop-in compatibility with existing Bently Nevada 3300 drivers, monitors, and System 1 software
- Non-Contact Measurement — Zero mechanical wear; continuous operation without maintenance intervals
- High-Temperature Tolerance — Rated to 177°C for hot-section turbine bearing proximity applications
- EMI/RFI Shielded Cable — Reliable signal integrity in electrically noisy plant environments
- Long-Term OEM Traceability — Full factory documentation and calibration certificates available
Complete System Bill of Materials
For a fully operational Bently Nevada 3300 Series proximity measurement loop, the following components are typically required:
- Proximity Probe Housing Assembly — 31000-28-05-15-030-00-02 (this item)
- Extension Cable — e.g., 330130-045-00-CN (5 m, matched to probe)
- Proximitor® Driver/Oscillator — e.g., 3300 XL 8mm Proximitor (330180-91-00)
- Vibration Monitor Module — e.g., 3500/42M Proximitor/Seismic Monitor
- Rack & Power Supply — 3500 Rack (3500/05-01-02-00-00-01)
- System 1 Software — for data acquisition, trending, and alarm management
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition)
- ISO 10816 / ISO 20816 — Mechanical vibration evaluation standards
- IEC 61508 — Functional safety (SIL-rated system configurations)
- ATEX / IECEx — Hazardous area certifications available for applicable variants
- CE Marking — European conformity for applicable export markets
Quality Assurance & Sourcing
Konmask.com sources Bently Nevada components exclusively through verified industrial distribution channels. Every unit undergoes:
- Visual and dimensional inspection against OEM drawings
- Functional continuity and impedance verification
- Packaging integrity check with anti-static and moisture protection
- Documentation review — part number, date code, and traceability records confirmed
We do not supply counterfeit, refurbished-as-new, or unverified grey-market parts. All stock is traceable to authorized distribution.
How to Source This Part
To place an order or request a quotation for the Bently Nevada 31000-28-05-15-030-00-02:
- Online: Add to cart directly on this page — stock availability confirmed at checkout
- Email RFQ: [email protected] — include quantity, required delivery date, and project site
- Phone/WhatsApp: +0086 19859288691 — available for urgent plant shutdown requirements
- Lead Time: In-stock items ship within 1–3 business days; ex-stock orders confirmed at inquiry
- Export: We support DDP, DAP, and EXW Incoterms for international buyers
Application-Specific FAQ
Q: Is the 31000-28-05-15-030-00-02 compatible with the Bently Nevada 3500 monitoring rack?
A: Yes. This probe assembly is designed for use with the 3300 Series Proximitor drivers, which interface directly with the 3500 Series monitoring rack via standard coaxial signal loops.
Q: Can this probe be used in hazardous (Zone 1 / Division 1) areas?
A: Certain 3300 Series configurations carry ATEX/IECEx certification. Please confirm the specific variant suffix with our technical team before installation in classified areas.
Q: What is the recommended gap voltage for this probe?
A: The nominal operating gap is typically set to −10 VDC (approximately 1.0 mm gap), with alarm and danger setpoints configured per API 670 guidelines in the monitor.
Q: Do you provide calibration certificates?
A: Factory calibration documentation is available upon request. Third-party NIST-traceable calibration can be arranged for critical applications.
Q: What is the difference between the 31000 and 330100 series probe part numbers?
A: The 31000 series designates the complete housing assembly including the probe body and integral cable. The 330100 series refers to the probe tip only. Ensure you order the correct assembly for your installation bracket configuration.
