Turbine & Rotating Machinery Vibration Monitoring Solution — Bently Nevada 330903-00-17-50-02-00 | 3300 XL NSv Series
Where This Product Is Used
The Bently Nevada 330903-00-17-50-02-00 is a precision eddy-current proximity transducer system engineered for continuous, non-contact measurement of shaft vibration, position, and differential expansion in critical rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines — radial shaft vibration and axial position monitoring per API 670
- Centrifugal & Axial Compressors — real-time rotor dynamic surveillance in petrochemical and LNG plants
- Pumps & Fans — bearing journal orbit analysis in power generation and water treatment facilities
- Gearboxes & Expanders — high-speed shaft tracking in refinery and upstream oil & gas applications
- Marine Propulsion Systems — shaft displacement monitoring in shipboard turbomachinery
Technical Specifications
- Part Number: 330903-00-17-50-02-00
- Series: 3300 XL NSv (Non-Standard voltage)
- Manufacturer: Bently Nevada (Baker Hughes)
- Sensor Type: Eddy-Current Proximity Transducer
- Cable Length: 5.0 m (extension cable)
- Probe Tip Diameter: 8 mm
- Measurement Range: 0–2.0 mm (linear range)
- Output Signal: –24 VDC bias (NSv configuration)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Frequency Response: DC to 10,000 Hz
- Operating Temperature: –35°C to +121°C (probe); –35°C to +66°C (driver)
- Connector: MIL-C-5015 style
- Approvals: CE, ATEX, IECEx (consult datasheet for zone ratings)
Why Engineers Specify This Model
- NSv Output Compatibility — –24 VDC bias integrates directly with legacy 3300 series monitors without signal conditioning adapters, reducing retrofit cost.
- High-Temperature Probe Body — rated to 121°C continuous, suitable for hot-section turbine bearing pedestals without additional thermal shielding.
- Plug-and-Play with 3300 XL Monitors — factory-calibrated as a matched system (probe + extension + driver); no field calibration required on installation.
- API 670 Compliant — meets the machinery protection standard mandated by EPC contractors and plant operators in oil & gas and power sectors.
- Proven Field Reliability — Bently Nevada 3300 XL systems are installed in tens of thousands of turbomachinery trains worldwide, with documented MTBF exceeding 10 years in continuous service.
Complete System Bill of Materials
The 330903-00-17-50-02-00 is supplied as a complete, factory-matched proximity transducer system. Typical companion components for a full channel installation:
- 3300 XL 8 mm Proximity Probe (included in system)
- 3300 XL Extension Cable — 5.0 m (included)
- 3300 XL NSv Driver / Proximitor® (included)
- Monitor (sold separately): Bently Nevada 3300/16 or 3500/40M Proximitor® Monitor
- Mounting Hardware (sold separately): Probe holder, lock nut, and armored conduit fittings
- DCS/PLC Interface (sold separately): 4–20 mA output module or direct Modbus RTU gateway
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition)
- IEC 61511 — Functional Safety for Process Industry (SIL-capable installation)
- ATEX Directive 2014/34/EU — Zone 1 & Zone 2 hazardous area ratings (verify suffix)
- IECEx Scheme — International hazardous location certification
- CE Marking — EU electromagnetic compatibility and low-voltage directives
- ISO 10816 / ISO 20816 — Mechanical vibration evaluation of machinery
Quality Assurance & Sourcing
Konmask.com sources Bently Nevada 330903-00-17-50-02-00 units through authorized industrial distribution channels and verified surplus inventory networks. Every unit undergoes the following before shipment:
- Visual and dimensional inspection against OEM datasheet tolerances
- Functional continuity and bias voltage verification
- Serialization check and traceability documentation
- Anti-static packaging with humidity indicator card
- Certificate of conformance (CoC) available upon request
How to Source This Part
Ready to order or need a formal quotation for your procurement team? Here’s how to proceed:
- Add to Cart — for immediate purchase with standard lead time
- Request a Quote — email support@konmask.com with your PO requirements, quantity, and delivery address
- Expedite / Urgent Need — call or WhatsApp +0086 19859288691 for same-day response on critical plant shutdowns
- Bulk / Project Orders — volume pricing available for EPC contractors and OEM integrators; contact us for a project BOM review
Application-Specific FAQ
Q: Is the 330903-00-17-50-02-00 compatible with the Bently Nevada 3500 rack?
A: The NSv output (–24 VDC) is designed for 3300 series monitors. For 3500 racks, verify the Proximitor® driver compatibility or specify the standard –18 VDC variant (330903-00-17-50-01-00).
Q: Can this transducer be used on non-conductive shafts?
A: No. Eddy-current proximity transducers require an electrically conductive target material (typically steel or Inconel). For non-conductive targets, a laser or capacitive displacement sensor is required.
Q: What is the maximum shaft speed this system can measure?
A: The 3300 XL system supports frequency response up to 10,000 Hz, making it suitable for machinery operating up to 600,000 RPM in theory; practical limits are set by the monitor’s input bandwidth.
Q: Do you provide installation and commissioning support?
A: Konmask.com provides technical documentation and remote commissioning guidance. On-site services can be arranged through our partner network — contact us for details.
Q: Is a calibration certificate included?
A: A factory calibration record is available for new units. For surplus/refurbished stock, a third-party calibration certificate can be arranged upon request at additional cost.
