Where This Product Is Used
The PROVIBTECH TM0180-A08-B13-C20-D10 proximity probe is deployed in continuous, mission-critical rotating machinery monitoring applications across heavy industry. Engineers specify this eddy-current sensor wherever non-contact, real-time shaft displacement measurement is required:
- Steam & Gas Turbines — Radial shaft vibration and axial position monitoring on high-speed turbine rotors in power generation plants.
- Centrifugal Compressors — Shaft orbit analysis and rotor dynamic monitoring in petrochemical and LNG compression trains.
- Pumps & Blowers — Bearing clearance and rotor eccentricity measurement in refinery and water-treatment pump stations.
- Gearboxes — Gear mesh vibration and shaft runout detection in industrial drive trains.
- Electric Motors (>500 kW) — Continuous vibration surveillance on large induction and synchronous motors per API 670 requirements.
- Paper & Steel Mill Rolls — Roll position and vibration monitoring in continuous process lines.
Wherever API 670 / ISO 10816 compliance is mandated and machine uptime is non-negotiable, the TM0180 series is the field-proven choice.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | TM0180-A08-B13-C20-D10 |
| Manufacturer | PROVIBTECH |
| Series | TM0180 |
| Sensor Type | Eddy-Current (Non-Contact) Proximity Probe |
| Probe Tip Diameter | 8 mm (A08) |
| Cable Length | 1.3 m integral cable (B13) |
| Linear Range | 2.0 mm (C20) |
| Thread Size | M10 × 1.0 (D10) |
| Output Signal | –24 VDC bias, voltage proportional to gap |
| Sensitivity | 7.87 V/mm (200 mV/mil) nominal |
| Frequency Response | DC to 10 kHz (–3 dB) |
| Operating Temperature | –35 °C to +120 °C |
| Target Material | AISI 4140 steel (standard); consult for other alloys |
| Protection Rating | IP67 |
| Weight | 70 g |
| Compatible Driver/Oscillator | PROVIBTECH TM0180 series driver (sold separately) |
Specifications subject to revision. Always verify against the current PROVIBTECH datasheet before final design-in.
Why Engineers Specify This Model
- Exact API 670 Geometry — The 8 mm tip diameter and M10 thread match the most common API 670 probe boss dimensions, enabling drop-in replacement without re-machining bearing housings.
- 2 mm Linear Range — Optimized for typical journal bearing clearances (0.1–1.5 mm), providing maximum resolution within the operating window.
- 1.3 m Integral Cable — Reaches from the probe boss to the junction box in the majority of standard turbomachinery installations without field splicing.
- Non-Contact Measurement — Zero mechanical wear; sensor life is independent of shaft speed or vibration amplitude.
- DC Response — Captures both dynamic vibration (AC component) and static position / slow roll (DC component) in a single channel.
- IP67 Sealing — Withstands oil mist, wash-down, and condensation in turbine enclosures and compressor skids.
Complete System Bill of Materials
A functional eddy-current measurement channel requires three components. The TM0180-A08-B13-C20-D10 probe is the sensing element; the complete BOM is:
- Proximity Probe — TM0180-A08-B13-C20-D10 (this item)
- Extension Cable — PROVIBTECH TM0180 series extension cable (specify length: 5 m / 9 m standard)
- Driver / Oscillator — PROVIBTECH TM0180 series driver module (–24 VDC supply, 4–20 mA or voltage output)
- Mounting Hardware — M10 × 1.0 lock nut and probe holder (customer-supplied or Konmask-sourced)
- Vibration Monitor / PLC Input Card — Compatible with any API 670 monitor accepting –24 VDC eddy-current input
Contact support@konmask.com to source the complete channel kit.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition): probe geometry and system performance compliant.
- ISO 10816 / ISO 20816 — Mechanical vibration — Evaluation of machine vibration by measurements on non-rotating parts.
- IEC 60529 — IP67 ingress protection rating.
- RoHS Compliant — Restriction of Hazardous Substances Directive.
Quality Assurance & Sourcing
Konmask.com sources PROVIBTECH instrumentation exclusively through authorized distribution channels and verified industrial surplus networks. Every unit offered is:
- Inspected for physical integrity and connector condition prior to listing.
- Stored in ESD-safe, climate-controlled warehousing.
- Shipped with original manufacturer labeling and part markings intact.
- Traceable to batch documentation where available.
We do not sell counterfeit, re-labeled, or specification-downgraded parts. If a unit does not meet our inspection criteria, it is not listed.
How to Source This Part
- Add to Cart — Click Add to Cart for in-stock units. Lead time is typically 1–3 business days for dispatch.
- Request a Quote — For quantities >5 units or complete channel kits, email support@konmask.com with your BOM.
- Urgent / Emergency Sourcing — Call or WhatsApp +0086 19859288691 for same-day response on critical machine-down situations.
- OEM / EPC Procurement — We support blanket PO arrangements and project-based procurement for EPC contractors and OEM service teams.
Application-Specific FAQ
Q: Is the TM0180-A08-B13-C20-D10 a direct replacement for Bently Nevada 330101 series probes?
A: The TM0180 series is designed to be functionally compatible with standard eddy-current monitoring systems. However, always verify sensitivity (V/mm), linear range, and driver compatibility with your specific monitor before installation. Contact us for a compatibility assessment.
Q: Can this probe be used on non-ferrous targets (aluminum, titanium)?
A: Eddy-current probes are sensitive to target material conductivity and permeability. The TM0180 is calibrated for AISI 4140 steel. Use on non-ferrous targets requires field recalibration. Consult PROVIBTECH application notes.
Q: What is the maximum shaft speed this probe can monitor?
A: The DC–10 kHz frequency response supports shaft speeds up to approximately 600,000 RPM for 1× vibration detection. For practical turbomachinery (up to 30,000 RPM), the probe is well within specification.
Q: Do you supply calibration certificates?
A: Calibration certificates from the original manufacturer are supplied where available. For applications requiring fresh NIST-traceable calibration, we can arrange third-party calibration services. Inquire at order time.
Q: What is your return policy for instrumentation?
A: Unused, uninstalled items in original condition may be returned within 14 days. Items that have been installed or show field use are non-returnable. See our full returns policy at Konmask.com.
