Turbine Shaft Monitoring Solution – Bently Nevada 3300/45-02-01-02-00 | 3300 Series
The Bently Nevada 3300/45-02-01-02-00 is a precision Differential Expansion Monitor Module engineered for continuous, real-time measurement of rotor-to-casing thermal differential expansion in rotating machinery. Designed for integration within the 3300 Series rack-based monitoring system, this module delivers the measurement accuracy and reliability demanded by power generation, petrochemical, and heavy industrial environments.
Where This Product Is Used
This module is specified by rotating machinery engineers and reliability teams across the following industries and applications:
- Steam Turbines – Monitors rotor-to-casing differential expansion during startup, load changes, and shutdown to prevent blade-tip rubs and catastrophic failure.
- Gas Turbines – Provides continuous differential expansion data for hot-section protection in combined-cycle power plants.
- Centrifugal Compressors – Tracks axial growth differentials in high-speed compressor trains in LNG, refinery, and gas processing facilities.
- Industrial Fans & Blowers – Monitors thermal expansion in large forced-draft and induced-draft fan assemblies.
- Hydro Turbines – Applied in hydroelectric generating units requiring long-term, low-maintenance shaft monitoring.
- Marine Propulsion Systems – Used in naval and commercial vessel turbine monitoring where space-efficient rack modules are required.
Technical Specifications
- Part Number: 3300/45-02-01-02-00
- Series: Bently Nevada 3300
- Module Type: Differential Expansion Monitor
- Measurement: Rotor-to-casing differential expansion (axial)
- Input: Compatible with 3300 Series proximity probes and extension cables
- Output: 4–20 mA analog, relay contact outputs (OK, Alert, Danger)
- Power Supply: 24 VDC (supplied via 3300 rack backplane)
- Rack Compatibility: Bently Nevada 3300 Series 4-slot and 8-slot racks
- Operating Temperature: 0°C to +65°C
- Approvals: CE, FM, CSA (refer to product datasheet for full certification list)
- Weight: 300 g (approx.)
- Country of Origin: USA
Why Engineers Specify This Model
- High-Resolution Measurement – Sub-micron resolution ensures early detection of abnormal thermal growth before damage thresholds are reached.
- Dual-Channel Architecture – Supports redundant sensor inputs for critical machinery where single-point failure is unacceptable.
- Seamless 3300 Rack Integration – Hot-swappable module design minimizes downtime during maintenance or replacement.
- Configurable Alert & Danger Setpoints – Field-adjustable thresholds allow site-specific protection tuning without firmware changes.
- Long-Term Reliability – Bently Nevada’s proven hardware platform with decades of installed base in power and process industries.
- DCS/SCADA Compatible – Analog and relay outputs integrate directly with DeltaV, Honeywell Experion, ABB 800xA, and other control systems.
Complete System Bill of Materials
For a complete differential expansion monitoring loop using the 3300/45-02-01-02-00, the following components are typically required:
- 3300/45-02-01-02-00 – Differential Expansion Monitor Module (this item)
- 3300/05 or 3300/10 – 3300 Series Rack (4-slot or 8-slot)
- 3300/20 – Power Supply Module
- 3300/46 – I/O Module (if external termination required)
- 330400 Series – 8 mm Proximity Probe
- 330130 Series – Extension Cable (specify length)
- 330180 Series – Proximitor Sensor
- Interconnect cable and terminal block accessories
Contact support@konmask.com for complete BOM assistance and compatibility verification.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition) – This module is designed to meet the requirements for differential expansion monitoring per API 670.
- IEC 61511 – Functional Safety for Process Industry Sectors
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation standards
- ATEX / IECEx – Hazardous area certifications available (verify suffix codes)
- CE Marking – Compliant with EU Machinery Directive and EMC Directive
Quality Assurance & Sourcing
Konmask.com sources Bently Nevada 3300 Series modules through authorized distribution channels and verified surplus supply networks. Every unit offered undergoes the following quality process:
- Visual and mechanical inspection upon receipt
- Firmware version and label verification against Bently Nevada documentation
- Functional power-on test where applicable
- Secure anti-static packaging for shipment
- Full traceability documentation available on request
We supply to MRO teams, OEM integrators, EPC contractors, and end-user plant maintenance departments globally.
How to Source This Part
- In Stock: Add to cart and proceed to checkout for immediate dispatch.
- Lead Time Orders: Contact us for volume pricing, scheduled delivery, or project-based procurement.
- RFQ / Bulk Inquiry: Email support@konmask.com with your project BOM for a consolidated quote.
- Urgent Requirement: Call or WhatsApp +0086 19859288691 for same-day response on critical spares.
- Export & Cross-Border: We ship globally with full export documentation, commercial invoice, and packing list.
Application-Specific FAQ
Q: Is the 3300/45-02-01-02-00 compatible with existing 3300 Series racks?
A: Yes. This module is designed for direct installation into any standard Bently Nevada 3300 Series rack without hardware modification.
Q: Can this module replace a 3300/45 with a different suffix?
A: Suffix codes indicate configuration options (input type, output type, approval class). Verify your existing module’s suffix against the replacement before installation. Contact us for cross-reference support.
Q: What probe types are compatible?
A: The 3300/45 series is designed for use with Bently Nevada 330400 Series 8 mm proximity probes and associated Proximitor sensors. Third-party probes may require calibration verification.
Q: Does this module support SIL-rated applications?
A: Bently Nevada 3300 Series modules can be applied in SIL-rated loops when installed per the relevant functional safety manual. Consult the Bently Nevada SIL documentation for this model.
Q: What is the warranty on this part?
A: Konmask.com provides a standard 90-day functional warranty on all tested modules. Extended warranty options are available — contact us for details.
