Vibration Monitoring Solution — BENTLY NEVADA 330130-080-02-00 | 3300 XL Series
Where This Product Is Used
The BENTLY NEVADA 330130-080-02-00 is an 8-meter (80 cm per segment × 10) extension cable engineered for use within the 3300 XL Proximity Transducer System. It bridges the gap between the proximity probe and the Proximitor® sensor in installations where direct mounting is not feasible due to distance, routing constraints, or hazardous-area separation requirements.
Typical deployment environments include:
- Steam & Gas Turbines — shaft radial vibration and axial position monitoring on high-speed rotating machinery
- Centrifugal & Reciprocating Compressors — continuous displacement measurement in petrochemical and LNG plants
- Pumps & Fans — bearing journal orbit analysis in power generation and water treatment facilities
- Gearboxes — differential expansion and eccentricity measurement in heavy industrial drives
- Marine Propulsion Systems — shaft monitoring in offshore platforms and vessel engine rooms
Technical Specifications
| Part Number | 330130-080-02-00 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Series | 3300 XL Proximity Transducer System |
| Cable Length | 8 meters (26.2 ft) |
| Cable Type | Coaxial, armored extension cable |
| Connector Type | MIL-C-5015 style, threaded coupling |
| Operating Temperature | -40°C to +85°C (–40°F to +185°F) |
| Impedance | 50 Ω nominal |
| Compatible Probes | 3300 XL 8mm, 11mm, 14mm proximity probes |
| Compatible Drivers | 3300 XL Proximitor® Sensors |
| Jacket Material | Stainless steel armored braid over PTFE insulation |
| Weight | ~300 g |
| Approvals | CE, FM, ATEX (refer to system certification) |
Why Engineers Specify This Model
- System-Matched Impedance: Factory-calibrated to maintain the 50 Ω coaxial characteristic of the 3300 XL system, ensuring no signal degradation across the full 8 m run.
- Armored Construction: Stainless steel braid provides mechanical protection against abrasion, crush loads, and rodent damage in harsh plant environments.
- PTFE Dielectric: Chemically inert insulation resists oils, solvents, and steam condensate common in turbine enclosures.
- Plug-and-Play Compatibility: Direct OEM replacement — no recalibration of the Proximitor® sensor required when swapping cables of the same length.
- Hazardous Area Routing: Enables physical separation of the probe (Zone 1/Div. 1) from the Proximitor® sensor (safe area), supporting ATEX/IECEx zoning strategies.
- Long Service Life: Rated for continuous operation at elevated temperatures, reducing maintenance intervals in high-cycle machinery.
Complete System Bill of Materials
The 330130-080-02-00 extension cable is one component of a complete 3300 XL proximity measurement chain. A typical system BOM includes:
- Proximity Probe — e.g., 330104-00-06-10-02-00 (8 mm, 5 m integral cable)
- Extension Cable — 330130-080-02-00 (this item, 8 m)
- Proximitor® Sensor / Driver — e.g., 330180-X1-05 (3300 XL 8 mm Proximitor®)
- Barrier / Isolator — MTL or P+F Zener barrier for IS installations
- Rack Monitor — 3500/40M or 3500/42M Proximitor®/Seismic Monitor
- Junction Box — stainless steel, IP66, for field termination
Contact support@konmask.com to source the complete system or individual components.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition): specifies proximity transducer system requirements for critical rotating equipment
- IEC 61511 — Functional Safety for SIS: extension cables used in safety-instrumented loops must maintain signal integrity
- ATEX Directive 2014/34/EU — Equipment for explosive atmospheres; system-level certification applies
- IECEx Scheme — International equivalent for hazardous area equipment
- ISO 10816 / ISO 20816 — Mechanical vibration measurement on non-rotating parts
- CE Marking — Conformity with applicable EU directives
Quality Assurance & Sourcing
Konmask.com sources the 330130-080-02-00 through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual inspection of connectors, armor braid, and jacket integrity
- Continuity and impedance verification against OEM specification
- Secure anti-static packaging with part number label and lot traceability
- Documentation package available on request: test report, CoC, and datasheet
We do not sell counterfeit, refurbished-as-new, or unverified grey-market parts. If provenance documentation is required for your plant’s QA process, please request it at the time of order.
How to Source This Part
- Add to Cart: In-stock units ship within 1–3 business days from our warehouse.
- Request a Quote: For volume orders (5+ units) or project BOM sourcing, email support@konmask.com for a formal quotation.
- Urgent Requirement: Call or WhatsApp +0086 19859288691 for same-day response on critical plant shutdowns.
- Lead Time: Standard stock items ship in 1–3 days; non-stock configurations quoted within 24 hours.
- Export: We ship globally. DDP, DAP, and EXW Incoterms available. HS Code: 8544.42 (insulated electric conductors).
Application-Specific FAQ
Q: Can I use the 330130-080-02-00 with a 3300 NSv or 3300 RAM probe?
A: No. The 330130-080-02-00 is calibrated for the 3300 XL system. Using it with NSv or RAM probes will introduce calibration errors. Specify the correct extension cable for your probe series.
Q: Can I daisy-chain two 8 m extension cables to achieve 16 m total length?
A: Bently Nevada does not recommend chaining extension cables beyond the system’s maximum total cable length specification. Consult the 3300 XL system TDI (Technical Data Information) for maximum allowable cable lengths before doing so.
Q: What happens if the extension cable is damaged in service?
A: A damaged cable will cause erratic or failed proximity readings, potentially triggering spurious trips or masking real machinery faults. Replace immediately. Keep a spare on-site for critical machinery.
Q: Is this cable suitable for use in a Zone 1 hazardous area?
A: The cable itself is passive; hazardous area suitability depends on the complete system certification (probe + cable + Proximitor® + barrier). Verify the system’s ATEX/IECEx certificate covers your zone classification.
Q: Do you provide a Certificate of Conformance?
A: Yes. Request a CoC at the time of order or email support@konmask.com after purchase.
