Bently Nevada 330103-00-17-10-02-CN – Eddy-Current Proximity Transducer System | 3300 XL Series
Engineering Background
The Bently Nevada 3300 XL Series represents the industry benchmark for non-contact, eddy-current shaft vibration and position measurement in rotating machinery. Developed by Baker Hughes (Bently Nevada), these transducer systems are deployed globally in turbines, compressors, pumps, and generators where continuous, high-resolution displacement monitoring is mission-critical.
Product Positioning
The 330103-00-17-10-02-CN is a complete proximity transducer system configured with a 5 mm tip diameter probe, 5-metre (16.4 ft) armored extension cable, and -18 mm threaded housing. The CN suffix designates the China-market / special-order configuration variant. It integrates directly with Bently Nevada 3300 series monitors and Keyphasor® systems, providing a plug-and-play solution for OEM and retrofit installations.
Complete Technical Specifications
| Part Number | 330103-00-17-10-02-CN |
| Series / Platform | Bently Nevada 3300 XL Proximity Transducer System |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Sensing Technology | Eddy-current (non-contact) |
| Probe Tip Diameter | 5 mm |
| Thread Size | M8 × 1 (-18 mm body) |
| Cable Length | 5 m (16.4 ft) armored extension cable |
| Linear Range | 0.25 – 2.25 mm (10 – 90 mil) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Frequency Response | DC – 10,000 Hz (–3 dB) |
| Supply Voltage | –24 VDC (nominal) |
| Output Voltage Range | –2 to –18 VDC |
| Temperature Range | –35 °C to +177 °C (probe); –35 °C to +85 °C (driver) |
| Target Material | AISI 4140 steel (standard); other alloys with calibration |
| Connector | BNC (standard) |
| Ingress Protection | IP67 (probe assembly) |
| Approvals | CE, ATEX (consult datasheet for zone ratings) |
| Weight | Approx. 100 g (probe + cable assembly) |
| Country of Origin | United States |
Proven Application Environments
- Steam & Gas Turbines – Shaft radial vibration, axial position, and differential expansion monitoring per API 670
- Centrifugal Compressors – Real-time rotor orbit and eccentricity measurement in petrochemical and LNG plants
- Pumps & Motors – Bearing journal displacement in high-speed rotating equipment
- Gearboxes – Gear mesh frequency analysis and shaft runout detection
- Keyphasor® Reference – Phase reference signal generation for torsional and balancing analysis
- Power Generation – Hydro, nuclear, and thermal plant machinery protection systems
Engineering Advantages
- Non-Contact Measurement – Zero mechanical wear; suitable for continuous 24/7 operation in harsh environments
- High Bandwidth – DC to 10 kHz response captures sub-synchronous, synchronous, and high-frequency vibration components
- OEM System Compatibility – Direct plug-in replacement for existing 3300 XL installations; no recalibration of monitors required
- Armored Cable – Stainless steel armor protects against mechanical damage, oil, and chemical exposure
- Wide Temperature Tolerance – Probe rated to +177 °C for hot-section turbine applications
- API 670 Compliant – Meets machinery protection standard for critical rotating equipment
System Architecture & Signal Flow
The 330103-00-17-10-02-CN operates as a three-component eddy-current system:
- Probe (330103 series) – Generates a high-frequency electromagnetic field at the tip; detects changes in gap distance to the conductive target shaft.
- Extension Cable (02 = 5 m) – Transmits the RF oscillator signal between probe and driver with minimal signal loss; armored jacket provides EMI shielding.
- Proximitor® Driver / Oscillator-Demodulator – Converts the impedance change into a DC voltage output proportional to gap distance (–2 to –18 VDC); connects to Bently Nevada 3300 series monitor input cards.
Signal output feeds directly into 3300/16 or 3300/20 monitor channels, enabling real-time alarm, danger, and trip logic per API 670 setpoints.
Sourcing & Quality Verification
- OEM-Traceable Stock – Units sourced through authorized Bently Nevada / Baker Hughes distribution channels with full traceability documentation available on request.
- Pre-Shipment Inspection – Each unit undergoes dimensional, continuity, and output voltage verification before dispatch.
- Authenticity Guarantee – Konmask.com provides a certificate of conformance (CoC) and, where available, original factory test reports.
- Packaging – Ships in original OEM packaging or equivalent ESD-safe protective packaging with desiccant.
Procurement Process
- Inquiry – Submit your part number, required quantity, and delivery timeline via email or the contact form.
- Quotation – Receive a formal quotation with lead time, pricing (HKD/USD), and shipping options within 24 hours.
- Order Confirmation – Purchase order accepted; payment via T/T, credit card, or agreed terms.
- Quality Check & Dispatch – Pre-shipment inspection completed; tracking number issued within 1–3 business days.
- After-Sales Support – Technical support available for installation, commissioning, and compatibility queries.
Technical FAQ
Q: Is the 330103-00-17-10-02-CN compatible with Bently Nevada 3500 series monitors?
A: The 3300 XL transducer system is optimized for 3300 series monitors. Compatibility with 3500 series requires verification of driver impedance and scale factor matching — contact our technical team for confirmation.
Q: What does the “CN” suffix indicate?
A: The CN suffix designates a China-region or special-configuration variant. Electrically and mechanically it is equivalent to the standard -02 configuration; confirm with your system integrator for any regional certification requirements.
Q: Can this transducer measure axial position as well as radial vibration?
A: Yes. With appropriate mounting (thrust collar target), the 330103 probe can measure axial shaft position. Consult Bently Nevada installation guidelines for axial measurement setup.
Q: What is the minimum order quantity?
A: Single units are available. Volume pricing is available for orders of 5 units or more.
Q: Do you provide calibration certificates?
A: Factory calibration data is available where provided by the OEM. Third-party calibration services can be arranged upon request.
