Bently Nevada 330180-X1-05 MOD145004-67 — 8mm Eddy-Current Proximity Transducer | 3300 XL Series Platform
Engineering Background
The Bently Nevada 3300 XL Series represents the industry benchmark for continuous machinery protection in rotating equipment applications. Developed by Baker Hughes (Bently Nevada), the 3300 XL platform is engineered to meet API 670 requirements for turbomachinery monitoring, delivering sub-micron resolution and exceptional signal stability in the harshest industrial environments.
Product Positioning
The 330180-X1-05 MOD145004-67 is an 8 mm eddy-current proximity transducer designed for radial vibration, axial position, and differential expansion measurement on steam turbines, gas turbines, compressors, and large rotating machinery. It is the preferred choice for procurement engineers requiring API 670-compliant, drop-in replacement components with full system compatibility.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 330180-X1-05 |
| Modification | MOD145004-67 |
| Series / Platform | Bently Nevada 3300 XL |
| Transducer Type | Eddy-Current Proximity Transducer |
| Probe Tip Diameter | 8 mm |
| Measurement Range | 0.25 mm – 2.25 mm (linear range) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Frequency Response | DC – 10,000 Hz (–3 dB) |
| Operating Temperature | –35°C to +177°C (probe) |
| Cable Length | 5 m (extension cable, system-matched) |
| Target Material | AISI 4140 steel (standard); consult factory for other alloys |
| Power Supply | –24 VDC (via Proximitor® driver) |
| Output Signal | –2 VDC to –18 VDC (DC-coupled) |
| Connector Type | Integral armored cable with MIL-spec connector |
| Ingress Protection | IP67 |
| Compliance | API 670, CE, RoHS |
| Country of Origin | United States |
| Weight | ~60 g |
Proven Application Environments
- Steam Turbines & Gas Turbines: Radial shaft vibration and axial position monitoring per API 670
- Centrifugal & Axial Compressors: Continuous bearing clearance and rotor dynamic measurement
- Large Electric Motors & Generators: Shaft orbit and eccentricity monitoring
- Pumps & Gearboxes: Differential expansion and thrust position measurement
- Petrochemical & Refinery Plants: SIL-rated machinery protection systems
- Power Generation (Nuclear, Thermal, Hydro): Continuous online monitoring in safety-critical loops
Engineering Advantages
- API 670 Compliant: Fully meets the 5th Edition standard for machinery protection systems — no derating or field modification required
- Thermally Stable Output: Proprietary temperature compensation circuitry maintains <±0.5% scale factor drift across the full operating range
- High EMI Immunity: Shielded armored cable and differential signal architecture reject common-mode electrical noise in VFD-rich environments
- Drop-In Replacement: 100% pin-compatible with existing 3300 XL Proximitor® drivers — zero rewiring, zero recalibration required
- Extended MTBF: Solid-state eddy-current design with no moving parts; rated >100,000 hours MTBF in continuous service
- Hazardous Area Rated: ATEX / IECEx certified for Zone 1 & Zone 2 explosive atmospheres
System Architecture & Signal Flow
The 330180-X1-05 operates as part of the complete 3300 XL three-component system:
- Probe (330180-X1-05): Eddy-current sensing element — mounts directly to bearing housing or machinery casing
- Extension Cable (330130-XX-XX): System-matched, impedance-controlled cable — transmits raw oscillator signal from probe to driver
- Proximitor® Driver (3300 XL series): Signal conditioning module — converts raw signal to calibrated DC voltage output for monitor input cards
Output feeds directly into Bently Nevada 3500 Series rack monitors, System 1® software, or any API 670-compliant monitoring system via standard ±24V loop.
Sourcing & Quality Verification
- OEM Traceability: Each unit ships with original Baker Hughes / Bently Nevada documentation and serialized label
- Pre-shipment Testing: 100% functional test — scale factor, linearity, frequency response, and insulation resistance verified before dispatch
- Calibration Certificate: Available upon request (NIST-traceable)
- Packaging: ESD-safe anti-static bag, foam-lined export carton — safe for air freight and sea freight
- Condition: New / Surplus New — never installed, full shelf life
Procurement Process
- Confirm Compatibility: Verify your existing Proximitor® driver model and cable length against your system BOM
- Request Quote: Contact support@konmask.com with your PO number, required quantity, and delivery timeline
- Lead Time: In-stock units ship within 1–3 business days; EXW Xiamen, China
- Payment Terms: T/T, PayPal, Trade Assurance — net 30 available for qualified accounts
- Export Documentation: Commercial invoice, packing list, COO, and MSDS provided for all international shipments
Technical FAQ
Q: Is the 330180-X1-05 compatible with the Bently Nevada 3500/42M monitor?
A: Yes. The 3300 XL probe system is fully compatible with all 3500 Series monitor input cards when paired with the correct 3300 XL Proximitor® driver.
Q: What is the difference between 330180-X1-05 and 330180-X1-CN-05?
A: The “-CN-” suffix denotes a connector-style variant. The base sensing element and scale factor are identical; only the cable termination differs. Confirm your driver input connector before ordering.
Q: Can this probe measure on stainless steel shafts?
A: Eddy-current sensitivity varies with target material conductivity and permeability. For non-standard alloys (316 SS, Inconel, titanium), a field calibration against the actual target is required. Contact our engineering team for target correction factors.
Q: Do you provide ATEX documentation?
A: Yes. ATEX/IECEx certificates and EC Declaration of Conformity are available upon request for all 3300 XL series components.
Q: What is the minimum order quantity?
A: MOQ is 1 unit. Volume pricing available for orders of 5+ units.
