Bently Nevada 330908-00-15-70-02-05 NSv Proximity Probe | Replacement, Equivalent & Selection Guide
The Bently Nevada 330908-00-15-70-02-05 is a high-precision NSv Series Proximity Probe designed for continuous, non-contact vibration and position monitoring of rotating machinery. Engineered to meet the demanding requirements of turbines, compressors, pumps, and motors in critical industrial environments, this probe integrates seamlessly with Bently Nevada 3300 and 3500 series monitoring systems.
At Konmask.com, we supply genuine and compatible-grade automation components with full traceability, fast global shipping, and expert pre-sales selection support.
Technical Specifications
- Part Number: 330908-00-15-70-02-05
- Series: NSv (Non-contact, Shaft-vibration)
- Manufacturer: Bently Nevada (Baker Hughes)
- Probe Type: Eddy-current proximity probe
- Probe Cable Length: 15 cm (integral cable)
- Extension Cable Length: 70 cm
- Driver / Oscillator: Compatible with 3300 XL 8 mm driver (330180)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linear Range: 0.25 – 2.54 mm (10 – 100 mil)
- Nominal Gap Voltage: −10 VDC at 1.27 mm (50 mil)
- Operating Temperature: −35 °C to +177 °C
- Tip Diameter: 8 mm
- Thread: M10 × 1
- Connector Code: 02 (standard BNC-compatible)
- Housing Material: Stainless steel
- Approvals: CE, ATEX (refer to datasheet for zone classification)
- Standard Compliance: API 670 4th Edition
Compatible Replacement & Equivalent Models
The following models are functionally equivalent or drop-in replacements for the 330908-00-15-70-02-05. Always verify cable length, driver compatibility, and connector type before substitution.
- 330908-00-15-70-02-00 — Same probe body, alternate connector variant
- 330908-00-30-70-02-05 — 30 cm probe cable, otherwise identical
- 330908-00-50-70-02-05 — 50 cm probe cable, extended-reach variant
- 330780-50-00 — 3300 XL 8 mm proximity probe, compatible driver system
- 330730-040-00-00 — 3300 NSv 8 mm probe, alternative NSv series
- 330100-90-00 — Legacy 7200 series equivalent (verify system compatibility)
- Emerson / Epro PR6423 — Third-party eddy-current equivalent (requires reconfiguration)
- Metrix ST5484E — Alternative proximity transducer for 3300-compatible systems
⚠ Replacement selection must match the original probe’s gap voltage, sensitivity, and driver pairing. Contact our engineers for a free compatibility check.
Why Choose the Original 330908-00-15-70-02-05
- ✅ Factory-calibrated sensitivity of 7.87 V/mm for direct system integration — no field calibration required
- ✅ Certified compatibility with Bently Nevada 3300 and 3500 monitoring racks
- ✅ High-temperature rated to +177 °C for steam turbine and hot-section applications
- ✅ Stainless steel housing resists corrosion in oil, gas, and chemical environments
- ✅ Plug-and-play replacement — no recalibration required when replacing like-for-like
- ✅ API 670 compliant for critical machinery protection installations
- ✅ Full OEM traceability with batch documentation available on request
Typical Applications
- Steam and gas turbine shaft radial vibration monitoring
- Centrifugal compressor radial and axial position measurement
- Pump and motor bearing displacement monitoring
- Gearbox and fan shaft eccentricity detection
- Critical machinery protection systems (API 670 compliant installations)
- Petrochemical, power generation, and LNG plant machinery trains
System Compatibility
- Bently Nevada 3300 Series: 3300 XL 8 mm Proximity Transducer System
- Bently Nevada 3500 Series: 3500/42M, 3500/40M proximity monitor modules
- Driver / Oscillator: 330180 (3300 XL 8 mm driver, 5 m / 9 m total cable)
- Extension Cable: 330130 series (total system cable length must not exceed 9 m)
- System Standard: API 670 4th Edition machinery protection
Selection Guide
Use the table below to identify the correct cable-length variant for your installation:
| Parameter | 330908-00-15-70-02-05 | 330908-00-30-70-02-05 | 330908-00-50-70-02-05 |
|---|---|---|---|
| Probe Cable Length | 15 cm | 30 cm | 50 cm |
| Extension Cable | 70 cm | 70 cm | 70 cm |
| Total System Length | ~1.0 m | ~1.2 m | ~1.5 m |
| Typical Use Case | Compact bearing housings | Standard installations | Extended-reach applications |
Need a custom cable length or non-standard connector? Contact us — we can source special configurations.
Quality Assurance & Sourcing
- Source: Authorized distribution channels and certified surplus with full documentation
- Inspection: Each unit visually inspected and cross-referenced against OEM part number
- Packaging: Original OEM packaging where available; otherwise anti-static protective packaging
- Warranty: 12-month warranty against manufacturing defects
- Lead Time: In-stock items ship within 1–3 business days; sourced items 5–15 business days
- Documentation: Certificate of conformance, packing list, and commercial invoice provided
How to Order
- Confirm your part number: 330908-00-15-70-02-05
- Verify quantity and required delivery timeline
- Add to cart or contact us directly for bulk pricing and lead time confirmation
- Provide your shipping address and preferred Incoterm (EXW, FOB, DDP available)
- Receive proforma invoice → confirm payment → dispatch with full tracking
📧 Email: [email protected]
📞 Phone / WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can I use 330908-00-15-70-02-05 to replace a 330905 series probe?
A: The 330905 uses a 5 mm tip vs. the 330908’s 8 mm tip. They are not directly interchangeable without modifying the probe holder and recalibrating the gap voltage. Contact us for guidance.
Q: Is this probe compatible with the Bently Nevada 3500/42M monitor?
A: Yes. The 330908-00-15-70-02-05 is fully compatible with the 3500/42M Proximitor Monitor when paired with the correct 330180 driver and within the 9 m total cable length limit.
Q: Can a third-party probe (e.g., Epro PR6423) replace this unit?
A: Third-party probes may be electrically compatible but require system reconfiguration and validation. We recommend OEM parts for API 670 certified installations. We can supply both options.
Q: What is the gap voltage for this probe?
A: The nominal gap voltage is −10 VDC at the midpoint of the linear range (approximately 1.27 mm / 50 mil gap). Refer to the Bently Nevada 3300 XL 8 mm system datasheet for full calibration curves.
Q: Do you provide calibration certificates?
A: Yes. Calibration certificates and certificates of conformance are available upon request for all new OEM units.
