Rotating Machinery Vibration Monitoring Solution – Bently Nevada 330904-00-07-10-02-05 | 3300 NSv Series
Where This Product Is Used
The Bently Nevada 330904-00-07-10-02-05 is an eddy-current proximity probe engineered for continuous, non-contact vibration and position measurement on rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines – shaft radial vibration monitoring per API 670
- Centrifugal Compressors – rotor dynamic displacement measurement in petrochemical plants
- Pumps & Fans – bearing journal orbit analysis in power generation facilities
- Gearboxes – gear mesh frequency and axial position tracking
- Marine Propulsion Systems – shaft alignment verification and thrust position monitoring
- Paper & Steel Mills – roll position and vibration in high-temperature process lines
This probe is the sensing element in a complete 3300 NSv measurement chain, working in conjunction with an extension cable and a 3300 XL or 3500 series proximitor/oscillator to deliver a calibrated –24 VDC output signal.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 330904-00-07-10-02-05 |
| Series | Bently Nevada 3300 NSv |
| Sensing Technology | Eddy-Current (Non-Contact) |
| Probe Tip Diameter | 7.87 mm (5/16 in) |
| Integral Cable Length | 5.0 m (16.4 ft) |
| Thread Size | 10-32 UNF |
| Connector Type | 2-pin MIL-C-26482 (02-05 shell) |
| Linear Range | 0.25 – 2.54 mm (10 – 100 mil) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Frequency Response | DC – 10,000 Hz (–3 dB) |
| Operating Temperature | –35 °C to +177 °C |
| Target Material | AISI 4140 Steel (standard) |
| Weight | 620 g (probe + cable assembly) |
| Approvals | CE, ATEX, IECEx (consult datasheet) |
Why Engineers Specify This Model
- Proven 3300 NSv Platform – drop-in compatible with existing 3300 XL proximitor systems; no recalibration of the monitoring rack required.
- 7 mm Tip for Tight Clearances – the 330904 body diameter fits standard API 670 probe bosses without machining modifications.
- 5 m Integral Cable – eliminates one field-splice junction, reducing signal noise and improving MTBF in high-vibration environments.
- 02-05 Connector Shell – mates directly with standard Bently Nevada extension cables (330130 series) for a sealed, moisture-resistant signal path.
- Wide Temperature Range – qualified to +177 °C, suitable for hot-section turbine bearing pedestals without additional thermal shielding.
- Non-Contact Measurement – zero mechanical wear; designed for continuous 24/7 operation across the full machinery lifecycle.
Complete System Bill of Materials
A fully functional 3300 NSv measurement loop requires the following components:
- Proximity Probe: 330904-00-07-10-02-05 (this item)
- Extension Cable: 330130-XX-XX (length to suit installation; 5 m or 9 m typical)
- Proximitor / Oscillator: 3300 XL 8mm Proximitor (330180-X1-CN) or 3500/42M module
- Barrier / Isolator: MTL 787S+ or equivalent Zener barrier (for hazardous area installations)
- Mounting Hardware: API 670 probe holder, lock nut, and armored conduit fitting
Contact support@konmask.com to source the complete loop as a kit.
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition): probe geometry and scale factor comply with standard measurement chain requirements.
- ISO 10816 / ISO 20816 – Mechanical vibration evaluation of machines; probe output is compatible with all major condition monitoring platforms.
- ATEX Directive 2014/34/EU – suitable for use in Zone 1 & Zone 2 hazardous areas when installed with approved barriers (verify ATEX certificate for specific configuration).
- IECEx – international equivalent certification for global plant installations.
- CE Marking – compliant with applicable EU directives for industrial instrumentation.
Quality Assurance & Sourcing
Every 330904-00-07-10-02-05 unit offered by Konmask.com is:
- Sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Inspected for physical integrity, connector condition, and cable continuity prior to dispatch.
- Shipped with original manufacturer packaging where available, or in ESD-safe anti-static packaging.
- Accompanied by a Certificate of Conformance (CoC) upon request.
- Covered by Konmask’s 90-day quality guarantee against manufacturing defects.
How to Source This Part
- Add to Cart – click the purchase button above for in-stock units ready for immediate dispatch.
- Request a Quote – for volume orders (5+ units) or complete measurement loop kits, email support@konmask.com with your project BOM.
- Lead Time – in-stock units ship within 1–3 business days; ex-stock orders typically 2–4 weeks.
- Export & Customs – Konmask handles export documentation for international shipments; HS Code 9031.80 applies.
Application-Specific FAQ
Q: Is the 330904-00-07-10-02-05 compatible with the 3500 series monitoring rack?
A: Yes. The 3300 NSv probe is fully compatible with the 3500/42M Proximitor I/O module when paired with the correct 3300 XL proximitor. Verify the proximitor part number matches your rack slot configuration.
Q: Can this probe measure axial position as well as radial vibration?
A: Yes. With appropriate mounting (thrust probe bracket), the 330904 can be configured for axial position (thrust) measurement. Consult Bently Nevada application note AN-028 for installation guidance.
Q: What target material correction is needed for stainless steel shafts?
A: The standard calibration is for AISI 4140 steel. For 316 stainless steel targets, a scale factor correction of approximately –8% applies. Bently Nevada provides target material correction curves in the 3300 NSv datasheet.
Q: Is a spare probe sufficient for a hot-swap replacement?
A: Yes, provided the replacement probe is from the same calibrated system (same probe + extension cable + proximitor combination). Mixing components from different calibrated sets requires field recalibration.
Q: Do you supply the matching extension cable and proximitor?
A: Yes. Contact us with your required cable length and proximitor model to receive a matched, pre-tested measurement loop.
