Turbine & Generator Control Solution — WOODWARD APP-PS7-PCI | PS7 Series PC Board
In gas turbine power plants and industrial generator sets, control system failures during peak load cycles cost operators an average of $50,000–$250,000 per unplanned outage hour. The root cause is frequently traced to aging or counterfeit PC board assemblies within the governor control rack — components that degrade silently under thermal cycling, vibration, and EMI stress until a critical fault halts production. Procurement teams face a compounding problem: OEM lead times of 16–24 weeks and a grey market flooded with remarked boards that pass visual inspection but fail under load.
The WOODWARD APP-PS7-PCI PC Board is a factory-specification power supply and communication interface card engineered for the WOODWARD PS7 governor control platform. It restores full system integrity by providing regulated DC bus power, PCI backplane communication, and fault-isolation logic in a single field-replaceable unit. Sourced through verified WOODWARD distribution channels and subjected to a four-stage incoming inspection protocol, this board eliminates the authenticity risk that makes grey-market procurement so costly — delivering a direct, like-for-like replacement that brings the control rack back to OEM baseline without firmware re-commissioning.
Where This Product Is Used
Gas Turbine Power Generation
• Frame 5 / Frame 6 / Frame 7 gas turbines running WOODWARD PS7 governor racks — board manages fuel-valve actuator power sequencing under ISO 3977 turbine control standards.
• Combined-cycle plant auxiliary systems where 24 VDC bus stability is critical to flame-detection and trip-relay logic.
• Peaking plant fast-start applications requiring cold-start board initialization within 90 seconds of energization.
Industrial Steam Turbine Drives
• Steam turbine-driven compressor trains in petrochemical plants (API 670 machinery protection environments) where the PS7 rack governs speed and extraction pressure simultaneously.
• Cogeneration facilities operating at 50 Hz / 60 Hz dual-frequency sites — board supports both without hardware modification.
• Refinery utility steam headers where governor response time ≤ 50 ms is mandated by process safety management (PSM) plans.
Hydro & Pump-Storage Generation
• Kaplan and Francis turbine governors in run-of-river hydro plants where the PS7 platform controls wicket-gate positioning under IEC 61116 small hydro standards.
• Pump-storage reversible units requiring seamless mode-switching logic supported by the PCI communication bus on this board.
• Remote unmanned hydro stations where MTBF > 80,000 hours is a contractual KPI.
Oil & Gas Compression
• Pipeline gas compressor stations (ASME B31.8 compliance zones) where WOODWARD PS7 governors regulate reciprocating and centrifugal compressor speed.
• Offshore platform gas-lift compressors operating in Class I Div 2 / Zone 2 hazardous areas — board is housed in purged enclosures meeting IEC 60079-2.
• LNG liquefaction train expander-compressors where control system uptime is tied to cargo delivery SLAs.
Marine Propulsion & Auxiliary Power
• Diesel-electric vessel propulsion systems using WOODWARD PS7 for engine governor control, certified under DNV GL and Lloyd’s Register class rules.
• Ship service generator sets where the board provides load-sharing communication between parallel alternators.
• Offshore supply vessel dynamic positioning (DP2) systems requiring redundant governor control with automatic failover.
Industrial Process & Manufacturing
• Paper mill steam turbine drives where governor stability directly affects paper machine draw-section speed synchronization.
• Steel plant rolling-mill motor-generator sets governed by PS7 racks in high-vibration, high-EMI environments.
• Cement plant kiln drive systems where continuous 24/7 operation makes board reliability a maintenance KPI tracked in ISO 55001 asset management programs.
Technical Specifications
| Parameter | Value | Application Relevance |
| Part Number | APP-PS7-PCI | Direct OEM cross-reference for PS7 governor rack |
| Manufacturer | WOODWARD | Original equipment; no third-party substitution |
| Board Type | PC Board / Power Supply & PCI Interface | Dual-function: DC bus regulation + backplane comms |
| Compatible Platform | WOODWARD PS7 Governor Control System | Slot-specific; not interchangeable with PS6 or EG series |
| Input Voltage Range | 18–32 VDC (nominal 24 VDC) | Tolerates battery-backed UPS sag during grid disturbances |
| Output Bus Voltage | Regulated ±15 VDC, +5 VDC | Powers analog I/O and digital logic cards in the same rack |
| Communication Interface | PCI Backplane Bus | High-speed inter-card data exchange for governor algorithms |
| Operating Temperature | 0 °C to +70 °C | Covers panel-interior ambient in tropical and arctic sites |
| Storage Temperature | −40 °C to +85 °C | Safe for long-term warehouse storage in unheated facilities |
| Humidity | 5–95% RH non-condensing | Suitable for coastal and offshore environments |
| Vibration Resistance | Per IEC 60068-2-6 | Qualified for compressor skid and marine deck mounting |
| Weight | 300 g (approx.) | Standard rack-card form factor; no structural modification needed |
| Warranty | 12 months from shipment | Covers latent defects under normal operating conditions |
Why Engineers Specify This Model
• In gas turbine fast-start applications, the APP-PS7-PCI delivers sub-90-second board initialization because its regulated power supply reaches steady-state output within 2 seconds of energization, meeting NERC BAL-002 spinning reserve response requirements.
• In offshore compressor stations, the APP-PS7-PCI delivers sustained operation in salt-fog environments because its conformal-coated PCB surface resists corrosion per IEC 60068-2-52, meeting DNV GL offshore equipment class requirements.
• In parallel generator load-sharing systems, the APP-PS7-PCI delivers deterministic PCI bus latency (<1 ms inter-card cycle) because its backplane interface is hardware-arbitrated rather than software-polled, meeting IEC 61850-5 GOOSE message timing requirements.
• In 24/7 process industry drives, the APP-PS7-PCI delivers >80,000-hour MTBF because it uses industrial-grade capacitors rated at 105 °C / 10,000 hours, meeting ISO 55001 asset reliability KPIs for critical rotating equipment.
• In steam turbine extraction-pressure control, the APP-PS7-PCI delivers stable ±15 VDC analog bus voltage under dynamic load swings because its linear regulation topology eliminates switching noise that would corrupt 4–20 mA pressure transmitter signals, meeting API 670 signal integrity requirements.
• In remote unmanned hydro stations, the APP-PS7-PCI delivers field-replaceable maintenance without firmware re-commissioning because it carries factory-programmed board identity recognized automatically by the PS7 rack supervisor, meeting IEC 61116 remote site maintainability guidelines.
Complete System Bill of Materials
The following components form a complete WOODWARD PS7 governor control system. The APP-PS7-PCI is the power and communication backbone that all other cards depend on:
| Component | Function | Relationship to APP-PS7-PCI |
| APP-PS7-PCI (this item) | Power supply & PCI backplane interface | Master board; all other cards receive power and comms from this unit |
| WOODWARD PS7 Rack / Chassis | Mechanical housing and backplane | Physical host; board slides into designated PS7 rack slot |
| PS7 CPU / Processor Card | Governor algorithm execution | Communicates with APP-PS7-PCI via PCI bus for power status and I/O arbitration |
| PS7 Analog I/O Card | Speed, pressure, temperature signal conditioning | Powered by ±15 VDC regulated output of APP-PS7-PCI |
| PS7 Digital I/O Card | Trip relay, solenoid, and discrete I/O | Powered by +5 VDC logic bus from APP-PS7-PCI |
| PS7 Communication Card (Modbus/Profibus) | SCADA / DCS integration | Shares PCI backplane managed by APP-PS7-PCI |
| 24 VDC UPS / Battery Charger | Uninterruptible power source | Feeds input to APP-PS7-PCI; board tolerates 18–32 VDC sag |
| Panel-Mount Terminal Blocks | Field wiring termination | Connect field sensors and actuators to PS7 I/O cards powered by this board |
| EMI Filter (DIN-rail) | Conducted EMI suppression on DC input | Protects APP-PS7-PCI input from VFD and switchgear noise |
Compliance & Industry Standards
• CE Marking (EU Machinery Directive 2006/42/EC) — Issued by WOODWARD’s EU authorized representative; confirms electromagnetic compatibility and low-voltage safety for European industrial installations.
• UL / cUL Recognition — Issued by Underwriters Laboratories; required for installations in North American industrial facilities under NEC Article 409 (industrial control panels).
• IEC 61010-1 (Safety for Measurement & Control Equipment) — Governs insulation, creepage, and clearance distances; directly relevant to buyers integrating this board into safety-instrumented systems.
• IEC 60068-2 Series (Environmental Testing) — Covers vibration (Test Fc), thermal shock (Test N), and humidity (Test Cab); confirms suitability for the harsh environments described in the application scenarios above.
• RoHS 2 Directive (2011/65/EU) — Confirms absence of restricted hazardous substances; required for export to EU and increasingly mandated by EPC contractors in their vendor qualification checklists.
• REACH Compliance — Confirms no SVHC (Substances of Very High Concern) above 0.1% w/w; required for chemical-sector and pharmaceutical-plant installations.
• ISO 9001:2015 (WOODWARD Manufacturing QMS) — WOODWARD’s production facilities are ISO 9001 certified; buyers can cite this in their supplier qualification documentation.
Quality Assurance & Sourcing
Sourcing Channel: Konmask.com procures WOODWARD components through authorized regional distributors and verified surplus channels with full chain-of-custody documentation. We do not source from anonymous spot-market brokers.
4-Step Incoming Inspection Protocol:
① Visual & Dimensional Inspection — Board markings, part number silk-screen, and connector pin integrity verified against WOODWARD published drawings.
② Date Code & Lot Traceability Check — Date codes cross-referenced against WOODWARD production records; boards with erased or re-marked date codes are rejected.
③ Functional Power-On Test — DC input applied; output bus voltages measured at ±15 VDC and +5 VDC rails under resistive load to confirm regulation within ±2% tolerance.
④ ESD-Safe Packaging Verification — Board re-packaged in anti-static bag with desiccant and foam insert before shipment; packaging integrity documented photographically.
Documentation Available Upon Request:
• Certificate of Conformance (CoC)
• Inspection Test Report (ITR)
• WOODWARD distributor invoice (chain-of-custody)
• RoHS / REACH compliance declaration
• High-resolution pre-shipment photographs
How to Source This Part
Step 1 — Submit Your Requirement
Email support@konmask.com or use the contact form with your part number (APP-PS7-PCI), required quantity, and delivery deadline. Include your plant location and any site-specific certification requirements (e.g., ATEX, DNV GL).
Step 2 — Receive Quotation & Availability Confirmation
Our technical team responds within 24 business hours with price, lead time, stock status, and available documentation. For urgent AOG (Aircraft on Ground) or plant-shutdown situations, flag your inquiry as URGENT for priority handling.
Step 3 — Order, Inspect & Ship
Upon order confirmation, the board undergoes our 4-step inspection protocol. We ship globally via DHL Express, FedEx International Priority, or freight forwarder of your choice. Export documentation (commercial invoice, packing list, HS code 8537.10) is prepared for all international shipments. Typical dispatch: 1–3 business days after payment confirmation.
Application-Specific FAQ
Q1: Can the APP-PS7-PCI be used as a direct replacement in a gas turbine governor rack without reconfiguring the PS7 CPU card?
A: Yes. The APP-PS7-PCI is a like-for-like hardware replacement. The PS7 rack supervisor automatically recognizes the board via its factory-programmed identity on the PCI bus. No firmware changes or CPU reconfiguration are required. This is critical for gas turbine sites where re-commissioning requires a licensed WOODWARD service engineer and can add 2–5 days to outage duration.
Q2: Our offshore compressor station requires documentation for ATEX Zone 2 installation — can you support this?
A: The APP-PS7-PCI itself is installed inside a purged and pressurized (Ex p) enclosure that carries the ATEX / IECEx certification — the board does not carry individual ATEX marking. We can provide the board’s CE declaration and IEC 60068-2 environmental test reports to support your enclosure system documentation package. Contact us with your specific Ex p enclosure model for a compatibility review.
Q3: We manage a fleet of 12 PS7 governor racks across three hydro stations — can Konmask.com support a blanket order with staggered delivery for our preventive maintenance program?
A: Yes. We support blanket purchase orders with scheduled release dates aligned to your PM calendar. We can hold allocated stock under a consignment or reserved-inventory arrangement, provide a single CoC package covering all units, and coordinate delivery to multiple site addresses. Contact support@konmask.com to discuss your fleet maintenance schedule.
