Vibration Monitoring Solution – Bently Nevada 330103-00-12-15-01-05 | 3300 XL Series
Where This Product Is Used
The Bently Nevada 330103-00-12-15-01-05 Proximity Transducer System is engineered for continuous, non-contact vibration and position measurement in the most demanding rotating machinery environments. Typical deployment sites include:
- Steam and gas turbine shafts in power generation plants
- Centrifugal and axial compressors in oil & gas processing facilities
- Boiler feed pumps and large motor-driven equipment in petrochemical plants
- Gearboxes and expanders in LNG and refinery operations
- Critical rotating assets monitored under API 670 machinery protection requirements
Technical Specifications
| Part Number | 330103-00-12-15-01-05 |
| Brand | Bently Nevada |
| Series | 3300 XL Proximity Transducer System |
| Probe Type | Proximity Probe Housing Assembly |
| Measurement Principle | Eddy-current (non-contact) |
| Cable Length | 1.2 m (extension cable configurable) |
| Thread Size | 8 mm |
| Linear Range | 0.25 mm – 2.54 mm (10 mil – 100 mil) |
| Output Sensitivity | 7.87 V/mm (200 mV/mil) |
| Operating Temperature | -35°C to +177°C |
| Target Material | AISI 4140 steel or equivalent |
| Weight | 60 g |
| Connector | Integral coaxial connector |
Why Engineers Specify This Model
- Drop-in OEM compatibility: Dimensionally identical to original Bently Nevada 3300 XL installations — no re-wiring or bracket modification required.
- High-temperature resilience: Rated to +177°C, suitable for hot-section turbine bearing pedestals without derating.
- Proven eddy-current linearity: ±1% linearity across the full measurement range ensures accurate shaft orbit and gap DC voltage readings.
- API 670 compliant system: Meets the machinery protection standard mandated by most EPC contractors and plant operators.
- Minimal maintenance: Solid-state, non-contact design eliminates wear parts and reduces planned maintenance intervals.
Complete System Bill of Materials
A fully functional 3300 XL proximity measurement loop requires the following components:
- Proximity Probe: 330103-00-12-15-01-05 (this item)
- Extension Cable: 330130-045-00-00 (1.5 m) or 330130-080-00-00 (8 m)
- Proximitor® Sensor / Driver: 330180-X1-05 or 330180-X1-CN
- Barrier (if IS zone required): 990-04-70-01-00
- Mounting hardware: 02-262783-01 (8 mm probe holder)
Contact support@konmask.com to source the complete loop as a kit.
Compliance & Industry Standards
- API 670 (Machinery Protection Systems) — 5th Edition
- IEC 61508 (Functional Safety) — SIL-capable system architecture
- ATEX / IECEx — available in IS-rated configurations
- CE Marking compliant
- RoHS compliant materials
Quality Assurance & Sourcing
Konmask.com sources Bently Nevada 330103-00-12-15-01-05 units through verified industrial distribution channels. Every unit shipped undergoes:
- Visual and dimensional inspection against OEM datasheet tolerances
- Coaxial connector continuity and impedance verification
- Packaging integrity check with anti-static protection
- Batch traceability documentation available on request
We do not sell counterfeit, refurbished-as-new, or unverified grey-market parts.
How to Source This Part
- Add to cart and complete checkout — we confirm stock and lead time within 1 business day.
- For urgent plant shutdowns or TAR (Turnaround) requirements, email support@konmask.com with your PO or RFQ.
- Bulk orders (5+ units) qualify for volume pricing — request a quote directly.
- DDP (Delivered Duty Paid) shipping available to most countries.
Application-Specific FAQ
Q: Is the 330103-00-12-15-01-05 compatible with the Bently Nevada 3500 rack system?
A: The 3300 XL probe is electrically compatible with 3500 series Proximitor inputs when used with the correct extension cable. Verify the driver module part number before ordering.
Q: What shaft material is required for accurate readings?
A: The probe is calibrated for AISI 4140 steel. For other target materials (stainless, Inconel, titanium), a material correction factor must be applied — consult the Bently Nevada calibration guide or contact our technical team.
Q: Can this probe be used in a hazardous area (Zone 1 / Division 1)?
A: Yes, when paired with an approved IS barrier (e.g., 990-04-70-01-00) and installed per the ATEX/IECEx system certificate. The probe itself is not intrinsically safe in isolation.
Q: What is the typical lead time?
A: In-stock units ship within 2–3 business days. Out-of-stock lead time is 2–4 weeks depending on sourcing. Contact us for real-time availability.
Q: Do you provide a warranty?
A: Yes — 12-month warranty against manufacturing defects. DOA units are replaced or refunded within 30 days of delivery.
