Rotating Machinery Vibration Monitoring Solution – Bently Nevada 330171-00-12-10-02-CN | 3300 XL Series
Where This Product Is Used
The Bently Nevada 330171-00-12-10-02-CN is a 3300 XL Proximitor® Transducer System engineered for continuous, real-time shaft vibration and position monitoring on critical rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines — radial vibration and thrust position monitoring per API 670
- Centrifugal Compressors — shaft orbit analysis and differential expansion measurement
- Pumps & Fans — bearing clearance monitoring and early-warning fault detection
- Gearboxes — gear mesh frequency and eccentricity tracking
- Petrochemical & Refinery Plants — continuous online protection in hazardous-area installations
- Power Generation Facilities — integration with DCS/PLC safety shutdown systems
Technical Specifications
| Part Number | 330171-00-12-10-02-CN |
| Series | 3300 XL Proximitor® System |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Sensor Type | Eddy-Current Proximity Transducer |
| Probe Cable Length | 12 inches (305 mm) — encoded in part number position 3 |
| Extension Cable Length | 10 m — encoded in part number position 4 |
| Output Signal | −24 VDC nominal (−18 V to −26 V operating range) |
| Scale Factor | 200 mV/mil (7.87 V/mm) |
| Linear Range | 25–325 mil (0.635–8.255 mm) |
| Frequency Response | DC to 10,000 Hz (−3 dB) |
| Target Material | AISI 4140 steel (standard); other alloys available |
| Temperature Range | −35°C to +177°C (probe); −35°C to +85°C (Proximitor) |
| Approvals | ATEX, IECEx, FM, CSA — intrinsically safe |
| Connector | 02 = standard BNC/MIL-spec (position 5 in part number) |
| Country Variant | CN = China market configuration |
| Weight | 220 g (approximate, probe + Proximitor assembly) |
Why Engineers Specify This Model
- API 670 Compliant — meets the machinery protection standard required by most EPC contractors and end-users in oil & gas
- Proven 3300 XL Platform — backward-compatible with existing 3300 Series monitor racks, reducing retrofit cost
- High Signal Integrity — coaxial cable construction minimises EMI pickup in electrically noisy plant environments
- Wide Temperature Tolerance — suitable for hot-section turbine bearing pedestals without derating
- Intrinsic Safety Ratings — ATEX/IECEx certified for Zone 0/1 hazardous areas; no additional barriers required in most installations
- CN Variant — factory-configured and documented for China CCC/SIL compliance documentation packages
Complete System Bill of Materials
A fully functional 3300 XL proximity measurement loop typically requires:
- 330171-00-12-10-02-CN — Proximitor Transducer System (this item)
- 3300/16 or 3500/42 — Vibration Monitor Module (sold separately)
- 3300/20 — Power Supply Module (if not using rack-integrated supply)
- 3500/22M — Transient Data Interface (optional, for waveform capture)
- Mounting bracket & armour conduit — site-specific, customer-supplied
- Bently Nevada System 1 Software — for trend analysis and alarm management
Compliance & Industry Standards
- API 670 — Machinery Protection Systems
- IEC 61511 / IEC 61508 — Functional Safety (SIL-capable loop)
- ATEX Directive 2014/34/EU — Ex ia IIC T6 Ga
- IECEx — International Electrotechnical Commission Explosive atmospheres
- FM Approved — Factory Mutual intrinsic safety
- CSA — Canadian Standards Association
- RoHS Compliant
Quality Assurance & Sourcing
All units offered through Konmask.com are sourced from authorised distribution channels or verified surplus stock. Each unit undergoes:
- Visual inspection for physical damage, connector integrity, and label legibility
- Continuity and impedance verification against Bently Nevada factory specifications
- Serialisation check against known counterfeit databases
- Anti-static packaging with humidity indicator card
- Certificate of conformance (CoC) available upon request
How to Source This Part
Stock availability for the 330171-00-12-10-02-CN changes frequently due to global demand in the oil & gas sector. To confirm current lead time, pricing, and quantity:
- 📧 Email: support@konmask.com
- 📞 Phone/WhatsApp: +0086 19859288691
- 🌐 Web: https://konmask.com
- Bulk orders (>5 units) qualify for volume pricing — contact us for a formal quotation.
Application-Specific FAQ
Q: Is the 330171-00-12-10-02-CN compatible with the 3500 Series monitor rack?
A: Yes. The 3300 XL Proximitor output is electrically compatible with 3500 Series monitor inputs. Verify gap voltage and scale factor settings in the monitor configuration.
Q: What shaft material is required for accurate readings?
A: The standard calibration targets AISI 4140 steel. For stainless steel, Inconel, or other alloys, a material correction factor must be applied — contact Bently Nevada or Konmask for a recalibration certificate.
Q: Can this transducer be used in a SIL 2 safety loop?
A: The 3300 XL system is SIL-capable when integrated with a certified safety monitor module (e.g., 3500/42). A full SIL assessment including PFD calculations should be performed by a qualified functional safety engineer.
Q: What does the “CN” suffix mean?
A: CN denotes the China-market configuration, which includes Chinese-language documentation, compliance paperwork aligned with GB standards, and may include specific connector or cable variants suited to local installation practices.
Q: What is the typical lead time?
A: Ex-stock units ship within 3–5 business days. For new-manufacture orders, lead time is typically 8–14 weeks. Contact us to check current availability.
